2015 Status I
0 Omdömen
The 200mm-travel Status I downhill bike features FSR suspension, plus a custom X-Fusion…
Färg:
BRUSHED/ROCKET RED
Vad är min storlek?
Välj en Storlek
Ej tillgänglig
Artikeln är inte tillgänglig för ”Hitta nära mig”
Produktinformation
The 200mm-travel Status I downhill bike features FSR suspension, plus a custom X-Fusion Vector R shock and 180mm-travel X-Fusion Vengeance fork.
World Cup-proven Specialized Butcher tread w/ SX casing
The custom color—Rocket Red—is designed to naturally age over time. It will exhibit splashes of a dark rich color when exposed to prolonged direct sunlight. This finish is deliberate and therefore not covered under the traditional warranty policy.
M4 alloy FSR frame w/ 200mm travel and full-cartridge bearings to handle gnarly downhill terrain
Specialized Demo low-rise handlebar for navigating technical descents
Avid DB3 hydraulic disc brakes w/ metallic pads and custom reach adjustment for complete control
Truvativ Ruktion crankset w/ Status guide for reliable pedaling performance on DH terrain
SRAM X7 rear derailleur for reliable and pinpoint shifts
X-Fusion Vengeance 170mm-travel fork provides plush performance through technical terrain
Custom X-Fusion Vector R coil shock for total control on rough terrain
P.Disc wide rims are engineered for going big
Tekniska specifikationer
FRAMESET
FRAME
M4 hydroformed tubing, 1.5"" forged headtube, ISCG mounts, 135mm rear spacing, full-cartridge bearing pivots, 200mm travel
HEADSET
Semi-integrated alloy cups for 1-1/2"" headtube and 1-1/8"" steerer, cartridge bearings
SEAT BINDER
Specialized 7050 alloy, single bolt, 34.9mm
SUSPENSION
REAR SHOCK
Custom X-Fusion Vector R, coil over w/ piggy back, rebound adj., 8.75x2.75"", spring rate XS: 350, S: 400, M: 450, L: 500
FORK
X-Fusion Vengeance R, coil spring, tapered alloy steerer, rebound adj., 20mm thru-axle, 170mm travel
WHEELS
FRONT HUB
Specialized Hi Lo disc, sealed cartridge bearings, 20mm thru-axle, 36h
REAR HUB
Specialized disc, bolt-on, 36h
SPOKES
Stainless, 14g
DRIVETRAIN
REAR DERAILLEUR
SRAM X7, 9-speed, short cage
SHIFT LEVERS
SRAM X4, 9-speed, trigger
CASSETTE
SRAM PG 830, 8-speed, 11-32
CRANKSET
Truvativ Ruktion, 165mm, 34T, w/ Status guide
BOTTOM BRACKET
Truvativ Howitzer XR, oversize sealed outboard cartridge bearings, 73mm
COCKPIT
SEATPOST
Specialized 6061 alloy, 2-bolt, 0mm setback, 30.9mm
STEM
SRAM Hussefelt, 1-1/8 steerer clamp
HANDLEBARS
Specialized Demo, low rise, 6061 alloy, 9-degree backsweep, 6-degree upsweep, 31.8mm
GRIPS
Specialized Sip Grip, light lock-on, half-waffle, S/M: regular thickness, Others: XL
SADDLE
Specialized DH, 8mm steel rails
BRAKES
FRONT BRAKE
Avid DB3, hydraulic disc, steel-backed metallic pads, 200mm Centerline rotor
REAR BRAKE
Avid DB3, hydraulic disc, steel-backed metallic pads, 180mm Centerline rotor
BRAKE LEVERS
Avid DB3, w/ reach adjust
ACCESSORIES
PEDALS
Alloy platform, 9/16""
*Vikter baserade på produktion av målade ramar som avbildas. Faktiska vikter kommer att variera beroende på färgsättning, ramstorlek och komponentvariation. Specifikationer kan ändras utan förvarning.
Geometri
| GROM | XS | S | M | L | |
|---|---|---|---|---|---|
| Seat Tube Length, Center to Top | 394mm | 394mm | 394mm | 419mm | 458mm |
| Top Tube Length, Actual | 510mm | 510mm | 531mm | 553mm | 574mm |
| Bottom Bracket Drop | -14.5mm | -14.5mm | -14.5mm | -14.5mm | -14.5mm |
| Bottom Bracket Height | 306mm | 355mm | 355mm | 355mm | 355mm |
| Seat Tube Angle, Actual | 71° | 71° | 71° | 71° | 71° |
| Seat Tube Angle, Effective | 75° | 75° | 75° | 75° | 75° |
| Wheel Base | 1164mm | 1164mm | 1164mm | 1189mm | 1214mm |
| Standover Height | 697mm | 746mm | 746mm | 743mm | 759mm |
| Stack | 646mm | 646mm | 646mm | 646mm | 646mm |
| Reach | 375mm | 375mm | 420mm | 425mm | 450mm |
| Head Tube Length | 120mm | 120mm | 120mm | 120mm | 120mm |
| Head Tube Angle | 64.5° | 64.5° | 64.5° | 64.5° | 64.5° |
| Front Center | 739mm | 739mm | 739mm | 764mm | 789mm |
| Chainstay Length | 426mm | 426mm | 426mm | 426mm | 426mm |
| Top Tube Length, Horizontal | 533mm | 533mm | 558mm | 583mm | 608mm |
| Crank Length | 165mm | 165mm | 165mm | 165mm | 165mm |
| Handlebar Width | 720mm | 780mm | 780mm | 780mm | 780mm |
| Stem Length | 40mm | 45mm | 45mm | 45mm | 45mm |
| Seatpost Length | 300mm | 300mm | 300mm | 300mm | 300mm |
Ladda ner användarmanualer
Säkerhetsvarningar finns tillgängliga i dokumentationen i avsnittet ”Ladda ner användarmanualer” på den här sidan.
