Tarmac Comp Compact Ultegra
$3,100.00
Part No.

Tarmac Comp Compact Ultegra

$3,100.00
Part No.  33595
load-spinner
Tarmac Comp Compact Ultegra
Overview
Technical Specifications
Geometry
Reviews
Shimano Ultegra 10-speed components keep shifting butter smooth and laser accurate.
  • New FACT IS 8r carbon SL2 frame with tapered head tube and elliptical seatstays is race-ready stiff and fast without sacrificing compliance
  • The FACT carbon fork is light, stiff and compliant with a tapered steerer and 12K weave construction
  • Adjustable 4-position oversized alloy stem with 31.8mm bar clamp for strength and versatile positioning
  • Specialized Ergo aluminum handlebar is stiff, tough and light for serious performance
  • FACT carbon Pave seatpost uses a Zertz insert to minimize road vibrations for greater comfort but remains stiff and efficient
  • Shimano Ultegra 10-speed shifters are lightweight, and laser-accurate for high-performance use

Technical Specifications

DRIVETRAIN
CHAIN Shimano Ultegra
BOTTOM BRACKET With crankset
CRANKSET Shimano Ultegra
FRONT DERAILLEUR Shimano Ultegra
SHIFT LEVERS Shimano Ultegra STI, flight deck compatible
CASSETTE Shimano 105, 10-speed, 11-28t
CHAINRINGS 50 x 34T
REAR DERAILLEUR Shimano Ultegra
WHEELS
REAR WHEEL Fulcrum Racing 6
INNER TUBES Standard presta valve
FRONT TIRE Specialized Turbo Comp, 700x23c, aramid bead, 120TPI, w/ Double Black Belt protection
REAR TIRE Specialized Turbo Comp, 700x23c, aramid bead, 120TPI, w/ Double Black Belt protection
FRONT WHEEL Fulcrum Racing 6
COCKPIT
SADDLE Body Geometry Romin Comp w/ hollow Cr-Mo rails
TAPE Specialized S-Wrap, w/ gel
SEATPOST Specialized Pro, FACT carbon w/ Zertz insert
STEM Specialized Comp-Set, 3D forged alloy, 4-position adjustable, 4-bolt 31.8mm clamp
HANDLEBARS Specialized Ergo 2014 alloy
BRAKES
FRONT BRAKE Shimano Ultegra
BRAKE LEVERS Shimano Ultegra STI, flight deck compatible
REAR BRAKE Shimano Ultegra
ACCESSORIES
PEDALS Black cage, body & toe clips w/ strap
FRAMESET
HEADSET 1-1/8"" upper and 1-1/5"" lower Cr-Mo cartridge bearings integrated w/ headset, 20mm cone spacer with 20mm of spacers
SEAT BINDER Forged alloy, 32.6mm
FORK Specialized FACT carbon full monocoque, OS race for 1-1/2"" bearing
FRAME Specialized FACT 8r carbon, FACT IS construction, compact race design, 1-1/2"" lower HS bearing, threaded BB

Geometry

Geometry Chart

Tarmac - Geometry

  49 52 54 56 58 61
Stem Length 75mm 90mm 100mm 100mm 110mm 120mm
Crank Length 170mm 170mm 172.5mm 172.5mm 175mm 175mm
Handle-Bar Width 400mm 420mm 420mm 420mm 440mm 440mm
Wheelbase 970mm 970mm 978mm 986mm 1003mm 1013mm
Seat-Tube Length, B-B Center to Top 460mm 490mm 510mm 530mm 550mm 580mm
Head-Tube Length 100mm 120mm 145mm 170mm 205mm 230mm
Top-Tube Length, Horizontal 518mm 537mm 548mm 565mm 582mm 600mm
Front-Center 576mm 576mm 583mm 591mm 605mm 612mm
Head-Tube Angle 72.25° 73° 73° 73.5° 73.5° 74°
Fork Rake 45mm 45mm 45mm 43mm 43mm 43mm
Trail 62mm 57mm 57mm 56mm 56mm 53mm
Stand-Over Height 730mm 755mm 777mm 800mm 828mm 857mm
Chain-Stay Length 405mm 405mm 405mm 405mm 407mm 410mm
Seat-Tube Angle 75.5° 74° 73.5° 73.25° 73° 72.5°
B-B Drop 71.5mm 71.5mm 69mm 69mm 67.5mm 67.5mm
Seat-Post Length 300mm 350mm 350mm 350mm 350mm 350mm
