Stumpjumper Elite Carbon World Cup
$4,200.00
Part No.

Stumpjumper Elite Carbon World Cup

$4,200.00
Part No.  93296
load-spinner
Stumpjumper Elite Carbon World Cup
Overview
Technical Specifications
Geometry
Reviews
The Stumpjumper Elite Carbon World Cup is a purpose-built cross-country race machine with a 1X10 drivetrain and 90mm-travel fork.
  • The custom color—Rocket Red—is designed to naturally age over time. It will exhibit splashes of a dark rich color when exposed to prolonged direct sunlight. This finish is deliberate and therefore not covered under the traditional warranty policy.
  • Lightweight and compliant Specialized alloy seatpost
  • SRAM X1, 11-speed rear derailleur for premium shifting performance
  • Roval Control 29 wheelset w/ 142+ spacing for greater control
  • FACT 9m carbon frame w/ World Cup Geometry and PF30 BB for efficient XC performance
  • SRAM X1 11-speed, PF30 crankset for optimal power and efficiency
  • RockShox SID 29 fork w/ Brain damping and 90mm travel for race-ready XC performance
  • Fast-rolling, 2Bliss Ready S-Works Fast Trak tires

Technical Specifications

FRAMESET
SWAT Bottle cage w/ SWAT Technology
SEAT BINDER Alloy, 31.8mm
HEADSET 1-1/8 and 1-1/2"" threadless, Campy style upper with 1-1/2"" lower, cartridge bearings
FRAME FACT 9m carbon, 29"" geometry, FACT IS construction, tapered headtube, carbon PF30 BB, full internal shift/brake routing, 142mm dropouts, PM 160 rear brake, replaceable alloy rear derailleur hanger
WHEELS
FRONT HUB Roval Control 29, 15mm thru-axle, 32h
REAR HUB Roval Control 29 142+, XX1 driver body, DT Swiss internals
SPOKES DT Swiss Revolution
RIMS Roval Control 29, alloy, 21mm inner width, 32h
FRONT TIRE S-Works Fast Trak Control, 120TPI, 2Bliss Ready, folding bead, 29x2.0""
REAR TIRE Specialized Fast Trak Control, 60TPI, 2Bliss Ready, folding bead, 29x2.0""
DRIVETRAIN
BOTTOM BRACKET SRAM, PF30, OS press-in bearings, sealed cartridge
CRANKSET SRAM X1 1000, X SYNC ring, PF30, 32T, 94mm BCD spider
CASSETTE SRAM XG 1180, 11-speed, 10-42
SHIFT LEVERS SRAM X1, 11-speed, trigger
REAR DERAILLEUR SRAM X1, 11-speed, alloy cage
COCKPIT
SADDLE Body Geometry Phenom Comp, hollow Cr-Mo rails, 143mm
SEATPOST Specialized alloy, single bolt, 27.2mm
GRIPS Specialized Sip Grip, light lock-on, half-waffle, S/M: regular thickness, Others: XL
HANDLEBARS Specialized flat, 8-degree backsweep, 31.8mm
STEM Specialized, forged alloy, 6-degree rise
BRAKES
BRAKE LEVERS Magura MTS, alloy lever
FRONT BRAKE Magura MTS, hydraulic disc, Hi Friction pad, alloy master cylinder, alloy caliper, Storm SL rotor, S/M: 180mm rotor, Others: 160mm
REAR BRAKE Magura MTS, hydraulic disc, Hi Friction pad, alloy master cylinder, alloy caliper, 160mm Storm SL rotor
ACCESSORIES
PEDALS Resin test ride, w/ toe clips, CEN std.
SUSPENSION
FORK RockShox SID 29 Brain, Solo Air spring, tapered alloy steerer, bottom-mount BrainFade, rebound adjust, 15mm thru-axle, S: 80mm travel, Others: 90mm

Geometry

Geometry Chart

Stumpjumper - Geometry

S M L XL
  S M L XL
Stem Length 75mm 90mm 105mm 105mm
Crank Length 170mm 175mm 175mm 175mm
Handlebar Width 700mm 700mm 700mm 700mm
Seat Tube Angle (Effective) 73.5° 73.5° 73.5° 73.5°
Reach 390mm 414mm 437mm 458mm
Stack 592mm 610mm 625mm 639mm
Chainstay Length 430mm 430mm 430mm 430mm
Bottom Bracket Drop 61mm 61mm 61mm 61mm
Head Tube Angle 71° 71° 71° 71°
Top Tube Length (Actual) 551mm 574mm 598mm 622mm
Ground-Top 902mm 920mm 935mm 949mm
Top Tube Length (Horizontal) 565mm 593mm 620mm 643mm
Standover Height 760mm 799mm 826mm 849mm
Wheel Base 1047mm 1078mm 1105mm 1131mm
Head Tube Height 90mm 100mm 115mm 130mm
B-B Height 0mm 0mm 0mm 0mm
Seat Tube Length - Center to Top 394mm 434mm 470mm 505mm
Bottom Bracket Height 310mm 310mm 310mm 310mm
