Les vrais vélos de trail à grosse suspension sont cools... Jusqu'au moment d'attaquer une montée. Le Camber Expert Carbon 29, lui, est équipé de grandes roues qui vous permettront de grimper avec un maximum d'efficacité. Et vous aurez toujours un débattement largement suffisant pour déchirer la descente. Pour ce faire, nous avons associé notre cadre Trail tout carbone FACT 9m à un arrière de Camber FSR en aluminium M5. Ce choix technique crée le mélange idéal de réactivité, légèreté et durabilité. Aux deux extrémités du vélo, vous trouverez des débattements suffisants pour offrir un confort de suspension généreux, sans exagérer en matière de capacité d'absorption. Cela signifie que vous n'aurez pas à sacrifier le rendement, le poids ou la vitesse pure pour rouler à votre guise. Notre géométrie Trail 29" et notre pivot concentrique léger et rigide à l'arrière vous le garantissent aussi. Pour répondre aux besoins de rangement du matériel essentiel à la pratique trail, nous avons équipé le Camber de notre système SWAT Door intégré au tube diagonal. Vous pourrez y loger en sécurité tout le matériel indispensable, à l'endroit où il faut, c.-à-d. sur le vélo. Pour l'équipement, nous avons choisi des composants comme une transmission monoplateau RAM GX Eagle avec pédalier Truvativ Descendant, de puissants freins SRAM Level TL, une fourche FOX 34 et un amortisseur arrière FOX FLOAT spécifique. Au total, un vélo qui sait faire tout, et rapidement.
- FACT 9m carbon Trail Chassis w/ Camber FSR M5 alloy rear end is mated with our Trail 29 Geometry to form a bike that's just as at home on the climbs as it is mowing over rough trail sections. You'll also find internal cable routing for clean lines and minimal maintenance and an integrated SWAT™ Door for zero-hassle storage of your trail essentials.
- FACT 9m carbon Trail Chassis w/ Camber FSR M5 alloy rear end is mated with our Trail 29 Geometry to form a bike that's just as at home on the climbs as it is mowing over rough trail sections. You'll also find internal cable routing for clean lines and minimal maintenance and an integrated SWAT™ Door for zero-hassle storage of your trail essentials.
- FOX 34 Performance Elite 29 fork features 34mm aluminum stanchions that are equal parts strong and stiff, 120mm of plush, trail-taming travel, and three-position lever adjust that lets you customize the suspension on-the-fly for any trail condition.
- FOX 34 Performance Elite 29 fork features 34mm aluminum stanchions that are equal parts strong and stiff, 120mm of plush, trail-taming travel, and three-position lever adjust that lets you customize the suspension on-the-fly for any trail condition.
- A SRAM GX Eagle shifting controls a wide range of gears with reliable precision.
- A SRAM GX Eagle shifting controls a wide range of gears with reliable precision.
Téléchargements manuels
Spécifications techniques
DRIVETRAIN
| CHAIN | SRAM GX Eagle, 12-speed w/ PowerLock® |
| BOTTOM BRACKET | SRAM PF30 |
| CRANKSET | Truvativ Descendant, alloy, 175/170mm crankarm, 30mm spindle |
| SHIFT LEVERS | SRAM GX Eagle, trigger, 12-speed |
| CASSETTE | SRAM GX Eagle, 12-speed, 10-50t |
| CHAINRINGS | Steel, 30T |
| REAR DERAILLEUR | SRAM GX Eagle, 12-speed |
SUSPENSION
| FORK | FOX 34 Performance 29, air spring, 3-position lever adjust, tapered steerer, 15x100mm thru-axle, 51mm offset, 120mm travel |
| REAR SHOCK | FOX FLOAT Performance, Rx Trail Tune, AUTOSAG, DPS damper, rebound and 3-position compression adjust, 205x53mm |
WHEELS
| FRONT HUB | Specialized, sealed cartridge bearings,15x100mm thru-axle, 24h |
| REAR HUB | Specialized, sealed cartridge bearings, 12x148mm thru-axle, 28h |
| INNER TUBES | Standard, Presta valve |
| SPOKES | DT Swiss Industry, stainless, 3-cross, 2.0" |
| RIMS | Roval Traverse Carbon 29, hookless carbon, 30mm inner width, 24/28h, tubeless ready, hand-built |
| FRONT TIRE | Purgatory, GRIPTON compound, 2Bliss Ready, 29 x 2.3" |
| REAR TIRE | Ground Control, Gripton compound, 2Bliss Ready, 29 x 2.3" |
COCKPIT
| SADDLE | Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm |
| SEATPOST | Command Post IRcc, 12-position micro-height adjustable, alien head design, bottom mount cable routing, remote SRL lever, 30.9mm, S: 100mm, M/L/XL: 125mm of travel |
| STEM | Specialized Trail, 3D-forged alloy, 4-bolt, 6-degree rise |
| HANDLEBARS | Specialized Trail, 7050 alloy, 8-degree backsweep, 6-degree upsweep, 25mm rise, 750mm width, 31.8mm clamp |
| GRIPS | Specialized Sip Grip, half-waffle, S/M: regular thickness, L/XL: XL thickness |
BRAKES
| FRONT BRAKE | SRAM Level TL disc lever/caliper, organic pads, 200/180mm rotors |
| REAR BRAKE | SRAM Level TL disc lever/caliper, organic pads, 180/160mm rotors |
ACCESSORIES
| PEDALS | Specialized Platform, Cr-Mo, 9/16" spindle |
FRAMESET
| SEAT BINDER | Alloy, 34.9mm |
| FRAME | FACT 9m carbon front chassis w/ Specialized M5 Aluminum rear end, 29 Trail Geometry, SWAT™ Door integration, PF30 BB, fully enclosed internal cable routing, Concentric Pivot link, 12x142mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 120mm of travel |
* Les caractéristiques sont sujettes à changements sans préavis.
Géométries
Camber - Géométries
| S | M | L | XL | |
|---|---|---|---|---|
| Crank Length | 170mm | 175mm | 175mm | 175mm |
| Stem Length | 60mm | 60mm | 75mm | 90mm |
| Seatpost Length | 390mm | 430mm | 430mm | 430mm |
| Saddle Width | 143mm | 143mm | 143mm | 143mm |
| Handlebar Width | 750mm | 750mm | 750mm | 750mm |
| Reach | 399mm | 427mm | 445mm | 471mm |
| Top Tube Length, Horizontal | 562mm | 590mm | 613mm | 647mm |
| Stack | 609mm | 609mm | 627mm | 655mm |
| Wheelbase | 1107mm | 1135mm | 1160mm | 1197mm |
| Chainstay Length | 437mm | 437mm | 437mm | 437mm |
| Front Center | 673mm | 701mm | 726mm | 763mm |
| BB Drop | 42mm | 42mm | 42mm | 42mm |
| BB Height | 330mm | 330mm | 330mm | 330mm |
| Seat Tube Angle | 75° | 75° | 75° | 75° |
| Head Tube Angle | 68.5° | 68.5° | 68.5° | 68.5° |
| Seat Tube Length | 396mm | 430mm | 468mm | 523mm |
| Head Tube Length | 115mm | 145mm | 95mm | 95mm |
| Bike Standover Height | 732mm | 735mm | 752mm | 766mm |
| Fork Rake/Offset | 46mm | 46mm | 46mm | 46mm |
| Fork Length, Full | 531mm | 531mm | 531mm | 531mm |
| Trail | 97mm | 97mm | 97mm | 97mm |
