2020 Pitch Sport

That spot where the bike path turns from concrete to dirt? The Pitch Sport is made to explore beyond, with a sturdy aluminum frame, smooth-riding front suspension, grippy tires for loose surfaces, and sure-stopping hydraulic disc brakes to keep you under control.

STRONG, SENSITIVE TYPE

Old-school strongmen have nothing on our A1 Premium Aluminum frame. But the Pitch Sport is in touch with its feelings too, offering a ride that's as comfortable as it is durable, thanks to a lightweight proprietary alloy and Sport Trail 27.5 Geometry for sure handling.

SIZE-SPECIFIC SUSPENSION

It's not enough to offer quality suspension like the coil-sprung SR SunTour XCT 30 fork on the Pitch Sport. We also custom-design travel based on frame size to keep the geometry and ride quality consistent over all sizes. Lockout limits annoying bobbing on smooth terrain.

SWEET SPOT WHEELS

Why 27.5-inch wheels exactly, not 27 or 28? It's a happy medium which offers most of the benefits of the older 26-inch size, like light weight and agility, with those of the newer, oversize 29er version, like fast-rolling efficiency and easy roll over obstacles.

The 16-speed Shimano drivetrain gives you the right gear, anytime.

A long-lasting, rust-resistant KMC chain offers quiet, sure shifting.

Grippy Ground Control Sport tires feature Flak Jacket flat protection.

Technical Specifications

Add Icon

FRAMESET

FRAME

A1 Premium Aluminum, Sport Trail 27.5 Geometry, zero-stack head tube, internal cable routing, 135x9mm forged dropouts, chainstay-mounted disc brake, replaceable alloy derailleur hanger

SEAT BINDER

Alloy, QR clamp, 34.9mm

SUSPENSION

FORK

SR SunTour XCT 30 w/ MCD lock out, Rx Tune, coil spring, 42mm offset, 80/90/100mm of travel of (size-specific)

COCKPIT

STEM

Stout 3D-forged alloy, 31.8mm, 6-degree rise

HANDLEBARS

Stout Mini Rise, alloy, 9-degree backsweep, 15mm rise, 31.8mm

GRIPS

Specialized MTB Grip, lock-on

SEATPOST

Alloy, 12mm offset, 2-bolt clamp, 30.9mm

BRAKES

FRONT BRAKE

Shimano BR-MT200, hydraulic disc, 160/180mm

REAR BRAKE

Shimano BR-MT200, hydraulic disc, 160mm

DRIVETRAIN

FRONT DERAILLEUR

Shimano Altus FD-M315

REAR DERAILLEUR

Shimano Acera, 8-speed

SHIFT LEVERS

Shimano EF505, hydraulic, 8-speed

CHAIN

KMC X8 EPT, anti-rust coating, 8-speed w/ reusable Missing Link™

CRANKSET

Stout 2x, forged alloy

CHAINRINGS

36/22T

BOTTOM BRACKET

Square-tapered, 73mm, internal bearings

CASSETTE

Sunrace, 8-speed, 11-34t

WHEELS

RIMS

Stout Trail 27.5, alloy, disc-specific, double-wall, 25mm internal width, 32h

FRONT HUB

Shimano, Center Lock™ disc, 9x100mm spacing, quick-release, 32h

REAR HUB

Shimano FH-TX505, Center Lock™ disc, 9x135mm spacing, quick-release, 32h

SPOKES

Stainless, 14g

FRONT TIRE

Ground Control Sport, 60 TPI, wire bead, Flak Jacket Flat protection, 27.5 x 2.3"

REAR TIRE

Ground Control Sport, 60 TPI, wire bead, Flak Jacket Flat protection, 27.5 x 2.3"

INNER TUBES

Schrader valve

* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.

Geometry

Add Icon
XSSMLXL
Crank Length165170170175175
Handlebar Width720mm720mm740mm740mm740mm
Stem Length3545456060
Saddle Width155mm155mm143mm143mm143mm
Seatpost Length350350350400400
Stack562mm562mm585mm604mm618mm
Reach380mm400mm420mm440mm460mm
Head Tube Length95mm95mm100mm120mm135mm
Head Tube Angle68.5°68.5°68.5°68.5°68.5°
BB Height310mm310mm310mm310mm310mm
BB Drop43mm43mm43mm43mm43mm
Trail94mm94mm94mm94mm94mm
Fork Length, Full475mm475mm495mm495mm495mm
Fork Rake/Offset42mm42mm42mm42mm42mm
Front Center631mm651mm680mm708mm733mm
Chainstay Length435mm435mm435mm435mm435mm
Wheelbase1063mm1083mm1112mm1139mm1165mm
Top Tube Length, Horizontal542mm572mm599mm625mm649mm
Bike Standover Height660mm690mm739mm766mm808mm
Seat Tube Length310mm360mm415mm450mm510mm
Seat Tube Angle74°73°73°73°73°
Geometry

Rider Reviews

  • 4
  • 3 Reviews

Pretty good bike.

This is a fun bike to ride. I have had a lot of experience riding it on dirt and through city streets and I have to say that you get a lot from this bike. On the road and on some smooth single track this thing handles it great, but the problem is when you get to more demanding trails. When riding drops, jumps, or bumpy terrain the bike has some problems. The chain slaps around like crazy and the chain sometimes even falls off. Also, the suspension is not enough for that kind of shredding. Something that really shined with this bike is the brakes, which have handled everything I've thrown at them. The tires are pretty good but dont provide tons of traction when riding damp or slick trails. Overall this bike is great if you want something that can get you into mountain biking while keeping its agility on the road. I have had some great experiences with this bike and I'm sure I'll have many more.


Name:
Da'quarius B.

Helpful?

Solid bike that gets the job done.

I absolutely love this bike. It is a great value for the price and it rides great. The breaking on this bike is really good and I have never had any problems with it. The tires on this bike are great and work well on dirt, gravel, and pavement. The shifting on this bike is really good. The fork is nice but isn't the greatest, I really wish it had more than only 100mm of travel. The pedals also aren't the greatest if you plan of riding any trails. I would recommend getting better pedals if you plan on taking this bike off road. this bike is really great if you are looking for a good bike that you can use on both trails and just biking around town. When I took this bike on my local trails I had a good experience. the bike handled really well on the less technical trails and on the climbs, it even performed well on some steeper sections. I was able to hit some small jumps and drops with it and it was really fun but the chain does make allot of noise on the bumpier trails. Overall this is a great bike for anyone who wants to get into mountain biking and have a good time.


Name:
Raj O.

Helpful?
