S-Works Venge ViAS Frameset—Sagan Superstar
$4,500.00
Part No.

S-Works Venge ViAS Frameset—Sagan Superstar

$4,500.00
Part No.  134250
load-spinner
S-Works Venge ViAS Frameset—Sagan Superstar
Overview
Technical Specifications
Geometry
Reviews

What happens when you combine a frame with over a thousand hours in the Win Tunnel, a fully integrated cockpit that eliminates exposed cables, mind- blowing braking performance, and a paintjob that pays tribute to multi-time World Champion, Peter Sagan? You get the S-Works Venge ViAS Sagan Superstar edition—the fastest, best looking bike on the road.

In our Win Tunnel, every tube, trailing edge, and design cue was made for speed, translating to a 116-second advantage, compared to the Tarmac SL5, over 40km. It's also Rider-First Engineered™ to ensure that every frame size experiences uniform performance, and front-end stiffness was increased by 30% over the Tarmac.

Of course, this disc iteration changes the game with undeniable stopping power, without any penalty to the aerodynamic profile, so you get powerful, controllable braking without any sacrifices. So when it comes to sprinting to the line, into the corner, or powering through the wind, you won't find anything faster.

  • The Rider-First Engineered™, FACT 11r frame design has made the Venge the stiffest, most aerodynamic bike that we’ve ever created. Every tube shape, trailing edge, and design cue was influenced by hours of testing in our Win Tunnel, computational fluid dynamics, 3D printed prototypes, and real-world rider feedback. And ultimately, this resulted in the fastest bike we’ve ever made.
  • Designed in our Win Tunnel, the fork features a top-end S-Works FACT 11r carbon construction that helps to cut through air like a hot knife through butter.
  • With its FACT carbon construction, the Venge seatpost provides impeccable power transfer and aerodynamic advantage, while still allowing for ample compliance for long days in the saddle.

Technical Specifications

DRIVETRAIN
BOTTOM BRACKET OSBB, CeramicSpeed bearings
COCKPIT
SEATPOST Specialized Venge Aero seatpost, FACT carbon
FRAMESET
SEAT BINDER Specialized Venge assembly
FORK S-Works FACT 11r carbon, full monocoque
FRAME S-Works FACT 11r carbon, Rider-First Engineered™, Win Tunnel Engineered, internal cable routing, 12x142mm thru-axle, carbon OSBB, flat disc mount

Geometry

Geometry Chart

Venge - Geometry

  46 49 52 54 56 58 61
Seatpost Length 330mm 330mm 330mm 380mm 380mm 380mm 380mm
Reach 377mm 386mm 385mm 386mm 395mm 401mm 408mm
Top Tube Length, Horizontal 511mm 518mm 536mm 547mm 565mm 581mm 600mm
Stack 489mm 505mm 526mm 543mm 564mm 591mm 612mm
Wheelbase 974mm 974mm 974mm 981mm 992mm 1006mm 1014mm
Chainstay Length 410mm 410mm 410mm 410mm 410mm 410mm 410mm
Front Center 575mm 575mm 575mm 581mm 592mm 606mm 613mm
BB Drop 73mm 71.5mm 71.5mm 69mm 69mm 68mm 67.5mm
BB Height 267mm 270mm 270mm 272.5mm 272.5mm 274mm 274mm
Seat Tube Angle 75° 75.5° 74° 73.5° 73.25° 73° 72.5°
Head Tube Angle 70° 72.25° 73° 73° 73.5° 73.5° 74°
Seat Tube Length 425mm 441mm 461mm 481mm 501mm 524mm 554mm
Head Tube Length 100mm 110mm 130mm 150mm 170mm 200mm 220mm
Bike Standover Height 692mm 730mm 755mm 775mm 795mm 826mm 850mm
Fork Rake/Offset 44mm 44mm 44mm 44mm 44mm 44mm 44mm
Fork Length, Full 358mm 358mm 358mm 358mm 358mm 358mm 358mm
Trail 73mm 63mm 58mm 58mm 55mm 55mm 52mm
