Sirrus Comp Carbon
$1,750.00
Part No.

Sirrus Comp Carbon

$1,750.00
Part No.  50731
load-spinner
Sirrus Comp Carbon
Overview
Technical Specifications
Geometry
Reviews
A completely redesigned FACT 8r frame along with a 2X10 drivetrain inspires Sirrus Comp Carbon riders to achieve all their riding goals and push themselves to increase their speed and fitness.
  • Specialized FACT 8r carbon frame with Zertz provides a lightweight, compliant ride for maximum speed and comfort
  • FACT carbon fork with Zertz for responsive road feel and forgiving ride, with fender mounts and wide clearance for added versatility
  • FSA Gossamer compact alloy crankset with 50/34 configuration for lightweight, wide-range gearing
  • Adjustable, 4-position, oversized forged alloy stem with 31.8mm bar clamp for strength and versatile positioning
  • Body Geometry Targa gel grips lock on and help alleviate hand pain and tingling fingers, integrated bar ends for changing hand position included
  • Specialized Body Geometry Targa Sport saddle has front/rear bumpers for durability and ample padding for comfort

Technical Specifications

FRAMESET
SEAT BINDER Alloy, 31.8mm
HEADSET 1-1/8"" FSA Campy style, integrated cartridge, 15mm alloy cone spacer
FORK Specialized FACT carbon, aluminum steerer
FRAME Specialized FACT 8r carbon disc, 1-1/8"" head tube, threaded BB
WHEELS
REAR WHEEL AXIS 1.0 Disc
INNER TUBES Standard presta valve
FRONT TIRE Specialized Espoir Sport, 60TPI, wire bead, double BlackBelt protection, 700x28c
REAR TIRE Specialized Espoir Sport, 60TPI, wire bead, double BlackBelt protection, 700x28c
FRONT WHEEL AXIS 1.0 Disc
DRIVETRAIN
BOTTOM BRACKET FSA, sealed bearings
CHAIN KMC X10
CRANKSET FSA Gossamer, forged alloy, 10-speed
CASSETTE Shimano HG-62, 10-speed, 11-32
SHIFT LEVERS Shimano Tiagra
FRONT DERAILLEUR Shimano Tiagra
CHAINRINGS 50/34
REAR DERAILLEUR Shimano Tiagra, 10-speed
COCKPIT
SADDLE Body Geometry Targa Sport, steel rails, 155mm
TAPE Specialized Body Geometry Targa, lock-on w/ integrated bar end
SEATPOST Alloy, 2-bolt, 12.5mm offset, 27.2mm
HANDLEBARS Specialized flat bar, double-butted alloy, 10-degree backsweep, 31.8mm
STEM Specialized Elite-Set, 3D forged alloy, 4-position adjustable, 4-bolt, 31.8mm clamp
BRAKES
BRAKE LEVERS Tektro Draco 2, hydraulic lever
FRONT BRAKE Tektro Draco 2, hydraulic disc, 160mm rotor
REAR BRAKE Tektro Draco 2, hydraulic disc, 160mm rotor
ACCESSORIES
PEDALS Sirrus, 1.5mm Varus angle, nylon body, symmetric alloy cage, low profile bearing system, toe clip capable

Geometry

Geometry Chart

Sirrus - Geometry

  SM MD LG XL
Stem Length 100mm 100mm 110mm 110mm
Crank Length 172.5mm 172.5mm 175mm 175mm
Handle-Bar Width 400mm 400mm 400mm 400mm
Wheelbase 1052mm 1060mm 1070mm 1091mm
Seat-Tube Length, B-B Center to Top 440mm 485mm 530mm 570mm
Head-Tube Length 150mm 165mm 190mm 225mm
Top-Tube Length, Horizontal 570mm 580mm 600mm 620mm
Front-Center 627mm 635mm 645mm 666mm
Head-Tube Angle 71° 71.5° 72° 72°
Fork Rake 51mm 51mm 51mm 51mm
Trail 63mm 60mm 57mm 57mm
Stand-Over Height 741mm 777mm 812mm 850mm
Chain-Stay Length 435mm 435mm 435mm 435mm
Seat-Tube Angle 73.25° 73.5° 73° 73°
B-B Drop 70mm 70mm 70mm 70mm
Seat-Post Length 350mm 350mm 350mm 350mm
