2009 Era HT HT Rim
0 レビュー
STILL LEAVING ITS COMPETITION IN THE DUST after decades in production, the Stumpjumper®…
カラー:
Silver/Blue
私にぴったりなサイズは？
サイズを選ぶ
製品の詳細
STILL LEAVING ITS COMPETITION IN THE DUST after decades in production, the Stumpjumper® Hardtail makes no apologies for being the leanest, lightest (some models are under 20 lbs.) and most precision hardtail on the market. Tradition works.
日本国内取り扱いサイズ：13.5,15.5"
日本国内取り扱いサイズ：13.5,15.5"
Era M5アロイハードテールフレーム、Designs for Womenジオメトリーデザイン、フルマニピュレーテッド女性専用OREダウンチューブ、トップチューブ、シートステー、チェーンステー、シートチューブ（Mono-stay シートステー）、ディスクマウント、交換式ディレーラーハンガー
技術仕様
FRAMESET
FRAME
Era M5 Manipulated Alloy hardtail, Designs for Women geometry, fully manipulated Women's specific DT, TT, SS, CS, ST w/ Mono-stay seatstays, ORE DT/TT, disc mount, replaceable derailleur hanger
HEADSET
1-1/8"" Threadless, 10mm insertion alloy cups, sealed cartridge bearing
SEAT BINDER
7050 hard annodized alloy collar w/ bolt, 34.9mm clamp ID, black
WHEELS
FRONT TIRE
S-Works Fast Trak LK, 26x2.0"", 120 TPI, tubeless ready aramid bead, dual compound
REAR TIRE
S-Works Fast Trak LK, 26x2.0"", 120 TPI, tubeless ready aramid bead, dual compound
INNER TUBES
Specialized Ultralight 26x2.0"", presta
RIMS
Mavic X317 w/ eyelets, 28/32h
FRONT HUB
Specialized Hi Lo disc, CNC flange, sealed cartridge bearing, 9mm DT RWS, alloy QR, 28h
REAR HUB
Custom Shimano M525 SL, alloy QR, 32h
SPOKES
DT Swiss 1.8mm stainless, black, alloy nipples
SUSPENSION
FORK
Fox Float F90 RL, 90mm travel, air spring, compression and rebound adj. w/ LO, alloy steerer
DRIVETRAIN
FRONT DERAILLEUR
Shimano M660 SLX, DMD, 34.9mm clamp, top swing, dual pull
REAR DERAILLEUR
Shimano RD-M772 XT Shadow, 9 speed, long cage
SHIFT LEVERS
Shimano Sl-M660 SLX, trigger
CASSETTE
Shimano HG61, 9-speed, 11-34t
CHAIN
SRAM PC-971, 9-speed w/Power Link
CRANKSET
Custom Shimano FC-M542, S/M: 170mm, L: 175mm
CHAINRINGS
22S x 32A x 44A, 4-bolt, 104/64mm
BOTTOM BRACKET
Shimano FC-M542
COCKPIT
STEM
Specialized adjustable rise, 31.8mm clamp, 3D forged w/ CNC finish
HANDLEBARS
Specialized XC flat 31.8mm bar, 2014 butted alloy, 8 degree backsweep, 600mm wide
GRIPS
Specialized thin lock on grip
SADDLE
Specialized Women's Ariel, hollow Cr-Mo rails, 143mm
SEATPOST
2014 butted alloy, single-bolt setback, S/M: 350, L/XL: 400mm
BRAKES
FRONT BRAKE
Avid SD-3R, linear pull, cartridge pads, lightweight compressionless housing
REAR BRAKE
Avid SD-3R, linear pull, cartridge pads, lightweight compressionless housing
BRAKE LEVERS
Avid FR-5, alloy, two-finger, linear pull
ACCESSORIES
PEDALS
Shimano M520, clipless
* 重量は、写真のように塗装されたフレームの生産に基づいています。実際の重量は、カラーウェイ、フレームサイズ、コンポーネントのバリエーションにより異なります。仕様は予告なしに変更されることがあります。
ジオメトリー
| 13.5 | 15.5 | 17 | 18 | |
|---|---|---|---|---|
| Bottom Bracket Height - Low Setting | 304mm | 304mm | 304mm | 304mm |
| Top Tube Length (Horizontal) | 530mm | 550mm | 570mm | 595mm |
| Head Tube Height | 100mm | 100mm | 110mm | 120mm |
| Head Tube Angle - Low Setting | 70.5° | 70.5° | 71° | 71° |
| Seat Tube Angle (Actual) - Low Setting | 73.5° | 73.5° | 73° | 73° |
| Top Tube Length (Actual) | 528mm | 535mm | 547mm | 571mm |
| Seat Tube Length - Center to Top | 343mm | 394mm | 432mm | 457mm |
| Wheel Base | 1014mm | 1034mm | 1043mm | 1069mm |
| Standover Height | 650mm | 683mm | 758mm | 775mm |
| Chainstay Length | 424mm | 424mm | 424mm | 424mm |
| Crank Length | 170mm | 170mm | 170mm | 175mm |
| Handlebar Width | 600mm | 600mm | 600mm | 600mm |
| Stem Length | 75mm | 75mm | 90mm | 90mm |
| Seatpost Length | 350mm | 350mm | 350mm | 350mm |
