技術仕様
WHEELS & TIRES
| Rear Wheel | DT R460, sealed cartridge hubs, 14g spokes, 24h |
| Front Tire | RoadSport, 700x26mm |
| Inner Tubes | Presta, 40mm valve |
| Rear Tire | RoadSport, 700x26mm |
| Front Wheel | DT R460, sealed cartridge hubs, 14g spokes, 20h |
COCKPIT
| Handlebars | Specialized Shallow Drop, 6061, 70x125mm, 31.8mm clamp |
| SeatPost | Alloy, 2-bolt Clamp, 12mm offset, 27.2mm, anti-corrosion hardware |
| Seat Binder | Bolt-type, 31.8mm |
| Tape | Specialized S-Wrap |
| Saddle | Body Geometry Bridge Saddle, steel rails |
| Stem | Specialized, 3D-forged alloy, 4-bolt, 7-degree rise |
DRIVETRAIN
| Chain | KMC X11 Extra Lightweight, 11-speed |
| Cassette | Shimano 105, 11-speed, 11-32t |
| Crankset | Praxis Alba |
| Rear Derailleur | Shimano 105 R7000 GS, medium cage, 11-speed |
| Shift Levers | Shimano 105 R7000, 11-speed |
| Front Derailleur | Shimano 105 |
| Bottom Bracket | Praxis 68mm BSA |
| Chainrings | 50/34T |
SUSPENSION
| Fork | Specialized FACT carbon, 1-1/8" to 1-3/8" taper, fender eyelets |
BRAKES
| Front Brake | Axis 1.0 caliper |
| Rear Brake | Axis 1.0 caliper |
FRAMESET
| Frame | Specialized E5 Premium Aluminum, fully manipulated tubing w/ SmoothWelds, 1-1/8"- 1-3/8" tapered head tube, internal cable routing, threaded BB, 130mm spacing |
* 予告なしに仕様が変更されることがあります。
マニュアルのダウンロード
Allez - ジオメトリー
ジオメトリー
| 44 | 49 | 52 | 54 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|---|
| Crank Length | 165mm | 165mm | 170mm | 172.5mm | 172.5mm | 175mm | 175mm |
| Stem Length | 70mm | 80mm | 90mm | 100mm | 100mm | 110mm | 110mm |
| Seatpost Length | 300mm | 300mm | 350mm | 350mm | 350mm | 350mm | 350mm |
| Saddle Width | 155mm | 155mm | 155mm | 143mm | 143mm | 143mm | 143mm |
| Handlebar Width | 360mm | 380mm | 400mm | 420mm | 420mm | 440mm | 440mm |
| Reach | 365mm | 374mm | 376mm | 380mm | 385mm | 390mm | 396mm |
| Stack | 516mm | 535mm | 552mm | 570mm | 596mm | 627mm | 649mm |
| Wheelbase | 974mm | 982mm | 983mm | 991mm | 999mm | 1014mm | 1021mm |
| Bike Stand-Over Height | 697mm | 720mm | 745mm | 763mm | 785mm | 813mm | 839mm |
| Head-Tube Length | 110mm | 125mm | 140mm | 155mm | 180mm | 215mm | 235mm |
| Front-Center | 567mm | 575mm | 576mm | 585mm | 593mm | 607mm | 614mm |
| Fork Rake/Offset | 47mm | 47mm | 47mm | 47mm | 47mm | 47mm | 47mm |
| Head-Tube Angle | 71.5° | 72.25° | 73° | 73° | 73.5° | 73.5° | 74° |
| Trail | 64mm | 59mm | 55mm | 55mm | 52mm | 52mm | 49mm |
| B-B Height | 263mm | 263mm | 263mm | 264mm | 264mm | 265.5mm | 265.5mm |
| Chain-Stay Length | 420mm | 420mm | 420mm | 420mm | 420mm | 420mm | 420mm |
| Fork Length (full) | 368mm | 368mm | 368mm | 368mm | 368mm | 368mm | 368mm |
| Seat-Tube Angle | 75.25° | 75.25° | 73.25° | 73.25° | 73.25° | 73.25° | 73.25° |
| B-B Drop | 77mm | 77mm | 77mm | 76mm | 76mm | 74.5mm | 74.5mm |
| Seat-Tube Length | 430mm | 460mm | 490mm | 510mm | 530mm | 550mm | 580mm |
| Top-Tube Length (horizontal) | 501mm | 515mm | 542mm | 552mm | 564mm | 579mm | 591mm |
