SO FAST IT WINS WORLD IRONMAN CHAMPIONSHIPS and carries Pro Tour riders to some of their fastest TT finishes, the FACT carbon Transition is every rider's unfair advantage.
  • The Transition Expert’s FACT carbon frame features our N’Aero tube shaping in a compact aero design.
  • The Specialized FACT N’Aero carbon monocoque fork is stiff, quick, and precise.
  • The Vision Tech aero handlebar puts you in the perfect position for the long-haul tri miles.
  • The Specialized integrated brake system maintains an aero profile while still providing sure stops.
  • The Body Geometry TriTip saddle features a thickly padded nose for comfort on those long miles.
  • The Transition Carbon seatpost is perfectly shaped to cheat the wind.

Technical Specifications

FRAMESET
SEAT BINDER Transition alloy
HEADSET Specialized Mindset Plus, 1"" integrated threadless, sealed cartridge bearings w/ two 10mm and two 5mm carbon spacers
FORK Specialized FACT N'Aero carbon, monocoque construction, 1"" steerer
FRAME Specialized FACT 7r N'Aero tube shaping, triple monocoque construction, compact aero geometry, vertical seat adjustment
WHEELS
FRONT HUB Roval Fusee Star, forged and CNC hub body, Roval Ti QR
REAR HUB Roval Fusee Star, forged and CNC hub body, alloy cassette, Roval Ti QR
INNER TUBES Specialized standard presta tube
SPOKES Stainless steel, bladed
RIMS Roval Fusee Star, E5
FRONT TIRE Specialized Mondo Pro, 700x21C, aramid bead, 120TPI
REAR TIRE Specialized Mondo Pro, 700x21C, aramid bead, 120TPI
DRIVETRAIN
BOTTOM BRACKET Shimano FC-4500
CHAIN Shimano Ultegra, 10-speed
CRANKSET Shimano Ultegra SL
CASSETTE Shimano 105, 10-speed 11-25t
SHIFT LEVERS Shimano Dura-Ace, 10-speed bar end shifters
FRONT DERAILLEUR Shimano Ultegra SL, braze-on clamp
CHAINRINGS 53 x 39t
REAR DERAILLEUR Shimano Dura-Ace, short cage
COCKPIT
SADDLE Body Geometry TriTip, super light foam, carbon reinforced base, hollow Ti rails, microfiber cover, 50mm nose width
TAPE Body Geometry cork ribbon
SEATPOST Specialized Transition carbon, 2 position
HANDLEBARS Vision Tech aluminum Transition aero bar
STEM Specialized Pro-Set, 3D forged alloy, 4-bolt 31.8mm bar clamp, 4-position adjustable
BRAKES
BRAKE LEVERS Vision Tech aero levers
FRONT BRAKE Specialized integrated brake system
REAR BRAKE Specialized integrated brake system
ACCESSORIES
PEDALS Silver cage, black body, w/ toe clip and strap

Geometry

Geometry Chart

Transition - Geometry

  SM MD LG XL
Saddle Setback (Min) 43mm 43mm 43mm 43mm
Handle-Bar Width 350mm 350mm 350mm 350mm
Wheelbase 400mm 400mm 420mm 420mm
BB Drop 50mm 50mm 50mm 50mm
Head-Tube Length 170mm 172.5mm 175mm 175mm
BB to top of Head-Tube, Horizontal 395mm 395mm 395mm 395mm
BB to top of Head-Tube, Vertical -100mm -100mm -100mm -100mm
Front-Center 100mm 110mm 120mm 120mm
Seat-Tube Length, B-B Center to Top vertical 72mm 72mm 72mm 72mm
Head-Tube Angle 575° 589° 602° 621°
Fork Rake 961mm 975mm 988mm 1007mm
Trail 761mm 763mm 768mm 787mm
Stand-Over Height 75mm 75mm 90mm 100mm
Chain-Stay Length 71.5mm 72mm 72mm 72.5mm
Saddle Setback (Max) 68mm 65mm 65mm 62mm
