2020 Fuse 27.5

$1,599.00

0 Avis

Here's proof you don't need tons of suspension travel to tackle challenging trails.…

Couleur:

Satin Sage Green/Black

Quelle est ma taille ?

Impériale

Métrique

Entrez vos mensurations et nous calculerons votre taille idéale.

Hauteur:

Pour un résultat plus précis, inclure la longueur de votre tibia.

Sélectionnez un(e) Taille

Caractéristiques du produit

Here's proof you don't need tons of suspension travel to tackle challenging trails. Equipped with an all-new, longer, lower and rowdier chassis, we've added 27.5x2.8 wheels and tires to the Fuse 27.5 to create a bike that lets you hit rocks and roots at speed with absolute control.

ROWDY BY DESIGN

The Fuse is loaded with smart touches. The wide-diameter down tube boosts stiffness. The low-slung top tube improves maneuverabilty on tight trails. And while this Fuse's 27.5x2.8 tires give it tons of traction and stability.

PERFECTLY DIALED

Fail to nail the geometry and advanced designs will still amount to nothing on the trail. Fuse gets it right. The long reach gives you even weight distribution. The slack head angle lends confidence on sketchy descents. The steep seat angle makes quick work of steep climbs.

SMART PARTS PICK

• Plus-size tires provide insane traction and stability on the choppiest trails.

• 130-millimeters of suspension courtesy of a RockShox Judy Silver TK fork.

• Highlights include hydraulic disc brakes, a dropper post, and single-ring drivetrain.

Spécifications techniques

FRAMESET

FRAME

Specialized A1 Aluminum, 148mm thru-axle, tapered head tube, internal cable routing

SEAT BINDER

Alloy, 38.6mm

SUSPENSION

FORK

RockShox Judy Silver TK, air spring, 42mm offset, 130mm of travel

COCKPIT

STEM

Stout 3D-forged alloy, 31.8mm, 6-degree rise

HANDLEBARS

Stout Riser, double-butted alloy, 9-degree backsweep, 5-degree upsweep, 15mm rise, 750mm / 780mm width, 31.8mm

GRIPS

Specialized Trail Grips

SADDLE

Body Geometry Bridge Saddle, steel rails

SEATPOST

TranzX Dropper, 30.9mm, XS-S: 100mm, M-XL: 120mm

BRAKES

REAR BRAKE

Tektro HD-M275, hydraulic disc, 160mm

FRONT BRAKE

Tektro HD-M275, hydraulic disc, 180/160mm

DRIVETRAIN

REAR DERAILLEUR

Shimano Deore, Shadow Plus, GS cage, 10-speed

SHIFT LEVERS

Shimano Deore, 10-speed

CASSETTE

SunRace, 11-42t, 10-speed

CHAIN

KMC X10, 10-speed w/ reusable Missing Link™

CRANKSET

Stout, forged alloy, 76mm BCD

CHAINRINGS

30T

BOTTOM BRACKET

Square taper, 73mm, internal bearings

WHEELS

RIMS

Stout Trail 27.5, 38mm internal width, disc-specific

FRONT HUB

Stout, alloy, sealed cartridge bearings, 15x110mm thru-axle, 24h

REAR HUB

Specialized, sealed cartridge bearings, 12x148mm thru-axle, 32h

SPOKES

Stainless, 14g

FRONT TIRE

Butcher GRID TRAIL, GRIPTON® compound, 2Bliss Ready, 27.5x2.8"

REAR TIRE

Slaughter GRID TRAIL, GRIPTON® compound, 2Bliss Ready, 27.5x2.8"

INNER TUBES

Presta, 40mm valve

* Les poids sont basés sur les cadres peints en production comme illustré. Les poids réels varieront en fonction de la couleur, de la taille du cadre et de la variation des composants. Les spécifications sont sujet à changement sans préavis.

Géométries

	XS	S	M	L	XL
Crank Length	170	170	170	170	175
Handlebar Width	750MM	750MM	780MM	780MM	780MM
Stem Length	45	45	45	45	45
Saddle Width	155mm	143mm	143mm	143mm	143mm
Seatpost Length	360	360	400	400	400
Seat-Tube Angle	74°	74°	74°	74°	74°
Head-Tube Length	105mm	105mm	105mm	120mm	135mm
Head-Tube Angle	66°	66°	66°	66°	66°
Chain-Stay Length	430mm	430mm	430mm	430mm	430mm
Front-Center	695mm	715mm	735mm	761mm	787mm
B-B Drop	48mm	48mm	48mm	48mm	48mm
B-B Height	315mm	315mm	315mm	315mm	315mm
Bike Stand-Over Height	717mm	736mm	739mm	744mm	789mm
Fork Length (full)	520mm	520mm	520mm	520mm	520mm
Top-Tube Length (horizontal)	573mm	593mm	613mm	637mm	661mm
Seat-Tube Length	340mm	375mm	410mm	455mm	505mm
Stack	603mm	603mm	603mm	615mm	630mm
Reach	400mm	420mm	440mm	460mm	480mm
Trail	113mm	113mm	113mm	113mm	113mm
Fork Rake/Offset	42mm	42mm	42mm	42mm	42mm
Wheelbase	1120mm	1140mm	1160mm	1186mm	1213mm
