2015 Stumpjumper EVO 29

0 Avis

Couleur:

Satin/Gloss Black/Charcoal/Rocket Red

Quelle est ma taille ?

Impériale

Métrique

Entrez vos mensurations et nous calculerons votre taille idéale.

Hauteur:

Pour un résultat plus précis, inclure la longueur de votre tibia.

Sélectionnez un(e) Taille

Choisissez la couleur et la grandeur que vous voulez pour pour le chercher dans l'inventaire du magasin le plus proche

Indisponible

Cet article est indisponible via Trouver en magasin

Livrer à -----

Caractéristiques du produit

The Stumpjumper EVO 29 features an all-new M5 aluminum frame, 1X10 drivetrain and aggressive Purgatory and Ground Control tires, to meet the demands of charging trail riders.

SRAM X0 Type 2, 10-speed, mid-cage rear derailleur for lightweight, pinpoint shifts
Roval Traverse Fattie 29 rims w/ Hi Lo hubs, 142+ rear hub spacing and 12mm axle for confident control
Versatile and lightweight Purgatory/Butcher Control tire combo
New M5 alloy frame w/ 29er geometry and PF30 BB for a responsive and race-ready design
SRAM X1 11-speed, PF30 crankset for optimal power and efficiency
Command Post XCP dropper post with carbon lower is engineered for XC racing
Specialized XC mini-rise handlebar for precise handling and control
The custom color—Rocket Red—is designed to naturally age over time. It will exhibit splashes of a dark rich color when exposed to prolonged direct sunlight. This finish is deliberate and therefore not covered under the traditional warranty policy.
RockShox Pike RC 120mm-travel fork w/ 15mm thru-axle is tuned to charge technical terrain
Shimano SLX hydraulic disc brakes w/ Ice Tech pads for total control and performance

Spécifications techniques

FRAMESET

FRAME

M5 alloy, 29” EVO geometry, tapered headtube, PF30 BB, internal shift/brake routing, 142mm dropouts, PM 160 rear brake, replaceable alloy rear derailleur hanger

HEADSET

1-1/8"" and 1-1/2"" threadless, Campy style upper with 1-1/2"" lower, cartridge bearings

SEAT BINDER

Alloy, 31.8mm

SUSPENSION

FORK

RockShox Pike RC 29, Solo Air spring, tapered alloy steerer, w/ lockout, compression, rebound adj., 15mm thru-axle, 120mm travel

WHEELS

RIMS

Roval Traverse Fattie 29, alloy disc, 29mm inner width, 32h

FRONT HUB

Specialized Hi Lo disc, sealed cartridge bearings, 15mm thru-axle, 32h

REAR HUB

Specialized Hi Lo disc, 4 sealed cartridge bearings, 12mm thru-axle, 32h

SPOKES

DT Swiss Industry, stainless

REAR TIRE

Specialized Ground Control, 60TPI, 2Bliss Ready, folding bead, 29x2.1""

DRIVETRAIN

REAR DERAILLEUR

SRAM X0 Type 2, 10-speed, mid cage

SHIFT LEVERS

SRAM X7, 10-speed, w/ MatchMaker clamp

CASSETTE

SRAM PG 1030, 10-speed, 11-36

CHAIN

SRAM PC 1031, 10-speed, w/ PowerLink, nickel finish

CRANKSET

SRAM X1 1000, X SYNC ring, PF30, 32T, 94mm BCD spider

BOTTOM BRACKET

SRAM, PF30, OS press-in bearings, sealed cartridge

COCKPIT

STEM

Specialized, forged alloy, 6-degree rise

HANDLEBARS

Specialized XC, mini rise, 7050 alloy, 8-backsweep, 6-upsweep, 10mm rise, 31.8mm

GRIPS

Specialized Sip Grip, light lock-on, half-waffle, S/M: regular thickness, Others: XL

SADDLE

Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm

SEATPOST

Command Post XCP, carbon lower tube, 2-position height adjustable, internal routing, 35mm travel, 27.2mm

BRAKES

FRONT BRAKE

Shimano SLX BR-M675, hydraulic disc, metallic pads, S/M: 180mm rotor, Others: 160mm

REAR BRAKE

Shimano SLX BR-M675, hydraulic disc, metallic pads, 160mm rotor

BRAKE LEVERS

Shimano SLX BL-M675, hydraulic, alloy lever

ACCESSORIES

PEDALS

Resin test ride, w/ toe clips, CEN std.

* Les poids sont basés sur les cadres peints en production comme illustré. Les poids réels varieront en fonction de la couleur, de la taille du cadre et de la variation des composants. Les spécifications sont sujet à changement sans préavis.

Géométries

	S	M	L	XL
Ground-Top	935mm	935mm	940mm	954mm
Longueur tube (horizontal)	575mm	603mm	630mm	653mm
Longueur tube de selle - centre à sommet	350mm	400mm	400mm	400mm
Seat Tube Angle (Effective)	73.5°	73.5°	73.5°	73.5°
Hauteur de la douille de direction	94mm	94mm	100mm	115mm
Top Tube Length (Actual)	568mm	585mm	608mm	629mm
Seat Tube Length - Center to Top	394mm	434mm	470mm	520mm
Boîte de pédalier - axe de roue	61mm	61mm	61mm	61mm
Boîte de pédalier - sol	310mm	310mm	310mm	310mm
Empattement	1093mm	1121mm	1149mm	1173mm
Hauteur cadre à l’entrejambe	778mm	806mm	830mm	853mm
Stack	627mm	627mm	633mm	648mm
Reach	390mm	418mm	443mm	462mm
Angle de direction	68°	68°	68°	68°
Longueur bases	430mm	430mm	430mm	430mm
Longueur manivelles	170mm	175mm	175mm	175mm
Largeur de cintre	750mm	750mm	750mm	750mm
Longueur de potence	70mm	70mm	90mm	90mm
