enRockhopper - Geometry
Geometry
| XS | S | M | L | XL | XXL | |
|---|---|---|---|---|---|---|
| Crank Length | 165mm | 170mm | 170mm | 175mm | 175mm | 175mm |
| Stem Length | 45mm | 45mm | 60mm | 60mm | 70mm | 90mm |
| Seatpost Length | 350mm | 350mm | 350mm | 400mm | 400mm | 400mm |
| Saddle Width | 155mm | 155mm | 143mm | 143mm | 143mm | 143mm |
| Handlebar Width | 720mm | 720mm | 750mm | 750mm | 750mm | 750mm |
| Reach | 380mm | 395mm | 418mm | 441mm | 462mm | 474mm |
| Top Tube Length, Horizontal | 548mm | 567mm | 594mm | 622mm | 648mm | 660mm |
| Stack | 586mm | 595mm | 605mm | 619mm | 633mm | 633mm |
| Wheelbase | 1065mm | 1084mm | 1110mm | 1138mm | 1164mm | 1176mm |
| Chainstay Length | 440mm | 440mm | 440mm | 440mm | 440mm | 440mm |
| Front Center | 631mm | 650mm | 676mm | 704mm | 730mm | 742mm |
| BB Drop | 57.5mm | 57.5mm | 57.5mm | 57.5mm | 57.5mm | 57.5mm |
| BB Height | 312.5mm | 312.5mm | 312.5mm | 312.5mm | 312.5mm | 312.5mm |
| Seat Tube Angle | 74° | 73.9° | 73.8° | 73.7° | 73.6° | 73.6° |
| Head Tube Angle | 69.8° | 69.8° | 69.8° | 69.8° | 69.8° | 69.8° |
| Seat Tube Length | 370mm | 400mm | 430mm | 470mm | 520mm | 560mm |
| Head Tube Length | 95mm | 95mm | 95mm | 110mm | 125mm | 125mm |
| Bike Standover Height | 719mm | 765mm | 776mm | 807mm | 837mm | 861mm |
| Fork Rake/Offset | 51mm | 51mm | 51mm | 51mm | 51mm | 51mm |
| Fork Length, Full | 486mm | 496mm | 506mm | 506mm | 506mm | 506mm |
| Trail | 82mm | 82mm | 82mm | 82mm | 82mm | 82mm |
