Overview
Technical Specifications
Geometry
Reviews
AN OLD FAVORITE MADE NEW, the Hardrock is still the most versatile hardtail for kicking around town, but its lighter weight, more efficient alloy chassis and category-leading specifications make it the perfect introduction to XC Trail riding.
  • This fully butted A1 Premium Aluminum frame offers improved fatigue life and comfort in a high performance and lightweight chassis, with an ORE top/down tube, externally relieved head tube and reinforced disc brake mount.
  • An SR Suntour suspension fork features a smooth 80mm of travel, with external preload adjustment for on the fly, fine-tuned performance.
  • Dual compound Enduro grips offer a comfortable handhold on long rides.
  • 7-speed EZ-fire shifters provide predictably smooth, accurate gear changes.
  • The smooth-shifting Shimano crankset is a rock-solid performer in a wide range of conditions.
  • Lightweight Specialized Fast Trak LK Sport tires have a low knob height for efficiency and shoulder knobs for precise cornering.
  • The Specialized XC saddle features Body Geometry comfort and abrasion-resistant side patches for enhanced durability.

Technical Specifications

DRIVETRAIN
CHAIN KMC Z7 w/ reuseable Missing Link
BOTTOM BRACKET FSA BB-7420, cartrdge bearings, 68mm x 122.5mm for 47.5mm chain line
CRANKSET Shimano FCM-191, polished
FRONT DERAILLEUR Shimano C-050, 34.9mm clamp
SHIFT LEVERS Shimano ST-EF50-7, 7-speed
CASSETTE Shimano MF-TZ31, 7-speed, 14-34t Mega Range
CHAINRINGS 42 x 34 x 24t
REAR DERAILLEUR Shimano Altus
SUSPENSION
FORK SR Suntour SF8-XCT-V2, 80mm, 1pc. alloy lower, 28mm Hi-Ten stanchions, 13-15"": standard spring, all others: ""stiff"" spring, coil/mcu spring w/ preload adj., spring assisted seals, disc only
WHEELS
FRONT HUB Specialized Hi Lo, forged alloy, double sealed, ground race, 32h
REAR HUB Specialized forged alloy,double sealed, ground race, QR, 32h
INNER TUBES Specialized schraeder valve
SPOKES 1.8mm (15g) stainless w/ brass nipples
FRONT TIRE Specialized Fast Trak LK Sport, 26x2.0"", 60TPI, aramid bead
RIMS Alex Z-1000, 26"", single wall, 32h
REAR TIRE Specialized Fast Trak LK Sport, 26x2.0"", 60TPI, aramid bead
COCKPIT
SADDLE Specialized XC, Body Geometry, 143mm width, front and rear bumpers
SEATPOST Specialized alloy two bolt, no offset, micro adjust, 30.9mm
STEM Specialized forged alloy, 15 degree rise
HANDLEBARS Specialized Hi-Ten, 32mm rise, 640mm wide, 8 degree back sweep, 6 degree up, 1.6mm thick
GRIPS Specialized Enduro, dual compound Kraton, no flange, 131mm
BRAKES
FRONT BRAKE Alloy linear pull, 1pc. pad
BRAKE LEVERS Shimano (integrated w/ shifter)
REAR BRAKE Alloy linear pull, 1pc. pad
ACCESSORIES
PEDALS Steel cage, composite body, 9/16""
FRAMESET
HEADSET Specialized 1-1/8"" threadless, loose ball
SEAT BINDER Specialized alloy w/ QR
FRAME Specialized A1 Premium Aluminum, fully butted, formed TT, double ORE DT, externally relieved HT, reinforced disc mount, forged dropouts w/ replaceable 98954020 hanger

Geometry

Geometry Chart

- Geometry

  13 15 17 19 21 23
Crank Length 170mm 170mm 170mm 175mm 175mm 175mm
Stem Length 60mm 60mm 75mm 75mm 90mm 90mm
Seatpost Length 350mm 350mm 350mm 400mm 400mm 400mm
Handlebar Width 640mm 640mm 640mm 640mm 640mm 640mm
Chainstay Length 424mm 424mm 424mm 424mm 424mm 424mm
Top Tube Length (Actual) 534mm 538mm 557mm 581mm 608mm 638mm
Top Tube Length (Horizontal) 540mm 555mm 580mm 605mm 630mm 655mm
Head Tube Angle - Low Setting 70.25° 70.25° 70.25° 70.25° 70.25° 70.25°
Standover Height 696mm 727mm 766mm 794mm 830mm 865mm
Head Tube Height 100mm 100mm 120mm 120mm 140mm 160mm
Wheel Base 1017mm 1032mm 1058mm 1083mm 1109mm 1135mm
Seat Tube Angle (Actual) - Low Setting 73° 73° 73° 73° 73° 73°
Seat Tube Length - Center to Top 330mm 381mm 432mm 483mm 533mm 584mm
Bottom Bracket Height - Low Setting 299mm 299mm 299mm 299mm 299mm 299mm
