2014 Myka Disc 26
0 Avis
Built for lightweight performance with anatomical engineering and components for…
Couleur:
Gloss White/Moto Green
Quelle est ma taille ?
Sélectionnez un(e) Taille
Indisponible
Cet article est indisponible via Trouver en magasin
Caractéristiques du produit
Built for lightweight performance with anatomical engineering and components for women, the Myka is the best-performing recreational mountain bike at a value everyone can appreciate. Myka component highlights include an 80mm-travel SR Suntour fork, Tektro disc brakes and Shimano trigger shifters.
A1 Premium Aluminum frame with Women's Recreational XC Geometry and low standover for a confident and lightweight ride
80mm smooth-travel SR Suntour fork with preload adjustment, lockout, and custom women's spring weights delivers size-appropriate tunability for varying terrain
Shimano Altus 8-speed rear derailleur with Sunrace 8-speed cassette for crisp shifting
Women's Body Geometry Riva Plus saddle features a women's cutout and plush seating area for all-day riding comfort
Tektro Novela mechanical disc brakes with women's shorter reach levers assure precise braking and durability
Spécifications techniques
FRAMESET
SEAT BINDER
Alloy, 34.9mm, QR, nylon washer, anti-corrosion bolt
HEADSET
1-1/8"" threadless, loose ball
FRAME
Specialized Myka A1 Premium Aluminum, Women's Recreational XC Geometry and tubesets, forged dropouts w/ replaceable alloy hanger
SUSPENSION
FORK
SR Suntour XCT-MLO 26"", custom women's coil/MCU spring, 1-1/8"" steel steerer, mechanical lockout w/ preload adj., 28mm steel stanchions, post-mount disc, 80mm travel
WHEELS
SPOKES
Stainless, 14g (2.0mm)
FRONT TIRE
Specialized Fast Trak Sport, 26x2.0"", wire bead, 40TPI
REAR TIRE
Specialized Fast Trak Sport, 26x2.0"", wire bead, 40TPI
FRONT HUB
Disc, alloy, Hi Lo flange, double-sealed, loose ball, steel axle, QR, 32h
REAR HUB
Disc, alloy, Hi Lo flange, double-sealed, loose ball, steel axle, steel cassette body, QR, 32h
RIMS
Specialized Disc 26"", alloy double-wall, 25mm, pin joint, 32h
INNER TUBES
Standard Schrader valve
DRIVETRAIN
CHAIN
KMC X8
FRONT DERAILLEUR
Shimano Tourney, 7/8-speed, 34.9mm clamp, low-mount, top-swing, dual-pull
REAR DERAILLEUR
Shimano Altus, 8-speed, SGS Cage
SHIFT LEVERS
Shimano ST-EF51, 8-speed, EZ Fire Plus
CASSETTE
Sunrace, 8-speed, 11-34
CHAINRINGS
42/34/24, steel
BOTTOM BRACKET
Square taper, cartridge bearings, 68mm shell
CRANKSET
Alloy, square taper, w/ chainguard
COCKPIT
STEM
Specialized alloy, 4-bolt clamp, 10-degree rise, 25.4mm, anti-corrosion hardware
HANDLEBARS
Specialized riser bar, Hi-Ten steel, 620mm/640mm wide, 8-degree backsweep, 25.4mm
GRIPS
Specialized Women's Myka, dual-density, Kraton
SEATPOST
Alloy, 2-bolt, 12.5mm offset, 30.9mm
SADDLE
Specialized Body Geometry Riva Plus Women's, steel rails, 155mm
BRAKES
BRAKE LEVERS
Included w/ shifter
FRONT BRAKE
Tektro Novela, mechanical disc, dual pad angle adjustment, 160mm rotor
REAR BRAKE
Tektro Novela, mechanical disc, dual pad angle adjustment, 160mm rotor
ACCESSORIES
PEDALS
Composite platform, w/ reflectors, 9/16""
* Les poids sont basés sur les cadres peints en production comme illustré. Les poids réels varieront en fonction de la couleur, de la taille du cadre et de la variation des composants. Les spécifications sont sujet à changement sans préavis.
Géométries
| 13.0 | 15.0 | 17.0 | 19.0 | |
|---|---|---|---|---|
| Longueur tube (horizontal) | 525mm | 545mm | 575mm | 595mm |
| Top Tube Length (Actual) | 515mm | 526mm | 550mm | 570mm |
| Angle de tube de selle (effectif) | 330mm | 381mm | 432mm | 483mm |
| Boîte de pédalier - axe de roue | 36mm | 36mm | 36mm | 36mm |
| Boîte de pédalier - sol | 300mm | 300mm | 300mm | 300mm |
| Empattement | 1027mm | 1047mm | 1069mm | 1089mm |
| Hauteur cadre à l’entrejambe | 650mm | 688mm | 725mm | 762mm |
| Stack | 566mm | 566mm | 604mm | 613mm |
| Reach | 362mm | 382mm | 390mm | 407mm |
| Longueur de douille de direction | 100mm | 100mm | 120mm | 130mm |
| Angle de direction | 69.5° | 69.5° | 69.5° | 69.5° |
| Longueur bases | 426mm | 426mm | 426mm | 426mm |
| Angle de Tube de selle | 74° | 74° | 73° | 73° |
| Longueur manivelles | 170mm | 170mm | 170mm | 175mm |
| Largeur de cintre | 640mm | 640mm | 660mm | 680mm |
| Longueur de potence | 60mm | 75mm | 75mm | 90mm |
| Longueur de tige de selle | 300mm | 350mm | 350mm | 400mm |
Téléchargements manuels
Pour les avertissements de sécurité, veuillez consulter la documentation dans la section "Téléchargements de manuels" de cette page.
