Tarmac Pro SL Compact Dura Ace
Part No.

Tarmac Pro SL Compact Dura Ace

Part No.  22993
Tarmac Pro SL Compact Dura Ace
Overview
Technical Specifications
Geometry
Reviews
Back To Top
Leading our pros to victory at races like Liège-Bastogne-Liège, Tour of Flanders, and countless others, the Tarmac® proves itself to be the best handling, most high-performance bike on the road. Thanks to the integration of critical components, an extremely rigid FACT carbon frame, and proprietary Body Geometry extras, we can proudly say that nothing is lighter and stiffer.
  • FACT carbon Pave seatpost uses a Zertz insert to minimize road vibrations for greater comfort
  • Adjustable 4-position, 3D-forged alloy stem with 31.8mm bar clamp for strength and versatile positioning
  • S-Works SL ergonomic carbon handlebars for superior fit, comfort, stiffness and strength at minimal weight
  • FACT full carbon monocoque fork integrates with the frame using an oversized race to deliver enhanced steering precision
  • Shimano Dura Ace hollow-forged crankset combines aerodynamic design, light weight and high rigidity for optimal power transfer
  • Advanced FACT IS 10r carbon frame is light, fast and powerful, with a 1.5" lower headset bearing for extra stiffness and Pro Tour performance
  • Body Geometry Toupe saddle features a carbon reinforced shell and hollow titanium rails for balanced stiffness and compliance on longer rides

Technical Specifications

Technical Specifications

DRIVETRAIN
CHAIN Shimano Ultegra
BOTTOM BRACKET BB cups
CRANKSET Shimano Hollowtech II
FRONT DERAILLEUR Shimano Ultegra
SHIFT LEVERS Shimano Dura-Ace STI, flight deck compatible
CASSETTE Shimano Ultegra, 10-speed, 11-28t
CHAINRINGS 50 x 34T
REAR DERAILLEUR Shimano Dura-Ace
WHEELS
REAR WHEEL Mavic Kysrium Elite
INNER TUBES Standard presta valve
FRONT TIRE SW Mondo 700x23c, Aramid bead, 127TPI , w/ Flak Jacket protection
REAR TIRE SW Mondo 700x23c, Aramid bead, 127TPI , w/ Flak Jacket protection
FRONT WHEEL Mavic Kysrium Elite
COCKPIT
SADDLE Body Geometry Toupe w/ hollow Ti rails
TAPE Specialized Pro D2
SEATPOST Specialized FACT carbon w/ Zertz insert, 27.2mm
STEM Specialized Pro-Set, 3D forged 7050 aluminum, 4-position adjustable, 4-bolt 31.8mm clamp
HANDLEBARS S-Works SL Ergo Carbon
BRAKES
FRONT BRAKE Shimano Ultegra
BRAKE LEVERS Shimano Dura-Ace STI, flight deck compatible
REAR BRAKE Shimano Ultegra
ACCESSORIES
PEDALS Silver cage/black body, w/ black toe clips and strap
FRAMESET
HEADSET Aheadset Stainless Race Steel Balls w/ top cap w/ 20mm of spacers
SEAT BINDER Alloy, 32.6mm clamp
FORK Tarmac full FACT carbon monocoque, OS race for 1.5"" bearing
FRAME Specialized Tarmac SL FACT 10r carbon, FACT IS construction, compact race design, 1.5"" lower HS bearing
* Specifications are subject to change without notice

Geometry

Geometry Chart

Tarmac - Geometry

  49 52 54 56 58 61
Stem Length 75mm 90mm 100mm 100mm 110mm 120mm
Crank Length 170mm 170mm 172.5mm 172.5mm 175mm 175mm
Handle-Bar Width 400mm 420mm 420mm 420mm 440mm 440mm
Wheelbase 941mm 961mm 973mm 988mm 1008mm 1030mm
Seat-Tube Length, B-B Center to Top 460mm 490mm 510mm 530mm 550mm 580mm
Head-Tube Length 100mm 120mm 145mm 170mm 205mm 230mm
Top-Tube Length, Horizontal 518mm 537mm 548mm 565mm 582mm 600mm
Front-Center 576mm 576mm 583mm 591mm 605mm 613mm
Head-Tube Angle 72.25° 73° 73° 73.5° 73.5° 74°
Fork Rake 45mm 45mm 45mm 43mm 43mm 43mm
Trail 62mm 57mm 57mm 56mm 56mm 53mm
Stand-Over Height 730mm 755mm 777mm 800mm 828mm 857mm
Chain-Stay Length 405mm 405mm 405mm 405mm 407mm 410mm
Seat-Tube Angle 75.5° 74° 73.5° 73.25° 73° 72.5°
B-B Drop 71.5mm 71.5mm 69mm 69mm 67.5mm 67.5mm
Seat-Post Length 300mm 350mm 350mm 350mm 350mm 350mm
