Vita Step Thru
Part No.

Vita Step Thru

Part No.  23661
load-spinner
Vita Step Thru
Overview
Technical Specifications
Geometry
Reviews
The Vita is for women riders who want the comfort and convenience of a flat bar with the quickness and efficiency of a road bike. Step-through frame design adds confidence.
  • Straight blade steel fork gives you all the durability you need to manage potholes and rough roads
  • Shimano Altus rear derailleur and Acera Rapidfire trigger shifters are a confidence-inspiring combination
  • Women's Body Geometry Comfort gel grips alleviate hand pain and tingling fingers for all-day riding comfort
  • Body Geometry Riva Road women's saddle combines lightweight hollow Cr-Mo rails and generous padding for all-day performance and comfort
  • Lightweight women's A1 Premium Aluminum double butted frame with step-thru design for easy on and off, enough tire clearance for fenders

Technical Specifications

DRIVETRAIN
CHAIN KMC Z-7, 12"" x 3/32""
BOTTOM BRACKET Sealed cartridge, square taper, 68mm
CRANKSET Shimano FCM131
FRONT DERAILLEUR Shimano, dual pull, top swing
SHIFT LEVERS Shimano EF-51, EZ Fire
CASSETTE SRAM, 7-speed, 12-32t
CHAINRINGS 48 x 38 x 28T w/ chainguard
REAR DERAILLEUR Shimano Altus
WHEELS
FRONT HUB Forged alloy, sealed, QR, 32h
REAR HUB Forged alloy, double-sealed, cassette, QR, 32h
INNER TUBES Standard presta valve
SPOKES Stainless 14g
FRONT TIRE Specialized All Condition Sport, 700x32c, wire bead, 60TPI w/ Flak Jacket protection
RIMS Alex AS-14, double wall
REAR TIRE Specialized All Condition Sport, 700x32c, wire bead, 60TPI w/ Flak Jacket protection
COCKPIT
SADDLE Body Geometry Women's Riva Road, 155mm width
TAPE Body Geometry Women's Comfort Grip
SEATPOST Alloy, two-bolt clamp, 30.9mm
STEM Alloy, CP bolt, 25.4mm
HANDLEBARS Alloy, small rise, 25.4mm
BRAKES
FRONT BRAKE Die cast aluminum, 108mm linear pull
BRAKE LEVERS Shimano EF-51 integrated w/ shifter
REAR BRAKE Die cast aluminum, 108mm linear pull
ACCESSORIES
PEDALS Nylon flat pedal w/ reflectors
FRAMESET
HEADSET 1-1/8"" sealed Cr-Mo bearings integrated w/ headset, 20mm alloy cone spacer with 20mm of spacers
SEAT BINDER Alloy, 31.8mm
FORK Straight blade steel fork w/ Fender and rack eyelets
FRAME Specialized A1 Premium aluminum, fully manipulated tubing, women's fitness geometry, hourglass Seatstays, integrated headset, fender and rack eyelets

Geometry

Geometry Chart

Vita - Geometry

S M L
  S M L
Stem Length 80mm 80mm 100mm
Crank Length 170mm 170mm 170mm
Handle-Bar Width 580mm 580mm 580mm
Wheelbase 1033mm 1049mm 1055mm
Seat-Tube Length, B-B Center to Top 385mm 440mm 485mm
Head-Tube Length 150mm 175mm 200mm
Top-Tube Length, Horizontal 515mm 540mm 555mm
Front-Center 605mm 615mm 619mm
Head-Tube Angle 69° 70.5° 71°
Fork Rake 51mm 51mm 51mm
Trail 79mm 69mm 66mm
Stand-Over Height 642mm 635mm 631mm
Chain-Stay Length 445mm 445mm 445mm
Seat-Tube Angle 76° 75° 74°
B-B Drop 78mm 74mm 70mm
Seat-Post Length 300mm 300mm 350mm
