2021 S-Works Aethos
SRAM Red eTap AXS
5
3 Reviews
For once, we’re not in it to win. With Aethos, we stopped worrying about winning,…
Product Details
For once, we’re not in it to win. With Aethos, we stopped worrying about winning, or the way things are supposed to be done, and instead chased the greatest expression of ride quality ever made. Well, we did it, and in staying true to keeping that promise, we broke every design, ride, and race rule along the way. And we’re not sorry. Aethos: Break the Rules.
Top off the world’s lightest frame with SRAM’s 12-speed RED eTAP AXS groupset and Roval’s featherweight Alpinist wheels and you’re left with a perfectly balanced top-tier ride that delivers everything in the name of performance.
- The Aethos frame has been designed with the perfect combination of ultimate ride feel, light weight, and style—from accelerating up steep pitches and descending technical descents, to all-day saddle comfort on even the longest coffee rides, the Aethos hits the mark. But how, you ask? By reinventing the traditional road shape found on bikes of the past, we’ve subtly altered these shapes to deliver massive gains in stiffness and balance, all without affecting weight or durability. Pair that with an entirely-new layup and process that we’ve perfected over multiple decades and you have the lightest frame out there (585 grams, S-Works, size 56cm). The Aethos is more than just a new bike, it’s the first of a new breed.
- The Aethos frame has been designed with the perfect combination of ultimate ride feel, light weight, and style—from accelerating up steep pitches and descending technical descents, to all-day saddle comfort on even the longest coffee rides, the Aethos hits the mark. But how, you ask? By reinventing the traditional road shape found on bikes of the past, we’ve subtly altered these shapes to deliver massive gains in stiffness and balance, all without affecting weight or durability. Pair that with an entirely-new layup and process that we’ve perfected over multiple decades and you have the lightest frame out there (585 grams, S-Works, size 56cm). The Aethos is more than just a new bike, it’s the first of a new breed.
- A featherweight frame is useless without confidence-inspiring ride characteristics, which is why we’ve developed the Aethos to have the perfect balance of front and rear stiffness combined with exceptional ride quality. By studying the flexing and breathing of carbon fiber, we were able to discover groundbreaking findings about how forces flow through frames. Just a few pedal strokes and you’ll realize this sublime ride sets a new standard.
- A featherweight frame is useless without confidence-inspiring ride characteristics, which is why we’ve developed the Aethos to have the perfect balance of front and rear stiffness combined with exceptional ride quality. By studying the flexing and breathing of carbon fiber, we were able to discover groundbreaking findings about how forces flow through frames. Just a few pedal strokes and you’ll realize this sublime ride sets a new standard.
- Every detail, from the derailleur hangers to the fork expander plug have been designed with style, weight, and durability in mind. We’ve also spec’d it with Roval’s all-new Alpinist carbon seatpost and wheels, further saving weight and improving ride characteristics. Everything in pursuit for the perfect ride.
- Every detail, from the derailleur hangers to the fork expander plug have been designed with style, weight, and durability in mind. We’ve also spec’d it with Roval’s all-new Alpinist carbon seatpost and wheels, further saving weight and improving ride characteristics. Everything in pursuit for the perfect ride.
Technical Specifications
Frameset
Frame
S-Works Aethos FACT 12r Carbon, Rider First Engineered™, Threaded BB, Electronic cable routing only, 12x142mm thru-axle, flat-mount disc
Seat Binder
Specialized Alloy, 30.0mm, titanium bolt
Cockpit
Tape
Supacaz Super Sticky Kush
Stem
S-Works SL, alloy, titanium bolts, 6-degree rise
Handlebars
S-Works Short & Shallow, 125mm Drop, 75mm Reach w/Di2 Hole
Saddle
Body Geometry S-Works Power, carbon fiber rails, carbon fiber base
SeatPost
Roval Alpinist Carbon Seatpost
Suspension
Fork
S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc
Brakes
Front Brake
SRAM RED eTAP AXS, hydraulic disc
Rear Brake
SRAM RED eTAP AXS, hydraulic disc
Drivetrain
Front Derailleur
SRAM RED eTAP AXS, braze-on
Rear Derailleur
SRAM RED eTAP AXS, 12-speed
Cassette
SRAM RED XG-1290, 12-speed, 10-33t
Chain
SRAM CN Red 12-speed
Crankset
SRAM RED AXS Power Meter
Bottom Bracket
SRAM DUB BSA 68
Wheels & Tires
Front Wheel
Roval Alpinist CLX, 21mm internal width carbon rim, 33mm depth, Win Tunnel Engineered, Roval AFD hub, 21h, DT Swiss Aerolite spokes
Rear Wheel
Roval Alpinist CLX, 21mm internal width carbon rim, 33mm depth, Win Tunnel Engineered, Roval AFD hub, 24h, DT Swiss Aerolite spokes
Front Tire
Turbo Cotton, 320 TPI, 700x26mm
Rear Tire
Turbo Cotton, 320 TPI, 700x26mm
Inner Tubes
Turbo Ultralight, 48mm Presta valve
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| 49 | 52 | 54 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|
| Crank Length | 165mm | 170mm | 172.5mm | 172.5mm | 175mm | 175mm |
| Handlebar Width | 380mm | 400mm | 420mm | 420mm | 440mm | 440mm |
| Stem Length | 80mm | 90mm | 100mm | 100mm | 110mm | 110mm |
| Saddle Width | 155mm | 155mm | 143mm | 143mm | 143mm | 143mm |
| Seatpost Length | 300mm | 300mm | 360mm | 360mm | 360mm | 360mm |
| Stack | 514mm | 527mm | 544mm | 565mm | 591mm | 612mm |
| Reach | 375mm | 380mm | 384mm | 395mm | 402mm | 408mm |
| Head Tube Length | 109mm | 120mm | 137mm | 157mm | 184mm | 204mm |
| Head Tube Angle | 71.75° | 72.5° | 73° | 73.5° | 73.5° | 74° |
| BB Height | 266mm | 266mm | 268mm | 268mm | 268mm | 268mm |
| BB Drop | 74mm | 74mm | 72mm | 72mm | 72mm | 72mm |
| Trail | 63mm | 58mm | 58mm | 55mm | 55mm | 52mm |
| Fork Length, Full | 369mm | 369mm | 369mm | 369mm | 369mm | 369mm |
| Fork Rake/Offset | 47mm | 47mm | 44mm | 44mm | 44mm | 44mm |
| Front Center | 574mm | 577mm | 579mm | 591mm | 606mm | 613mm |
| Chainstay Length | 410mm | 410mm | 410mm | 410mm | 410mm | 410mm |
| Wheelbase | 973mm | 975mm | 978mm | 991mm | 1005mm | 1012mm |
| Top Tube Length, Horizontal | 508mm | 531mm | 540mm | 562mm | 577mm | 595mm |
| Bike Standover Height | 705mm | 728mm | 748mm | 769mm | 796mm | 824mm |
| Seat Tube Length | 431mm | 462mm | 481mm | 504mm | 532mm | 567mm |
| Seat Tube Angle | 75.5° | 74° | 74° | 73.5° | 73.5° | 73° |
