enTechnical Specifications
E-BIKE
| Wiring Harness | Custom Specialized wiring harness w/ chargeport |
| Charger | Custom charger, 48V System w/ SL system charger plug |
| UI/Remote | Specialized TCU, 10-LED State of charge, 3-LED Ride Mode display, ANT+/Bluetooth®, w/Handlebar remote |
| Battery | Specialized SL1-320, fully integrated, 320Wh |
| Motor | Specialized SL 1.1, custom lightweight motor |
ACCESSORIES
| SWAT | Fender Clamp Adaptor |
FRAMESET
| Fork | Future Shock 2.0 w/ Smooth Boot, Boost™ 12x110mm thru-axle, flat-mount disc |
| Frame | FACT 11r carbon, Open Road Geometry, front/rear thru-axles, fully integrated down tube battery, internal cable routing, fender/rack mounts, Boost™ 12x148mm |
| Seat Binder | Specialized Alloy, 30.8mm |
COCKPIT
| Saddle | S-Works Power, carbon rails, carbon base, synthetic leather |
| Handlebars | S-Works Carbon Hover Drop 125mm, Reach 75mm, w/Di2 hole |
| Tape | Roubaix S-Wrap |
| Stem | S-Works Future Stem w/ Integrated Computer mount |
| SeatPost | S-Works FACT carbon 27.2mm, 20mm offset |
DRIVETRAIN
| Chain | SRAM RED 12-speed |
| Chainrings | 40T |
| Shift Levers | SRAM Red eTap AXS Hydraulic |
| Cassette | Shimano XT, 11-speed, 11-42t |
| Crankset | Praxis, Carbon M30, custom offset |
| Rear Derailleur | Shimano XTR M9050 Di2, Shadow Plus, GS cage, 11-speed |
WHEELS & TIRES
| Rear Tire | S-Works Turbo, 700x28mm |
BRAKES
| Front Brake | Shimano 105, Hydraulic disc |
| Rear Brake | Shimano 105, Hydraulic disc |
WHEELS
| Rear Wheel | Roval CLX 50 Disc, carbon, tubeless-ready, Win Tunnel Engineered, 50mm depth, DT Swiss 240 internals, CeramicSpeed bearings, 24h |
| Front Wheel | Roval CLX 50 Disc, carbon, tubeless-ready, Win Tunnel Engineered, 50mm depth, CeramicSpeed bearings, 21h |
| Front Tire | S-Works Turbo, 700x28mm |
| Inner Tubes | Presta, 60mm valve |
* Specifications are subject to change without notice
Manual Downloads
Turbo Creo - Geometry
Geometry
| S | M | L | XL | XXL | |
|---|---|---|---|---|---|
| Crank Length | 170mm | 172.5mm | 172.5mm | 175mm | 175mm |
| Stem Length | 80mm | 90mm | 100mm | 110mm | 110mm |
| Seatpost Length | 350mm | 350mm | 400mm | 400mm | 400mm |
| Saddle Width | 155mm | 143mm | 143mm | 143mm | 143mm |
| Handlebar Width | 400mm | 420mm | 420mm | 440mm | 440mm |
| Reach | 373mm | 379mm | 384mm | 391mm | 399mm |
| Stack | 575mm | 592mm | 615mm | 643mm | 675mm |
| Wheelbase | 1005mm | 1012mm | 1020mm | 1036mm | 1052mm |
| Bike Stand-Over Height | 731mm | 759mm | 782mm | 810mm | 840mm |
| Head-Tube Length | 145.5mm | 163.5mm | 185.5mm | 217mm | 250mm |
| Front-Center | 592mm | 598mm | 605mm | 621mm | 636mm |
| Fork Rake/Offset | 50mm | 50mm | 50mm | 50mm | 50mm |
| Head-Tube Angle | 72° | 72.5° | 73° | 73° | 73° |
| Trail | 60mm | 56mm | 53mm | 53mm | 52mm |
| B-B Height | 264.5mm | 267mm | 267mm | 269.5mm | 269.5mm |
| Chain-Stay Length | 426mm | 426mm | 427mm | 427mm | 428mm |
| Fork Length (full) | 390mm | 390mm | 390mm | 390mm | 390mm |
| Seat-Tube Angle | 74° | 74° | 73.5° | 73.5° | 73° |
| B-B Drop | 80.5mm | 78mm | 78mm | 75.5mm | 75.5mm |
| Seat-Tube Length | 447.5mm | 477.5mm | 502.5mm | 527.5mm | 557.5mm |
| Top-Tube Length (horizontal) | 539mm | 548mm | 566mm | 581mm | 605mm |
