enStumpjumper ST - Geometry
Geometry
| S | M | L | XL | |
|---|---|---|---|---|
| Crank Length | 170mm | 170mm | 170mm | 170mm |
| Stem Length | 50mm | 50mm | 50mm | 50mm |
| Seatpost Length | 406mm | 456mm | 456mm | 456mm |
| Saddle Width | 155mm | 143mm | 143mm | 143mm |
| Handlebar Width | 780mm | 780mm | 780mm | 780mm |
| Reach | 405mm | 425mm | 445mm | 470mm |
| Top Tube Length, Horizontal | 573mm | 597mm | 628mm | 662mm |
| Stack | 619mm | 619mm | 642mm | 656mm |
| Wheelbase | 1151mm | 1171mm | 1201mm | 1232mm |
| Chainstay Length | 437mm | 437mm | 437mm | 437mm |
| Front Center | 716mm | 736mm | 766mm | 797mm |
| BB Drop | 33mm | 33mm | 33mm | 33mm |
| BB Height | 341mm | 341mm | 341mm | 341mm |
| Seat Tube Angle | 74.8° | 74.5° | 74.1° | 73.7° |
| Head Tube Angle | 66.5° | 66.5° | 66.5° | 66.5° |
| Seat Tube Length | 380mm | 410mm | 455mm | 505mm |
| Head Tube Length | 100mm | 100mm | 125mm | 140mm |
| Bike Standover Height | 756mm | 762mm | 775mm | 776mm |
| Fork Rake/Offset | 51mm | 51mm | 51mm | 51mm |
| Fork Length, Full | 560mm | 560mm | 560mm | 560mm |
| Trail | 107mm | 107mm | 107mm | 107mm |
