Men's S-Works Diverge
CADRE
S-Works FACT 11r carbon, Open Road Geometry, 12x142mm thru-axle, Future Shock Progressive suspension, 20mm of travel, flat-mount disc
FOURCHE
S-Works FACT carbon, flat-mount disc, 12x100mm thru-axle
POTENCE
S-Works SL, alloy, titanium bolts, 6-degree rise
GUIDOLINE
S-Wrap Roubaix w/ sticky gel
SELLE
Body Geometry S-Works Phenom, carbon rails, 143mm
TIGE DE SELLE
Command Post XCP, 27.2mm, 35mm of travel
GUIDON
Easton EC70 AX Carbon Adventure Bar, 16-degree flare
COLLIER DE TIGE DE SELLE
Diverge collar for carbon frames
FREIN AVANT
Shimano Dura-Ace, hydraulic disc
FREIN ARRIÈRE
Shimano Dura-Ace, hydraulic disc
MANETTES DE DÉRAILLEURS
Shimano Dura-Ace Di2 Disc R9170
DÉRAILLEUR ARRIÈRE
Shimano XTR M9050 Di2, Shadow Plus, GS cage, 11-speed
CASSETTE
Shimano XTR, 11-speed, 11-40t
PÉDALIER
Easton EC90 SL Carbon
PLATEAUX
40T
JEU DE PÉDALIER
CeramicSpeed 386 EVO
CHAÎNE
Shimano Dura-Ace, 11-speed
ROUE AVANT
Roval CLX 32 Disc, Win Tunnel Engineered, carbon rim, 32mm depth, Roval AFD hub, CeramicSpeed bearings, 21h
ROUE ARRIÈRE
Roval CLX 32 Disc, Win Tunnel Engineered, carbon rim, 32mm depth, Roval AFD hub, CeramicSpeed bearings, 24h
PNEU AVANT
Sawtooth 2Bliss Ready, 700x38mm
PNEU ARRIÈRE
Sawtooth 2Bliss Ready, 700x38mm
CHAMBRES À AIR
Presta valve, 48mm
PÉDALES
Nylon, 105x78x28mm, loose ball w/reflectors
* Les poids sont basés sur les cadres peints en production comme illustré. Les poids réels varieront en fonction de la couleur, de la taille du cadre et de la variation des composants. Les spécifications sont sujet à changement sans préavis.
48 | 52 | 54 | 56 | 58 | 61 | |
---|---|---|---|---|---|---|
Crank Length | 170mm | 170mm | 172.5mm | 172.5mm | 175mm | 175mm |
Handlebar Width | 400mm | 420mm | 420mm | 420mm | 440mm | 440mm |
Stem Length | 80mm | 90mm | 100mm | 100mm | 110mm | 110mm |
Saddle Width | 143mm | 143mm | 143mm | 143mm | 143mm | 143mm |
Seatpost Length | 350mm | 350mm | 400mm | 400mm | 400mm | 400mm |
Stack | 569mm | 574mm | 592mm | 613mm | 639mm | 662mm |
Reach | 360mm | 367mm | 373mm | 379mm | 385mm | 392mm |
Head Tube Length | 90mm | 95mm | 108mm | 128mm | 155mm | 178mm |
Head Tube Angle | 70.8° | 71° | 71.9° | 72.5° | 72.5° | 72.8° |
BB Height | 265mm | 265mm | 265mm | 265mm | 265mm | 265mm |
BB Drop | 85mm | 85mm | 85mm | 85mm | 85mm | 85mm |
Trail | 64mm | 62mm | 62mm | 58mm | 58mm | 56mm |
Fork Length, Full | 390mm | 390mm | 390mm | 390mm | 390mm | 390mm |
Fork Rake/Offset | 55mm | 55mm | 50mm | 50mm | 50mm | 50mm |
Front Center | 593mm | 599mm | 597mm | 604mm | 618mm | 629mm |
Chainstay Length | 419mm | 419mm | 421mm | 421mm | 421mm | 421mm |
Wheelbase | 997mm | 1004mm | 1004mm | 1011mm | 1025mm | 1036mm |
Top Tube Length, Horizontal | 524mm | 532mm | 549mm | 561mm | 575mm | 589mm |
Bike Standover Height | 704mm | 726mm | 752mm | 776mm | 801mm | 815mm |
Seat Tube Length | 405mm | 440mm | 473mm | 500mm | 525mm | 555mm |
Seat Tube Angle | 74° | 74° | 73.5° | 73.5° | 73.5° | 73.5° |
