Secteur Triple
Part No.

Secteur Triple

Part No.
Please select an option
Secteur Triple
Technical Specifications
Perfect for a Gran Fondo or epic weekend ride, the Secteur's Endurance Road Geometry, FACT carbon fork with vibration-absorbing Zertz, and shaped tubesets delivers a ride that's stable, smooth, and quick. The 8-speed Shimano triple drivetrain adds efficiency and reliability to any road adventure.
  • Specialized Espoir Sport, 700x25c tires w/ double BlackBelt protection to fight flats
  • Specialized Roubaix bar tape w/ gel pads for shock absorbing comfort
  • Body Geometry Toupé Sport saddle w/ steel rails for all day comfort
  • Shimano Claris, triple crankset w/ wide gear range at a great value
  • Shimano 2400 Claris rear derailleur for clean and crisp shifting
  • A1 Premium Aluminum frame w/ Compliance Plus seatstays is lightweight and efficient
  • Specialized FACT carbon fork w/ Zertz provides predictable steering and smooth handling

Technical Specifications

BOTTOM BRACKET Shimano, Octalink spline
CHAIN KMC Z51, 8-speed
CRANKSET Shimano Claris, 50/39/30
FRONT DERAILLEUR Shimano Claris 2400, braze-on
SHIFT LEVERS Shimano Claris 2400 STI
CASSETTE Sunrace, 8-speed, 11-32
REAR DERAILLEUR Shimano Claris 2400
INNER TUBES Standard, presta valve
FRONT TIRE Specialized Espoir Sport, 60TPI, wire bead, double BlackBelt protection, 700x25c
REAR TIRE Specialized Espoir Sport, 60TPI, wire bead, double BlackBelt protection, 700x25c
SADDLE Body Geometry Toupé Sport, steel rails, 155mm
TAPE Specialized Roubaix, w/ 2.5mm gel pads, bar end plug
SEATPOST Specialized Sport, alloy, 2-bolt, 27.2mm
HANDLEBARS Specialized, shallow drop, alloy, 125mm drop, 70mm short-reach
STEM Specialized 3D forged alloy, 4-bolt, 6-degree rise
FRONT BRAKE Tektro, caliper, dual pivot, long-reach, reach adjust
REAR BRAKE Tektro, caliper, dual pivot, long-reach, reach adjust
PEDALS Nylon flat test ride, loose-ball, w/ reflectors
HEADSET 1-1/8"" integrated sealed Cr-Mo cartridge bearings, 20mm alloy cone spacer, w/ 20mm of spacers
SEAT BINDER Alloy, 31.8mm
FORK Specialized FACT carbon w/ Zertz, alloy steerer/crown
FRAME Specialized A1 Premium Aluminum, Endurance Road Geometry, fully manipulated tubing w/ smooth welds, Compliance Plus seatstays, 1-1/8"" lower bearing


Geometry Chart

Secteur - Geometry

  49 52 54 56 58 61
Crank Length 170mm 170mm 170mm 175mm 175mm 175mm
Stem Length 80mm 90mm 100mm 100mm 110mm 110mm
Handle-Bar Width 400mm 420mm 420mm 420mm 440mm 440mm
Reach 378mm 378mm 380mm 387mm 391mm 398mm
Stack 528mm 547mm 564mm 590mm 622mm 643mm
Wheelbase 983mm 989mm 1000mm 1010mm 1029mm 1038mm
Seat-Tube Length, B-B Center to Top 418mm 447mm 466mm 485mm 510mm 535mm
Head-Tube Length 125mm 145mm 165mm 190mm 225mm 245mm
Top-Tube Length, Horizontal 518mm 537mm 548mm 565mm 582mm 600mm
Front-Center 582mm 588mm 595mm 606mm 621mm 628mm
Head-Tube Angle 72° 72° 72° 72.5° 72.5° 73°
Stand-Over Height 730mm 756mm 776mm 798mm 829mm 851mm
Fork Rake 49mm 49mm 49mm 49mm 49mm 49mm
Trail 59mm 59mm 59mm 56mm 56mm 53mm
Chain-Stay Length 412mm 412mm 415mm 415mm 418mm 420mm
Seat-Tube Angle 75.5° 74° 73.5° 73.25° 73° 72.5°
B-B Drop 73mm 73mm 71.5mm 71.5mm 70mm 70mm
Seat-Post Length 300mm 300mm 350mm 350mm 350mm 350mm
