Ruby Elite Triple
$2,200.00
Part No.

Ruby Elite Triple

$2,200.00
Part No.  22373
load-spinner
Ruby Elite Triple
Overview
Technical Specifications
Geometry
Reviews
Women's Performance Road Ride like hell! The Ruby is purpose-built for women who demand a ride without compromise. Utilizing the latest in proprietary Specialized FACT carbon composite technology, female cyclists now have every advantage in equipment that had historically been available to the other half of the population. Whether it's the local race circuit or long rides with fast friends, the Ruby is the perfect riding partner.
  • The Ruby Elite frame is constructed of our light and strong FACT 7r carbon, the Designs for Women geometry means it’s ideally suited to a woman’s body, Zertz inserts minimize vibrations for all-day comfort.
  • The Specialized FACT carbon monocoque fork features Zertz inserts to soak up vibrations.
  • The 3D-forged Comp-Set stem has an oversized bar-clamp area for a solid steering connection.
  • The Women’s alloy handlebar features a short-reach drop and ergonomic shaping for maximum comfort.
  • The race-ready Body Geometry Jett Women’s saddle is scientifically proven to reduce pressure on your soft parts.

Technical Specifications

FRAMESET
SEAT BINDER Specialized CNC alloy, 32.6mm
HEADSET Specialized Mindset Plus, 1-1/8"" integrated threadless, sealed cartridge bearings, 20mm alloy cone w/ one 10mm and two 5mm alloy spacers
FORK Specialized FACT carbon, monocoque construction, full carbon legs, crown and steerer w/ Zertz inserts
FRAME Specialized FACT 7r carbon, triple monocoque construction, Designs for Women compact design, Zertz inserts
WHEELS
FRONT HUB Specialized forged alloy, 28h, sealed ball bearings, QR
REAR HUB Specialized forged alloy, 32h, double sealed ball bearings, cassette, QR
INNER TUBES Specialized standard presta tube
SPOKES DT Champion, stainless 14g w/ ProLoc brass nipples
RIMS Mavic CXP22 rim, alloy triple-wall, machined sidewalls, 28/32h w/ eyelets
FRONT TIRE Specialized All Condition Pro, 700x23c, aramid bead, 120TPI w/ Flak Jacket
REAR TIRE Specialized All Condition Pro, 700x23c, aramid bead, 120TPI w/ Flak Jacket
DRIVETRAIN
BOTTOM BRACKET Shimano FC-4500
CHAIN Shimano 105, 10-speed
CRANKSET Shimano Triple
CASSETTE Shimano 105, 10-speed, 12-27t
SHIFT LEVERS Shimano 105, 10-speed STI, flight deck compatible
FRONT DERAILLEUR Shimano 105, 31.8mm clamp, bottom pull
CHAINRINGS 50 x 39 x 30t
REAR DERAILLEUR Shimano 105, long cage
COCKPIT
SADDLE Body Geometry Jett women's saddle, microfiber, gel padding, hollow Cr-Mo rails
TAPE Body Geometry Bar Phat, cork ribbon w/ 4mm gel padding
SEATPOST Specialized Pavé II, FACT carbon w/ Zertz insert, aluminum head, 27.2mm
HANDLEBARS Specialized Womens, 2014 alloy, short-reach drop, ergonomic shaping, 31.8mm
STEM Specialized Comp-Set, 3D forged alloy, 4-bolt 31.8mm bar clamp, 4- position adjustable
BRAKES
BRAKE LEVERS Shimano 105, 10-speed STI, flight deck compatible
FRONT BRAKE Ultralight dual pivot brakes, Teflon pivots, forged alloy w/ cartridge pads
REAR BRAKE Ultralight dual pivot brakes, Teflon pivots, forged alloy w/ cartridge pads
ACCESSORIES
PEDALS Silver cage, black body, w/ toe clip and strap

Geometry

Geometry Chart

Ruby - Geometry

  44 48 51 54 56
Handle-Bar Width 300mm 300mm 350mm 350mm 350mm
Reach 496mm 506mm 518mm 537mm 548mm
Wheelbase 380mm 380mm 400mm 400mm 420mm
Stack 400mm 430mm 450mm 480mm 500mm
Seat-Tube Length, B-B Center to Top 405mm 405mm 405mm 405mm 408mm
Head-Tube Length 165mm 165mm 170mm 170mm 172.5mm
Ground-Top 73mm 73mm 73mm 73mm 71.5mm
Top-Tube Length, Horizontal 76mm 75.75mm 75.5mm 74mm 73.5mm
Front-Center 105mm 115mm 125mm 145mm 165mm
Head-Tube Angle 574° 579° 582° 588° 595°
Fork Rake 967mm 973mm 976mm 982mm 993mm
Trail 693mm 718mm 735mm 758mm 778mm
Stand-Over Height 75mm 75mm 90mm 100mm 100mm
Chain-Stay Length 51mm 51mm 49mm 49mm 49mm
Seat-Tube Angle 66° 62° 59° 59° 59°
B-B Drop 70.5mm 71.25mm 72mm 72mm 72mm
