Stumpjumper M5 29er Frame
Part No.

Stumpjumper M5 29er Frame

Part No.  23671
Stumpjumper M5 29er Frame
Technical Specifications
M5 advances alloy technology to its highest level. Build your fast and efficient 29er from scratch.
  • Thomson Elite Setback alloy post is super strong and light for worry-free bombing up or down the trails
  • 29er HT frame with curved top tube looks as fast and sweet as it rides due to its race-optimized 29" geometry and M5 manipulated alloy construction

Technical Specifications

SEATPOST Thomson Elite Setback w/ 12 degree clamp, 15.5/17.5"": 367mm, others:410mm
HEADSET 1-1/8"" upper and lower campy style cartridge bearings for integrated alloy HT
SEAT BINDER 34.9mm clamp ID, 7050 hard annodized alloy collar w/ QR, black
FRAME M5 manipulated alloy frame, 29"" geometry, curved TT


Geometry Chart

Stumpjumper - Geometry

  15.5 17.5 19 21
Stem Length 75mm 90mm 105mm 105mm
Crank Length 170mm 175mm 175mm 175mm
Seatpost Length 350mm 350mm 400mm 400mm
Handlebar Width 660mm 660mm 660mm 660mm
Reach 380mm 409mm 428mm 447mm
Stack 574mm 592mm 611mm 630mm
Chainstay Length 424mm 424mm 424mm 424mm
Top Tube Length (Actual) 538mm 567mm 590mm 614mm
Ground-Top 878mm 896mm 915mm 934mm
Top Tube Length (Horizontal) 555mm 590mm 615mm 640mm
Head Tube Angle - Low Setting 70.5° 70.5° 70.5° 70.5°
Standover Height 741mm 780mm 811mm 846mm
Wheel Base 1034mm 1070mm 1096mm 1122mm
Head Tube Height 120mm 140mm 160mm 180mm
Seat Tube Angle (Actual) - Low Setting 73° 73° 73° 73°
Seat Tube Length - Center to Top 394mm 445mm 483mm 533mm
Bottom Bracket Height - Low Setting 304mm 304mm 304mm 304mm
