Sirrus Comp Carbon
Overview
Technical Specifications
Geometry
Reviews
A completely redesigned FACT 8r frame along with a 2X10 drivetrain inspires Sirrus Comp Carbon riders to achieve all their riding goals and push themselves to increase their speed and fitness.
  • Specialized FACT 8r carbon frame with Zertz provides a lightweight, compliant ride for maximum speed and comfort
  • FACT carbon fork with Zertz for responsive road feel and forgiving ride, with fender mounts and wide clearance for added versatility
  • FSA Gossamer compact alloy crankset with 50/34 configuration for lightweight, wide-range gearing
  • Adjustable, 4-position, oversized forged alloy stem with 31.8mm bar clamp for strength and versatile positioning
  • Body Geometry Targa gel grips lock on and help alleviate hand pain and tingling fingers, integrated bar ends for changing hand position included
  • Specialized Body Geometry Targa Sport saddle has front/rear bumpers for durability and ample padding for comfort

Technical Specifications

DRIVETRAIN
CHAIN KMC X10
BOTTOM BRACKET FSA, sealed bearings
CRANKSET FSA Gossamer, forged alloy, 10-speed
FRONT DERAILLEUR Shimano Tiagra
SHIFT LEVERS Shimano Tiagra
CASSETTE Shimano HG-62, 10-speed, 11-32
CHAINRINGS 50/34
REAR DERAILLEUR Shimano Tiagra, 10-speed
WHEELS
REAR WHEEL AXIS 1.0 Disc
INNER TUBES Standard presta valve
FRONT TIRE Specialized Espoir Sport, 60TPI, wire bead, double BlackBelt protection, 700x28c
REAR TIRE Specialized Espoir Sport, 60TPI, wire bead, double BlackBelt protection, 700x28c
FRONT WHEEL AXIS 1.0 Disc
COCKPIT
SADDLE Body Geometry Targa Sport, steel rails, 155mm
TAPE Specialized Body Geometry Targa, lock-on w/ integrated bar end
SEATPOST Alloy, 2-bolt, 12.5mm offset, 27.2mm
STEM Specialized Elite-Set, 3D forged alloy, 4-position adjustable, 4-bolt, 31.8mm clamp
HANDLEBARS Specialized flat bar, double-butted alloy, 10-degree backsweep, 31.8mm
BRAKES
FRONT BRAKE Tektro Draco 2, hydraulic disc, 160mm rotor
BRAKE LEVERS Tektro Draco 2, hydraulic lever
REAR BRAKE Tektro Draco 2, hydraulic disc, 160mm rotor
ACCESSORIES
PEDALS Sirrus, 1.5mm Varus angle, nylon body, symmetric alloy cage, low profile bearing system, toe clip capable
FRAMESET
HEADSET 1-1/8"" FSA Campy style, integrated cartridge, 15mm alloy cone spacer
SEAT BINDER Alloy, 31.8mm
FORK Specialized FACT carbon, aluminum steerer
FRAME Specialized FACT 8r carbon disc, 1-1/8"" head tube, threaded BB

Geometry

Geometry Chart

- Geometry

S M L XL
  S M L XL
Crank Length 0mm 0mm 0mm 0mm
Stem Length 0mm 0mm 0mm 0mm
Handle-Bar Width 0mm 0mm 0mm 0mm
Reach 379mm 380mm 387mm 392mm
Stack 546mm 563mm 589mm 621mm
Wheelbase 989mm 1000mm 1010mm 1029mm
Seat-Tube Length, B-B Center to Top 475mm 495mm 515mm 540mm
Head-Tube Length 145mm 165mm 190mm 225mm
Fork Length 367 367 367 367
Top-Tube Length, Horizontal 537mm 548mm 565mm 582mm
Front-Center 588mm 595mm 606mm 621mm
Head-Tube Angle 72° 72° 72.5° 72.5°
Stand-Over Height 756mm 776mm 798mm 829mm
Fork Rake 49mm 49mm 49mm 49mm
Trail 59mm 59mm 56mm 56mm
Chain-Stay Length 412mm 415mm 415mm 418mm
Seat-Tube Angle 74° 73.5° 73.25° 73°
B-B Drop 73mm 71.5mm 71.5mm 70mm
Seat-Post Length 0mm 0mm 0mm 0mm
