S-Works Aethos
SRAM RED AXS
0 Reviews
Don’t get us wrong, we’re all for racing. Grand Tour top steps, Classic’s Monuments—they’re…
We deliver! Just say when and how.
Product Details
Don’t get us wrong, we’re all for racing. Grand Tour top steps, Classic’s Monuments—they’re in our DNA. But sometimes riding simply to ride, riding for the love of riding, is just what we need. And this is what the Aethos lives for. Sure, it’s given nothing up to performance, and happens to be the lightest frame out there, but with no compromise to style. Aethos: Billions of calculations in the pursuit of one thing—the perfect ride.
Top off the world’s lightest frame with a full SRAM RED AXS groupset with power meter - the lightest electronic groupset ever - and Roval’s featherweight Alpinist CLX II wheels and you’re left with a perfectly balanced top-tier ride that gives up nothing in the name of performance.
- The Aethos frame has been designed with the perfect combination of ultimate ride feel, light weight, and style—from accelerating up steep pitches and descending technical descents, to all-day saddle comfort on even the longest coffee rides, the Aethos hits the mark. But how, you ask? By reinventing the traditional road shape found on bikes of the past, we’ve subtly altered these shapes to deliver massive gains in stiffness and balance, all without affecting weight or durability. Pair that with an entirely new layup and process that we’ve perfected over multiple decades and you have the lightest frame out there (585 grams, S-Works, size 56cm). The Aethos is more than just a new bike, it’s the first of a new breed.
- A featherweight frame is useless without confidence-inspiring ride characteristics, which is why we’ve developed the Aethos to have the perfect balance of front and rear stiffness combined with exceptional ride quality. By studying the flexing and breathing of carbon fiber, we were able to discover groundbreaking findings about how forces flow through frames. Just a few pedal strokes and you’ll realize this sublime ride sets a new standard.
- Every detail, from the derailleur hangers to the fork expander plug have been designed with style, weight, and durability in mind. We’ve also spec’d it with Roval’s all-new Alpinist carbon seatpost and wheels, further saving weight and improving ride characteristics. Everything in pursuit for the perfect ride.
Technical Specifications
Frameset
Frame
S-Works Aethos FACT 12r Carbon, Rider First Engineered™, Threaded BB, Electronic cable routing only, 12x142mm thru-axle, flat-mount disc
Suspension
Fork
S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc
Brakes
Front Brake
NEW SRAM RED AXS, hydraulic disc
Rear Brake
NEW SRAM RED AXS, hydraulic disc
Drivetrain
Shift Levers
NEW SRAM RED AXS, 12-speed
Front Derailleur
NEW SRAM RED AXS, braze-on
Rear Derailleur
NEW SRAM RED AXS, 12-speed
Cassette
NEW SRAM RED XG-1290, 12-speed, 10-33t
Chain
NEW SRAM RED 12-speed
Crankset
NEW SRAM RED AXS Power Meter
Chainrings
48/35
Bottom Bracket
SRAM DUB BSA 68
Wheels & Tires
Front Wheel
Roval Alpinist CLX, Tubeless, 21mm internal width carbon rim, 33mm depth, Win Tunnel Engineered, Roval AFD hub, 21h, DT Swiss Aerolite spokes
Rear Wheel
Roval Alpinist CLX, Tubeless, 21mm internal width carbon rim, 33mm depth, Win Tunnel Engineered, Roval AFD hub, 24h, DT Swiss Aerolite spokes
Front Tire
S-works Turbo 2BR, 700x28mm
Rear Tire
S-works Turbo 2BR, 700x28mm
Inner Tubes
700x20-28, 48mm Presta Valve
Cockpit
Tape
Supacaz Super Sticky Kush
Stem
Roval Alpinist, alloy, titanium bolts, 6-degree rise
Handlebars
S-Works Short & Shallow, 125mm Drop, 75mm Reach w/Di2 Hole
Saddle
S-Works Power with Mirror
SeatPost
Roval Alpinist Carbon Seatpost
Seat Binder
Specialized Alloy, 30.0mm, titanium bolt
Product Details
Product ID
221535
Weight
Weight
6.34 kg (13 lb, 15.6 oz)
Weight Size
56
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| 49 | 52 | 54 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|
| Crank Length | 165mm | 170mm | 172.5mm | 172.5mm | 175mm | 175mm |
| Handlebar Width | 380mm | 400mm | 420mm | 420mm | 440mm | 440mm |
| Stem Length | 80mm | 90mm | 100mm | 100mm | 110mm | 110mm |
| Saddle Width | 155mm | 155mm | 143mm | 143mm | 143mm | 143mm |
| Seatpost Length | 300mm | 300mm | 360mm | 360mm | 360mm | 360mm |
| Stack | 514mm | 527mm | 544mm | 565mm | 591mm | 612mm |
| Reach | 375mm | 380mm | 384mm | 395mm | 402mm | 408mm |
| Head Tube Length | 109mm | 120mm | 137mm | 157mm | 184mm | 204mm |
| Head Tube Angle | 71.75° | 72.5° | 73° | 73.5° | 73.5° | 74° |
| BB Height | 266mm | 266mm | 268mm | 268mm | 268mm | 268mm |
| BB Drop | 74mm | 74mm | 72mm | 72mm | 72mm | 72mm |
| Trail | 58mm | 55mm | 55mm | 52mm | 63mm | 58mm |
| Fork Length, Full | 369mm | 369mm | 369mm | 369mm | 369mm | 369mm |
| Fork Rake/Offset | 47mm | 47mm | 44mm | 44mm | 44mm | 44mm |
| Front Center | 574mm | 577mm | 579mm | 591mm | 606mm | 613mm |
| Chainstay Length | 410mm | 410mm | 410mm | 410mm | 410mm | 410mm |
| Wheelbase | 973mm | 975mm | 978mm | 991mm | 1005mm | 1012mm |
| Top Tube Length, Horizontal | 508mm | 531mm | 540mm | 562mm | 577mm | 595mm |
| Bike Standover Height | 705mm | 728mm | 748mm | 769mm | 796mm | 824mm |
| Seat Tube Length | 431mm | 462mm | 481mm | 504mm | 532mm | 567mm |
| Seat Tube Angle | 75.5° | 74° | 74° | 73.5° | 73.5° | 73° |
