Men's Camber Comp Carbon 27.5

Icon

2018 Men's Camber Comp Carbon 27.5

Life is full of choices, but choosing the right trail bike isn't an easy one. If you value efficiency and playful trail manners, however, the Camber Comp Carbon 27.5 is for you.

It blends all of the trail bike characteristics that you want with the XC climbing prowess that you need. This is achieved by thoughtfully combining our FACT 9m carbon fiber Trail Chassis with a M5 alloy Camber FSR rear end. The combination results in blending light weight, rigidity, and durability in one package.

At both ends of the bike, you'll find a little extra travel to deliver 130mm of plush suspension—all without going overboard on big hit capability. This means that you don't have to sacrifice efficiency, weight, or sheer speed to ride how you want. And with our Trail 27.5 Geometry and lightweight, stiff, and smooth Concentric Pivot at the rear, we can guarantee it.

The other trail component of the Camber is utility, and along these lines, it features our fully integrated SWAT™ Door at the down tube of the frame. Open it up, and you're able to safely and securely house your ride essentials right where you want them—on the bike.

For the build, we selected components that focus on strength and performance, like a SRAM GX/NX one-by drivetrain, powerful SRAM Level TL hydraulic disc brakes, and our all-new Command Post IRcc dropper with up to 10 mid-positions. However you ride, the Camber is ready for it.

Technical Specifications

Add Icon

FRAMESET

FRAME

FACT 9m carbon front chassis w/ Specialized M5 Aluminum rear end, 27.5 Trail Geometry, SWAT™ Door integration, PF30 BB, fully enclosed internal cable routing, Concentric Pivot link, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 130mm of travel

SEAT BINDER

Alloy, 34.9mm

SUSPENSION

REAR SHOCK

FOX FLOAT Performance, Rx Trail Tune, AUTOSAG, DPS damper, rebound and 3-position compression adjust, 205x53mm

FORK

RockShox Reba RL 27.5, tapered alloy steerer, 46mm offset, external rebound adjust, low speed compression to lockout, Maxle® Stealth thru-axle, 130mm of travel

WHEELS

RIMS

Roval Traverse 27.5, hookless alloy, 29mm inner width, tubeless ready, 24/28h

FRONT HUB

Specialized, sealed cartridge bearings, 15x110mm spacing, 24h

REAR HUB

Specialized, sealed cartridge bearings, 12x148mm thru-axle, 28h

SPOKES

DT Swiss Industry, stainless, 3-cross, 2.0"

FRONT TIRE

Purgatory, Gripton compound, 2Bliss Ready, 27.5 x 2.3"

REAR TIRE

Ground Control, Gripton compound, 2Bliss Ready, 27.5 x 2.3"

INNER TUBES

27.5 x 1.75/2.4mm, 40mm Presta valve

DRIVETRAIN

REAR DERAILLEUR

SRAM GX, long cage, 11-speed

SHIFT LEVERS

SRAM GX, trigger, 11-speed

CASSETTE

SRAM NX, 11-speed, 11-42t

CHAIN

KMC X11, 11-speed w/ Missing Link™

CRANKSET

Race Face Aeffect crank, 170/175mm arms, PF30

CHAINRINGS

Steel, 30T

BOTTOM BRACKET

Race Face PF30

COCKPIT

STEM

Specialized Trail, 3D forged alloy, 4-bolt, 6-degree rise

HANDLEBARS

Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 27mm rise, 750mm width

GRIPS

Specialized Sip Grip, half-waffle, S/M: regular thickness, L/XL: XL thickness

SADDLE

Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm

SEATPOST

Command Post IRcc, 12-position micro-height adjustable, alien head design, bottom mount cable routing, remote SRL lever, 30.9mm, S: 100mm, M/L/XL: 125mm of travel

BRAKES

FRONT BRAKE

SRAM Level TL disc lever/caliper, organic pads, 200/180mm rotors

REAR BRAKE

SRAM Level TL disc lever/caliper, organic pads, 180/160mm rotors

ACCESSORIES

PEDALS

Specialized Platform, Cr-Mo, 9/16" spindle

* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.

Geometry

Add Icon
SMLXL
Crank Length170mm175mm175mm175mm
Handlebar Width750mm750mm750mm750mm
Stem Length60mm60mm75mm90mm
Saddle Width143mm143mm143mm143mm
Seatpost Length390mm430mm430mm430mm
Stack580mm590mm599mm608mm
Reach399mm425mm454mm475mm
Head Tube Length105mm115mm125mm95mm
Head Tube Angle68°68°68°68°
BB Drop23mm23mm23mm23mm
Trail97mm97mm97mm97mm
Fork Length, Full522mm522mm522mm522mm
Fork Rake/Offset42mm42mm42mm42mm
Front Center670mm700mm732mm757mm
Chainstay Length420mm420mm420mm420mm
Wheelbase1089mm1119mm1151mm1176mm
Top Tube Length, Horizontal554mm583mm614mm638mm
Bike Standover Height725mm730mm743mm752mm
Seat Tube Length396mm430mm468mm523mm
Seat Tube Angle75°75°75°75°
