There’s no other e-bike out there with ride quality, range, and power like this,…
There’s no other e-bike out there with ride quality, range, and power like this, at a weight that’s light enough to carry. The Turbo Vado SL 4.0 EQ is best for your daily commute, quick errands and getting around town. Extra-bright, built-in lights in front and back mean you’ll see and be seen. DRYTECH fenders keep water and road spray away, and a standard rear rack is always ready for your bags and panniers. This is your go-to for local transportation.
Saddle
Bridge Sport, Steel rails, 155mm
SeatPost
Specialized, alloy, dual-bolt, 25mm offset, 27.2mm
Stem
Specialized Stealth Stem, alloy, 14 deg, 31.8mm, integrated TCD mount
Tape
Specialized Body Geometry Contour, lock-on
Handlebars
Specialized, alloy, 9-degree backsweep, 15mm rise, 31.8mm
Rear Derailleur
Shimano Deore, Shadow Plus, GS cage, 10-speed
Shift Levers
Shimano Deore, RapidFire Plus, 10-speed w/ Optical Gear Display
Cassette
Shimano Deore, 10spd, 11-42t
Chain
KMC e10S, 10-speed w/ Missing Link™
Crankset
Praxis, Forged alloy M30, custom offset
Chainrings
Praxis, 44T, 104BCD
Rims
700C disc, 22mm rim depth, 21mm internal width
Front Hub
Specialized alloy front hub disc, sealed cartridge bearings, 12x110mm, Center Lock™, 24h
Rear Hub
Specialized alloy rear hub disc, Center Lock™, sealed cartridge bearings, 12x148mm, 28h
Spokes
DT Swiss Industry
Front Tire
Nimbus II Sport Reflect, 700x38mm
Rear Tire
Nimbus II Sport Reflect, 700x38mm
Motor
Specialized SL 1.1, custom lightweight motor
UI/Remote
Specialized TCU, 10-LED State of charge, 3-LED Ride Mode display, ANT+/Bluetooth®, w/Handlebar remote
Battery
Specialized SL1-320, fully integrated, 320Wh
Charger
Custom charger, 48V System w/ SL system charger plug
Wiring Harness
Custom Specialized wiring harness w/ chargeport
Headlight
Lezyne Ebike Hecto STVZO E65, 210Lumens, 12V
Taillight
Lezyne Ebike Rear Fender STVZO, 11Lumens, 12V
Kickstand
Specialized kickstand, 40mm mount
Rack
Turbo SL Rack, Closed Platform, direct fender mount, Racktime-compatible, 15kg
Fenders
Specialized DryTech, Aluminum
Bell
Simple bell
Pedals
Specialized Commuter w/ grip tape & reflectors
Fork
Rigid full aluminum disc, Boost™ 12x110mm, front- rack-compatible
Seat Binder
Integrated w/ frame
Rear Brake
Tektro HD-R290, hydraulic disc, 160mm
Front Brake
Tektro HD-R290, hydraulic disc, 160mm
Inner Tubes
Standard 40mm PV 700x32-50
SWAT
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
S | M | L | XL | |
---|---|---|---|---|
Crank Length | 170mm | 172.5mm | 172.5mm | 175mm |
Seatpost Length | 350mm | 350mm | 350mm | 350mm |
Handlebar Width | 680mm | 680mm | 680mm | 680mm |
Stem Length | 60mm | 75mm | 75mm | 90mm |
Saddle Width | 155mm | 155mm | 155mm | 155mm |
Stack | 595mm | 626mm | 660mm | 696mm |
Reach | 378mm | 401mm | 415mm | 424mm |
Head-Tube Length | 185mm | 217mm | 250mm | 285mm |
Head-Tube Angle | 70° | 70.5° | 71° | 71.5° |
B-B Height | 270mm | 270mm | 270mm | 270mm |
B-B Drop | 70mm | 70mm | 70mm | 70mm |
Trail | 71mm | 67mm | 64mm | 61mm |
Fork Length (full) | 390mm | 390mm | 390mm | 390mm |
Fork Rake/Offset | 50mm | 50mm | 50mm | 50mm |
Front-Center | 626mm | 655mm | 675mm | 690mm |
Chain-Stay Length | 445mm | 445mm | 445mm | 445mm |
Wheelbase | 1062mm | 1091mm | 1110mm | 1126mm |
Top-Tube Length (horizontal) | 554mm | 587mm | 610mm | 630mm |
Bike Stand-Over Height | 770mm | 790mm | 815mm | 840mm |
Seat-Tube Length | 415mm | 446.5mm | 494.5mm | 535mm |
Seat-Tube Angle | 73.5° | 73.5° | 73.5° | 73.5° |
