Haul 1 Step Through
$660.00
Part No.

Haul 1 Step Through

$660.00
Part No.  23032
load-spinner
Haul 1 Step Through
Overview
Technical Specifications
Geometry
Reviews
Riders who would rather use their legs than drive a car will love this real-deal cargo bike with integrated deck, lights and fenders. The HAUL is designed for carrying heavier loads than you thought possible on two wheels.
  • Folding alloy kickstand
  • Globe City grips deliver form, fit and function in one simple design
  • Slim and effective color-matched alloy chainguard keeps your duds clean
  • Beautiful Elm wood deck adds to the function of the rear rack - holds 40kg
  • Globe classic aluminum fenders are color matched with custom chevron detail
  • Shimano Alivio 8-speed rear derailleur and double front crank are tough and precise
  • Double-walled 700c rims with machined sidewalls offer durability in a lightweight profile
  • Women’s Body Geometry Fitness saddle with front and rear bumpers for comfort where it counts
  • Form-fit LED tail light with steady and flashing functions, front light integrated into handlebar stem for visibility
  • Globe A1 Premium Aluminum frame with custom tubing and butting profiles, sturdy integrated rack makes loaded transport simple, secure and easy

Technical Specifications

FRAMESET
SEAT BINDER Globe Chevron forged alloy, chrome plated
HEADSET 1-1/8"" threadless, integrated, semi-cartridge campy style bearings
FORK Globe Haul straight-blade steel fork
FRAME Globe A1 Premium Aluminum cargo design, fully manipulated custom tubing w/ fender and rack braze-ons, integrated kickstand mount, fully integreated rear rack w/ forged dropout and pannier hook
WHEELS
FRONT HUB Forged alloy, double sealed, ground race, QR, 36h
REAR HUB Forged alloy, double sealed, ground race, cassette, QR, 36h
INNER TUBES Schraeder valve
SPOKES 1.8mm (15g) stainless
RIMS Globe 700c, double wall, 36h w/CNC side wall
FRONT TIRE Specialized Nimbus, 700x35c, 60TPI, w/ Flak Jacket protection
REAR TIRE Specialized Nimbus, 700x35c, 60TPI, w/ Flak Jacket protection
DRIVETRAIN
BOTTOM BRACKET Cartridge bearing, square spindle with crank stop right side and capless bolts
CHAIN KMC Z8, w/ reusable Missing Link
CRANKSET FSA alloy crank arm
CASSETTE SRAM PG-820, 8-speed, 11-32t
SHIFT LEVERS Shimano SL-MC40, 8-speed, Rapid Fire
FRONT DERAILLEUR Shimano FD-M310, 31.8mm clamp, top swing, dual pull
CHAINRINGS 48 x 36 x 26t w/ chainguard
REAR DERAILLEUR Shimano Alivio, 8-speed
COCKPIT
SADDLE Specialized Body Geometry Fitness women's, front and rear bumpers, 155mm width
TAPE Globe City 140mm
SEATPOST Alloy, 2-bolt forged head, 12.5mm offset, 27.2mm
HANDLEBARS Alloy, 31.8mm, 650mm wide, 31 degree up, 24 degree back sweep
STEM Forged alloy, 4-bolt, 31.8mm, 8 degree rise, including LED top-cap light
BRAKES
BRAKE LEVERS V-Brake, linear pull
FRONT BRAKE Alloy linear pull, 1pc. pad
REAR BRAKE Alloy linear pull, 1pc. pad
ACCESSORIES
PEDALS Globe City, Body Geometry, composite w/rubber top, 1.5mm varus wedge

Geometry

Geometry Chart

Haul - Geometry

SM MD LG
  SM MD LG
Wheelbase 1121mm 1133mm 1139mm
Seat-Tube Length, B-B Center to Top 385mm 435mm 460mm
Head-Tube Length 140mm 170mm 200mm
Top-Tube Length, Horizontal 540mm 555mm 570mm
Front-Center 628mm 640mm 646mm
Head-Tube Angle 69.5° 69.5° 70°
Fork Rake 51mm 51mm 51mm
Trail 78mm 78mm 74mm
Stand-Over Height 603mm 612mm 617mm
Chain-Stay Length 500mm 500mm 500mm
Seat-Tube Angle 74.5° 74° 73.5°
B-B Drop 65mm 65mm 65mm
Seat-Post Length 0mm 0mm 0mm
