Hardrock
FRAME
Specialized A1 Premium Aluminum, fully butted, w/ canti bosses, 6061 alloy, double ORE down tube, externally relieved head tube, forged dropouts and reinforced disc mount, alloy replaceable derailleur hanger
HEADSET
1-1/8"" threadless, loose ball w/ seals
SEAT BINDER
34.9mm, alloy, extruded QR lever/collar
FORK
SR Suntour XCT (SF12-XCT-V4-P), 1pc. alloy lower, 28mm Hi-Ten stanchions, 1-1/8"" alloy steerer, coil/mcu spring w/ preload adj., 80mm travel
RIMS
Alex HR 26"", alloy double-wall, 24mm, pin joint, 32h
FRONT HUB
QR axle, sealed loose ball, 17mm contact, 32h
REAR HUB
Double-sealed loose ball, 19mm contact, QR, 32h
SPOKES
Stainless silver, 2.0mm (14g)
FRONT TIRE
Specialized Fast Trak LK Sport, 60 TPI, wire bead, 26x2.0""
INNER TUBES
Schrader valve
REAR TIRE
Specialized Fast Trak LK Sport, 60 TPI, wire bead, 26x2.0""
FRONT DERAILLEUR
Shimano Altus, 8-speed, 34.9mm clamp, top-swing, dual-pull
REAR DERAILLEUR
SRAM X3, 7-speed, long cage
SHIFT LEVERS
SRAM X3, 7-speed, trigger
CASSETTE
Shimano 7-speed, 12-32t
CHAIN
KMC X-8, 8-speed, reusable Missing Link
CRANKSET
SR Suntour XCT, 8-speed, square taper spindle
CHAINRINGS
42/32/22, replaceable outer
BOTTOM BRACKET
Square taper, cartridge bearing, double crank stop
STEM
Ahead, 4 bolt clamp, 20º rise, 25.4mm
HANDLEBARS
Hi-Ten riserbar, 35mm rise, 8º backsweep, 4º upsweep, 25.4mm
GRIPS
Specialized Enduro, dual compound
SADDLE
Specialized Body Geometry Hardrock, steel rails, front and rear bumpers, 143mm width
SEATPOST
Alloy, 2 bolt head, 30.9mm, 12.5mm offset, micro adjust
FRONT BRAKE
Die cast, alloy ""V"" brake, 1pc. pad
REAR BRAKE
Die cast, alloy ""V"" brake, 1pc. pad
BRAKE LEVERS
Alloy ""V""-brake, two-finger, linear pull
PEDALS
Composite platform w/ molded pins, toe clip compatible, 9/16"" w/ reflectors
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
13.0 | 15.5 | 17.5 | 19.0 | 21.0 | 23.0 | |
---|---|---|---|---|---|---|
Top Tube Length (Horizontal) | 540mm | 561mm | 586mm | 605mm | 630mm | 655mm |
Top Tube Length (Actual) | 534mm | 542mm | 563mm | 581mm | 608mm | 638mm |
Seat Tube Length, Center to Top | 330mm | 394mm | 444mm | 483mm | 533mm | 584mm |
Bottom Bracket Drop | 41mm | 41mm | 41mm | 41mm | 41mm | 41mm |
Bottom Bracket Height | 299mm | 299mm | 299mm | 299mm | 299mm | 299mm |
Wheel Base | 1022mm | 1044mm | 1069mm | 1088mm | 1114mm | 1140mm |
Standover Height | 696mm | 724mm | 759mm | 794mm | 830mm | 865mm |
Stack | 571mm | 571mm | 590mm | 590mm | 609mm | 628mm |
Reach | 365mm | 387mm | 406mm | 425mm | 444mm | 463mm |
Head Tube Length | 100mm | 100mm | 120mm | 120mm | 140mm | 160mm |
Head Tube Angle | 70.25° | 70.25° | 70.25° | 70.25° | 70.25° | 70.25° |
Chainstay Length | 424mm | 424mm | 424mm | 424mm | 424mm | 424mm |
Seat Tube Angle | 73° | 73° | 73° | 73° | 73° | 73° |
Crank Length | 170mm | 170mm | 175mm | 175mm | 175mm | 175mm |
Handlebar Width | 640mm | 640mm | 640mm | 640mm | 640mm | 640mm |
Stem Length | 60mm | 75mm | 75mm | 90mm | 90mm | 105mm |
Seatpost Length | 300mm | 350mm | 350mm | 400mm | 400mm | 400mm |
