Men's Sirrus Elite Alloy
$1,200.00
Part No.

Men's Sirrus Elite Alloy

$1,200.00
Part No.
Please select an option
load-spinner
Men's Sirrus Elite Alloy
Overview
Technical Specifications
Geometry
Reviews

There's nothing elitist about our Sirrus Elite. In fact, it's designed to help anyone along their path to fitness and health. Need proof? How do a durable, lightweight aluminum frame and a FACT carbon fiber fork sound? If you ask us, it sounds like you found your partner in health. But if you need more convincing, let's turn a spotlight on its components.

It features a reliable and precise mix from Shimano & microSHIFT that will always have you in the right gear. Powerful hydraulic disc brakes, meanwhile, stop on a dime in any condition, while a whole host of scientifically tested and engineered Body Geometry components, from the grips to the saddle, will keep you riding in total comfort over the long haul. And lastly, you'll find that this bike was fully designed for use with racks and fenders, so lugging your stuff around the city just got a whole lot easier. We're in this together, and the Sirrus Elite Alloy will always have your back.

  • Working with our Body Geometry team, we designed a frame that strikes the optimal balance between comfort and efficiency. The A1 SL Premium Aluminum construction pairs weight savings with rugged durability, while the rack, fender, and disc mounts give you an incredibly versatile package.
  • The lightweight FACT carbon fiber fork provides a smooth, responsive ride, while the Plug + Play fender mounts give you the option to install rain-fighting fenders.
  • The Praxis Alba crankset is lightweight, durable, and aids in smooth, crisp shifts.

Technical Specifications

DRIVETRAIN
BOTTOM BRACKET Praxis M24, BSA
CHAIN KMC X10, 10-speed w/ reusable Missing Link™
CRANKSET Praxis Alba M24, solid forged arms, 6061 outer ring, steel inner ring, 110 BCD, 10-speed
SHIFT LEVERS microSHIFT, flat bar road shifters, 10-speed
FRONT DERAILLEUR microSHIFT Centos, 10-speed, 31.8mm clamp
CASSETTE Shimano Tiagra, 10-speed, 11-34t
CHAINRINGS 48/32T
REAR DERAILLEUR Shimano Tiagra, GS cage, 10-speed
SUSPENSION
FORK Specialized FACT 9r carbon, 1-1/8" steerer, QR, flat-mount disc, Plug + Play rack & fender mounts
COCKPIT
SADDLE Specialized Canopy Comp, hollow Cr-Mo rails
SEAT BINDER Bolt-type, 31.8mm
SEATPOST Alloy, 2-bolt, 14mm offset, 27.2mm
HANDLEBARS Double-butted alloy, 9-degree backsweep, 31.8mm
STEM Specialized Flowset, integrated, 3D-forged alloy, 4-bolt, 12-degree rise, 31.8mm clamp
WHEELS & TIRES
FRONT HUB Alloy, 6-bolt disc, loose ball bearings, 100mm spacing, quick-release 24h
REAR HUB Alloy, 6-bolt disc, 11-speed freehub, loose ball bearings, 135mm quick-release, 28h
INNER TUBES Presta, 48mm valve
SPOKES Stainless, 14g
RIMS 700C disc, double-wall alloy, 30mm depth, 21mm internal width, disc-specific
FRONT TIRE Espoir Sport Reflect, 60 TPI, wire bead, double BlackBelt protection, 700x30mm
REAR TIRE Espoir Sport Reflect, 60 TPI, wire bead, double BlackBelt protection, 700x30mm
BRAKES
FRONT BRAKE TRP Flow Set Control, hydraulic disc, resin pads, flat-mount, 160mm
REAR BRAKE TRP Flow Set Control, hydraulic disc, resin pads, flat-mount, 140mm
ACCESSORIES
PEDALS Specialized Fitness platform, alloy
FRAMESET
FRAME Specialized A1 SL Premium Aluminum, Fitness Geometry, fully manipulated butted tubing, internal cable routing, flat-mount disc, quick-release, Plug + Play rack/fender mounts

Geometry

Geometry Chart

Sirrus - Geometry

S M L XL XXL
  S M L XL XXL
Crank Length 170MM 170MM 172.5MM 172.5MM 175MM
Stem Length 75mm 90mm 90mm 105mm 105mm
Seatpost Length 300mm 350mm 350mm 350mm 350mm
Saddle Width 155mm 155mm 155mm 155mm 155mm
Handlebar Width 580mm 580mm 600mm 620mm 620mm
Reach 388mm 400mm 402mm 414mm 426mm
Top Tube Length, Horizontal 555mm 576mm 583mm 604mm 631mm
Stack 564mm 593mm 611mm 639mm 670mm
Wheelbase 1057mm 1069mm 1072mm 1087mm 1109mm
Chainstay Length 440mm 440mm 440mm 440mm 440mm
Front Center 626mm 638mm 641mm 656mm 679mm
BB Drop 70mm 70mm 70mm 70mm 70mm
BB Height 275mm 275mm 275mm 275mm 275mm
Seat Tube Angle 73.5° 73.5° 73.5° 73.5° 73°
Head Tube Angle 70° 71° 71.5° 72° 72°
Seat Tube Length 415mm 455mm 495mm 535mm 565mm
Head Tube Length 153mm 179mm 196mm 223mm 256mm
Bike Standover Height 735mm 775mm 805mm 845mm 875mm
Fork Rake/Offset 51mm 51mm 51mm 51mm 51mm
Fork Length, Full 390mm 390mm 390mm 390mm 390mm
Trail 72mm 65mm 62mm 59mm 59mm
