Roubaix Triple
Part No.

Roubaix Triple

Part No.  22522
Roubaix Triple
Technical Specifications
SERIOUSLY SMOOTH AND SERIOUSLY FAST. When the new Roubaix isn't silencing the cobbles and stealing the podium of races by the same name, it's busy turning your next 100 miles in to the "Big Easy."
  • The FACT 6r carbon, triple-monocoque frame on the Roubaix X3 offers an all-day-long comfortable ride without sacrificing speed or agility, the vibration-absorbing Zertz inserts add an additional layer of comfort.
  • The Specialized FACT carbon monocoque fork is full carbon—legs, crown, steerer—and Zertz inserts soak up the chatter.
  • The4-position-adjustable Specialized Comp-Set stem is easily adjusted to match your needs, the oversized 31.8mm clamp area provides a solid steering interface.
  • The Specialized Pro handlebars feature a short drop and ergonomic shape, for maximum comfort and control.
  • The Body Geometry Avatar saddle features a microfiber cover and gel padding for long-term comfort.

Technical Specifications

CHAIN Shimano 105, 10-speed
BOTTOM BRACKET FSA MegaExo, integrated exterior cartridge bearings, alloy
CRANKSET FSA Gossamer MegaExo, 2-piece crankset
FRONT DERAILLEUR Shimano 105, 31.8mm clamp, bottom pull
SHIFT LEVERS Shimano 105, 10-speed STI, flight deck compatible
CASSETTE Shimano 105, 10-speed, 12-27t
CHAINRINGS 50 x 39 x 30t
REAR DERAILLEUR Shimano 105, long cage
FRONT HUB Specialized forged alloy, 32h, sealed ball bearings, QR
REAR HUB Specialized forged alloy, 32h, double sealed ball bearings, cassette, QR
INNER TUBES Specialized standard presta tube
SPOKES Stainless 14g
FRONT TIRE Specialized Roubaix Pro, 700x23/25c, aramid bead, 120TPI
RIMS Mavic CXP22 rim, alloy triple-wall, machined sidewalls, 32 hole
REAR TIRE Specialized Roubaix Pro, 700x23/25c, aramid bead, 120TPI
SADDLE Body Geometry Avatar, microfiber cover, gel padding, Cr-Mo rails
TAPE Body Geometry Bar Phat, cork ribbon w/ 4mm gel padding
SEATPOST Specialized carbon wrapped, two-bolt clamp, 27.2mm
STEM Specialized Comp-Set, 3D forged alloy, 4-bolt 31.8mm bar clamp, 4- position adjustable
HANDLEBARS Specialized Pro, 2014 alloy, short-drop, ergonomic shaping, 31.8mm
FRONT BRAKE Ultralight dual pivot brakes, Teflon pivots, forged alloy w/ cartridge pads
BRAKE LEVERS Shimano 105, 10-speed STI, flight deck compatible
REAR BRAKE Ultralight dual pivot brakes, Teflon pivots, forged alloy w/ cartridge pads
PEDALS Silver cage, black body, w/ toe clip and strap
HEADSET Specialized Mindset Plus, 1-1/8"" integrated threadless, sealed cartridge bearings, 20mm alloy cone w/ one 10mm and two 5mm alloy spacers
SEAT BINDER Specialized CNC alloy, 32.6mm
FORK Specialized FACT carbon, monocoque construction, full carbon legs, crown and steerer w/ Zertz inserts.
FRAME Specialized FACT 6r carbon, triple monocoque construction, compact race design, Zertz inserts


Geometry Chart

Roubaix - Geometry

  49 54 56 61
Handle-Bar Width 300mm 350mm 350mm 350mm
Reach 518mm 548mm 565mm 600mm
Wheelbase 400mm 420mm 420mm 440mm
Stack 480mm 500mm 520mm 570mm
Seat-Tube Length, B-B Center to Top 412mm 415mm 415mm 418mm
Head-Tube Length 170mm 172.5mm 172.5mm 175mm
Ground-Top 73mm 71.5mm 71.5mm 70mm
Top-Tube Length, Horizontal 75.5mm 73.5mm 73.25mm 73mm
Front-Center 145mm 165mm 190mm 215mm
Head-Tube Angle 582° 595° 606° 621°
Fork Rake 983mm 1000mm 1010mm 1029mm
Trail 737mm 756mm 778mm 824mm
Stand-Over Height 90mm 100mm 100mm 120mm
Chain-Stay Length 49mm 49mm 49mm 49mm
Seat-Tube Angle 59° 59° 56° 53°
B-B Drop 72mm 72mm 72.5mm 73mm
