Globe Vienna 4
$880.00
Part No.

Globe Vienna 4

$880.00
Part No.  22268
load-spinner
Globe Vienna 4
Overview
Technical Specifications
Geometry
Reviews
The multi-tool of city bikes—as versatile, efficient and economical as they come. Once you realize your college 10-speed isn't what it used to be, go for this simple, clean and reliable bike built for your everyday commute, fitness break or casual loop.
  • Body Geometry Comfort grips with integrated bell prevent hand pain and tingling fingers.
  • The Sugino Impel aluminum crankset provides a solid and smooth-spinning pedaling platform.
  • Shimano’s Nexus rear hub provides a smooth shifting, worry-free internal 8-speed setup.
  • Globe 700c rims are double-walled and eyeletted for strength, with machined sidewalls for smooth braking.
  • A Body Geometry Sonoma saddle reduces pressure on sensitive arteries.

Technical Specifications

DRIVETRAIN
CHAIN Shimano CN-NX10 1/2"" x 1/8""
BOTTOM BRACKET Shimano BB-UN26, square taper
CRANKSET Sugino EX-1 aluminum
SHIFT LEVERS Shimano Tape Fire, 8-speed
CHAINRINGS 42t
SUSPENSION
FORK Specialized A1 Premium Aluminum steerer and blades
WHEELS
FRONT HUB Specialized, forged alloy, double sealed, ground race, steel QR, 32h
REAR HUB Shimano Nexus Internal 8-Speed
INNER TUBES Specialized schraeder valve
SPOKES 1.8mm (15g) stainless
FRONT TIRE Specialized Nimbus, 700x35c, 60TPI, Flak Jacket
RIMS Specialized/Alex Globe, 700c, pinned, double wall w/ CNC sidewalls, eyelets, 32h
REAR TIRE Specialized Nimbus, 700x35C, 60TPI, Flak Jacket
COCKPIT
SADDLE Specialized Sonoma, Body Geometry, 155mm width, front and rear bumpers
SEATPOST Specialized alloy two bolt, no offset, micro adjust, 27.2mm
STEM Globe 3D forged, 10 degree rise, 25.4mm clamp
HANDLEBARS Globe alloy flatbar, 31.8mm, 600mm wide, 15 degree back sweep
GRIPS Men's Body Geometry Comfort w/ integrated bell, closed end, 132mm
BRAKES
FRONT BRAKE Avid SD3, alloy linear pull w/ 1pc. pad
BRAKE LEVERS Shimano Nexus
REAR BRAKE Avid SD3, alloy linear pull w/ 1pc. pad
ACCESSORIES
PEDALS Globe, Body Geometry Aluminum, anti-slip composite, 9/16""
FRAMESET
HEADSET Specialized semi integrated, Campy style
SEAT BINDER Specialized forged alloy, stainless bolt
FRAME Specialized A1 Premium Aluminum trekking design, fully manipulated tubing, internal gear dropouts w/ fender and rack braze-ons, integrated kickstand mount

Geometry

Geometry Chart

Vienna - Geometry

  45 49 53 57 61
Handle-Bar Width 620mm 620mm 620mm 620mm 620mm
Reach 0mm 0mm 0mm 0mm 0mm
Wheelbase 1089mm 1099mm 1109mm 1108mm 1129mm
Stack 0mm 0mm 0mm 0mm 0mm
Seat-Tube Length, B-B Center to Top 385mm 425mm 490mm 520mm 560mm
Head-Tube Length 150mm 170mm 190mm 210mm 230mm
Ground-Top 0mm 0mm 0mm 0mm 0mm
Top-Tube Length, Horizontal 550mm 565mm 580mm 595mm 635mm
Front-Center 642mm 657mm 667mm 666mm 687mm
Head-Tube Angle 69° 69° 69° 70° 71°
Fork Rake 51mm 51mm 51mm 51mm 51mm
Trail 82mm 82mm 82mm 75mm 68mm
Stand-Over Height 715mm 756mm 777mm 797mm 821mm
Chain-Stay Length 455mm 455mm 455mm 455mm 455mm
Seat-Tube Angle 76° 75.5° 74.5° 73.5° 72.5°
B-B Drop 65mm 65mm 65mm 65mm 65mm
