2012 Haul 1 Step-Through

0 Reviews

Riders who would rather use their legs than drive a car will love this real-deal…

Color:

Red

What's my size?

Imperial

Metric

Enter your height and we'll calculate your size.

Height:

For a more accurate result, include your shin length.

Select a Size

Choose the color and size you're looking for to search nearby store inventory.

Unavailable

This item is not available for Find Nearby

Product Details

Riders who would rather use their legs than drive a car will love this real-deal cargo bike with integrated deck and fenders. The Haul 1 is designed for carrying heavier loads than you thought possible on two wheels, with a step-through design for easy access.

Uber-tough but lightweight, this Globe A1 Premium Aluminum step-through frame with integrated rack makes loaded transport simple and easy
Double walled 32-hole alloy rims with high-flange, phone dial hubs for timeless look and smooth ride
City grips look stylish and keep hands comfortably and safely in place
Shimano Altus 7-speed rear derailleur provides sure-fire shifts every time
Classic BG saddle is soft and supportive for efficient comfort, with center groove for those sensitive areas, and bumpers for durability
BB-mounted kickstand for added convenience
Sturdy and convenient integrated alloy rack carries 10kg load with style
Durable full-coverage steel fenders, with a detailed nose, provide stylish protection from the elements, and accommodate wide commuter tires

Technical Specifications

FRAMESET

FRAME

Globe A1 Premium Aluminum trekking design, fully manipulated tubing w/ fender and rack braze-ons, integrated kickstand mount, fully integrated rear rack w/ forged dropout and pannier hook

FORK

Globe Hi-Ten straight-blade steel fork

HEADSET

1-1/8"" threadless, integrated, semi-cartridge Campy style bearings

SEAT BINDER

Globe forged alloy extra slim clamp, 31.8mm

WHEELS

REAR HUB

Forged alloy, double-sealed, cassette, QR

SPOKES

2mm (14g) stainless

FRONT TIRE

Specialized Nimbus Sport w/ Flak Jacket protection, 26 TPI, 700x35c

REAR TIRE

Specialized Nimbus Sport w/ Flak Jacket protection, 26 TPI, 700x35c

INNER TUBES

Schrader valve

RIMS

Alloy double-wall

FRONT HUB

Forged alloy, double sealed, ground race, QR

DRIVETRAIN

FRONT DERAILLEUR

Shimano, top swing, dual pull

REAR DERAILLEUR

Shimano Altus, 7-speed

SHIFT LEVERS

Shimano Alivio Rapidfire, 7-speed

CASSETTE

Shimano Mega Range, 7-speed, 14-34t

CHAIN

KMC Z7

CRANKSET

SR Suntour double ring, w/ alloy crank arm, 170mm

CHAINRINGS

38/28s, w/alloy guard

BOTTOM BRACKET

Cartridge bearing, square spindle w/ crank stop right side, capless bolts

COCKPIT

STEM

Forged alloy, 4-bolt, 25.4mm, 1-1/8"" w/ 15 degree rise

HANDLEBARS

Alloy, 25.4mm, 31 degree up, 24 degree back sweep

TAPE

Globe City 140mm close type

SADDLE

Globe Haul women's w/ through hole, 175mm

SEATPOST

Alloy, 2-bolt forged head, 30.9mm, 12.5mm offset

BRAKES

FRONT BRAKE

Alloy linear pull, 1pc. pad

REAR BRAKE

Alloy linear pull, 1pc. pad

BRAKE LEVERS

Die cast ""V""-brake lever, linear pull

ACCESSORIES

PEDALS

Composite platform body, sealed loose ball bearings

* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.

Geometry

	SM	MD	LG
Seat-Tube Angle	74.5°	74°	73.5°
Head-Tube Length	140mm	170mm	200mm
Seat-Post Length	350mm	350mm	350mm
Head-Tube Angle	69.5°	69.5°	70°
Chain-Stay Length	500mm	500mm	500mm
Top-Tube Length, Horizontal	540mm	555mm	570mm
Front-Center	628mm	640mm	646mm
Handle-Bar Width	650mm	650mm	650mm
Stand-Over Height	603mm	612mm	617mm
Seat-Tube Length, B-B Center to Top	385mm	435mm	460mm
Fork Rake	51mm	51mm	51mm
B-B Drop	65mm	65mm	65mm
Trail	78mm	78mm	74mm
Wheelbase	1121mm	1133mm	1139mm
Crank Length	170mm	170mm	175mm
Stem Length	90mm	90mm	110mm
