Roubaix Elite Triple
Part No.

Roubaix Elite Triple

Part No.
load-spinner
Roubaix Elite Triple
Overview
Technical Specifications
Geometry
Reviews
Performance Endurance Road FROM THE SPRING CLASSICS TO YOUR LOCAL CENTURY The Roubaix pioneered the endurance road category and is still the best bike for riding longer and faster.

Inside Tech You can't beat this system. The Roubaix Pro features a proprietary FACT carbon crank and bottom bracket system that, because it was designed as an integrated part of the Roubaix chassis, cuts weight (an amazing 148 grams) while boosting pedaling efficiency.

Useful Links FACT Carbon Manuals/Tech Bulletins

  • Specialized FACT 6r carbon frame, triple monocoque construction, compact design, Zertz inserts
  • Specialized FACT 6r carbon, triple monocoque construction, compact design, Zertz inserts
  • Shimano 105, 10-speed, 31.8mm clamp, bottom pull
  • Specialized FACT monocoque carbon fork, full carbon legs, crown and steerer w/ Zertz inserts
  • Shimano 105, 10-speed, long cage
  • Specialized Comp-Set, 3D forged alloy stem and Specialized Zertz Comp, 6061 alloy bar
  • Mavic Open Sport, double wall rim, machined sidewalls w/ eyelets
  • Shimano 105 10-speed drivetrain
  • Mavic Open Sport, double wall rims with Specialized forged alloy hubs
  • Specialized forged alloy, 24 hole, double sealed ball bearings, straight pull spokes, QR
  • Specialized Roubaix Pro tires
  • Specialized forged alloy, 28 hole, double sealed ball bearings, straight pull spokes, cassette, QR
  • Stainless 14g, straight-pull
  • Specialized Roubaix Pro, 700x23/25c, aramid bead, 120TPI
  • Body Geometry Avatar, microfiber cover, gel padding, Cro-Mo Rails
  • Specialized Pavé FACT carbon w/ Zertz insert, 27.2mm

Technical Specifications

DRIVETRAIN
CHAIN Shimano 105, 10-speed
BOTTOM BRACKET FSA MegaExo, integrated exterior cartridge bearings, alloy
CRANKSET FSA Gossamer MegaExo, 2-piece crankset
FRONT DERAILLEUR Shimano 105, 31.8mm clamp, bottom pull
SHIFT LEVERS Shimano 105, 10-speed STI, flight deck compatible
CHAINRINGS 50x39x30T
REAR DERAILLEUR Shimano 105, long cage
WHEELS
FRONT HUB Specialized forged alloy, 24 hole, double sealed bearings, straight pull spokes, QR
REAR HUB Specialized forged alloy, 28 hole, double sealed bearings, straight pull spokes, cassette, QR
SPOKES Stainless 14g, straight-pull
FRONT TIRE Specialized Roubaix Pro, 700x23/25c, aramid bead, 120TPI, Flak Jacket
RIMS Mavic Open Sport, double wall rim, machined sidewalls w/ eyelets
REAR TIRE Specialized Roubaix Pro, 700x23/25c, aramid bead, 120TPI, Flak Jacket
COCKPIT
SADDLE Specialized Avatar, microfiber cover, gel padding, Cr-Mo Rails
STEM Specialized Comp-Set, 3D forged alloy, 4-bolt 31.8mm bar clamp, 4-position adjustable
HANDLEBARS Specialized Zertz Comp, 6061 alloy, Zertz damper, short-reach drop, ergonomic top shaping, 31.8mm
BRAKES
FRONT BRAKE Ultralight dual pivot brakes, Teflon pivots, forged alloy w/ cartridge pads
BRAKE LEVERS Shimano 105, 10-speed STI, flight deck compatible
REAR BRAKE Ultralight dual pivot brakes, Teflon pivots, forged alloy w/ cartridge pads
ACCESSORIES
PEDALS Composite body test ride pedals
FRAMESET
HEADSET Specialized Mindset Plus, 1 1/8"" integrated threadless, cartridge sealed bearings, alloy 20mm cone w/ one 10mm and two 5mm alloy spacers
SEAT BINDER Specialized CNC, alloy, 32.6mm clamp
FORK Specialized FACT monocoque carbon fork, full carbon legs, crown and steerer w/ Zertz inserts
FRAME Specialized FACT 6r carbon, triple monocoque construction, compact design, Zertz inserts

Geometry

Geometry Chart

- Geometry

  49 52 54 56 58 61
Handle-Bar Width 300mm 350mm 350mm 350mm 350mm 350mm
Reach 518mm 537mm 548mm 565mm 582mm 600mm
Stack 450mm 480mm 500mm 520mm 540mm 570mm
Wheelbase 400mm 400mm 420mm 420mm 440mm 440mm
Seat-Tube Length, B-B Center to Top 412mm 412mm 415mm 415mm 418mm 420mm
Head-Tube Length 170mm 170mm 172.5mm 172.5mm 175mm 175mm
Ground-Top 73mm 73mm 71.5mm 71.5mm 70mm 70mm
Top-Tube Length, Horizontal 74mm 75.5mm 73.5mm 73.25mm 72.5mm 73mm
Front-Center 125mm 145mm 165mm 190mm 215mm 235mm
Head-Tube Angle 582° 588° 595° 606° 621° 628°
Stand-Over Height 75mm 90mm 100mm 100mm 110mm 120mm
Fork Rake 983mm 989mm 1000mm 1010mm 1029mm 1038mm
Trail 739mm 760mm 781mm 802mm 826mm 850mm
Chain-Stay Length 49mm 49mm 49mm 49mm 49mm 49mm
Seat-Tube Angle 59° 59° 59° 56° 53° 56°
B-B Drop 72mm 72mm 72mm 72.5mm 72.5mm 73mm
