Secteur Elite Triple
Overview
Technical Specifications
Geometry
Reviews
The Secteur brings the Classics-winning geometry of the Roubaix down to an accessible price point that recreational riders will love. Featuring an all-new, aluminum frame design with an endurance focus, the Secteur puts efficiency, reliability and comfort above all else.
  • Ergonomic short drop aluminum handlebars provide a comfortable riding position
  • Adjustable 4-position stem with 31.8mm bar clamp for strength and versatile positioning
  • The Shimano 105 10-speed STI brake/shift levers give crisp shifts and effortless braking.
  • Smooth, precise Shimano 105 10-speed shifters provide wide-range, lightning-fast gear selection
  • All-new Secteur A1 Premium Aluminum frame is ergonomically designed for maximum comfort over the long haul
  • FACT carbon fork for maximum strength at minimal weight, with Zertz inserts to minimize vibration and has rack/fender fittings

Technical Specifications

DRIVETRAIN
CHAIN KMC DX10 SC
BOTTOM BRACKET With Crankset
CRANKSET Shimano FCR-553
FRONT DERAILLEUR Shimano 105
SHIFT LEVERS Shimano 105 STI, flight deck compatible
CASSETTE Shimano 105, 10-speed, 12-27t
CHAINRINGS 50 x 39 x 30T
REAR DERAILLEUR Shimano 105
WHEELS
FRONT HUB Forged alloy, sealed, 32 hole, for J bend round spokes
REAR HUB Forged alloy, sealed, cassette, QR, 32h
INNER TUBES Standard presta valve
SPOKES Stainless 14g
FRONT TIRE Specialized All Condition Pro II, 700x25c, aramid bead, 120TPI, w/ Flak Jacket protection
RIMS Mavic CXP-22 N, aluminum triple-wall, sleeve joint, CNC machined sidewalls
REAR TIRE Specialized All Condition Pro II, 700x25c, aramid bead, 120TPI, w/ Flak Jacket protection
COCKPIT
SADDLE Body Geometry Avatar Gel w/ hollow Cr-Mo rails
TAPE Specialized S-Wrap, cork ribbon w/ 2.5 gel pads
SEATPOST Carbon wrapped, two-bolt clamp, 27.2mm
STEM Specialized Elite-Set, 3D forged alloy, 4-position adjustable, 4-bolt 31.8mm clamp
HANDLEBARS Specialized Comp Ergo, 6061 alloy
BRAKES
FRONT BRAKE Tektro cold-forged, dual pivot w/ cartridge pads
REAR BRAKE Tektro cold-forged, dual pivot w/ cartridge pads
ACCESSORIES
PEDALS Silver cage/black body, w/ black toe clips and strap
FRAMESET
HEADSET Cage bearings integrated HS. w/ 20mm of spacers w/ top cap
SEAT BINDER Alloy, 31.8mm
FORK Secteur carbon, alloy crown and steerer, rack eyelets w/ Zertz inserts
FRAME Specialized Secteur A1 Premium aluminum, fully manipulated tubing, smooth weld compact design, integrated headset

Geometry

Geometry Chart

- Geometry

  46 49 52 54 56 58 61
Crank Length 170mm 170mm 170mm 172.5mm 172.5mm 175mm 175mm
Stem Length 75mm 75mm 90mm 100mm 100mm 110mm 120mm
Handle-Bar Width 400mm 400mm 420mm 420mm 420mm 440mm 440mm
Wheelbase 980mm 983mm 989mm 1000mm 1010mm 1029mm 1038mm
Seat-Tube Length, B-B Center to Top 410mm 440mm 475mm 495mm 515mm 535mm 565mm
Head-Tube Length 110mm 125mm 145mm 165mm 190mm 225mm 245mm
Top-Tube Length, Horizontal 505mm 518mm 537mm 548mm 565mm 582mm 600mm
Front-Center 579mm 582mm 588mm 595mm 606mm 621mm 628mm
Head-Tube Angle 71° 72° 72° 72° 72.5° 72.5° 73°
Stand-Over Height 713mm 741mm 767mm 786mm 805mm 825mm 852mm
Fork Rake 49mm 49mm 49mm 49mm 49mm 49mm 49mm
Trail 66mm 60mm 60mm 60mm 56mm 56mm 53mm
Chain-Stay Length 412mm 412mm 412mm 415mm 415mm 418mm 420mm
Seat-Tube Angle 76° 75.5° 74° 73.5° 73.25° 73° 72.5°
B-B Drop 73mm 73mm 73mm 71.5mm 71.5mm 70mm 70mm
Seat-Post Length 300mm 300mm 350mm 350mm 350mm 350mm 350mm
