Fuse Comp 29
Fuse Comp 29
We deliver! Just say when and how.
The Fuse Comp 29 punches way above its weight class thanks to a light-yet-burly M4 aluminum chassis, frame geometry that lends the bike both playfulness and capability, and parts that withstand a serious flogging.
Technical Specifications
Frameset
Frame
Specialized M4 Premium Aluminum, 148mm thru-axle, adjustable dropout, SS compatible, tapered head tube, internal cable routing
Seat Binder
Alloy, 38.6mm
Suspension
Fork
RockShox Recon RL, air spring, 46mm offset, 130mm of travel
Cockpit
Stem
Stout 3D-forged alloy, 31.8mm, 6-degree rise
Handlebars
Stout Riser, double-butted alloy, 9-degree backsweep, 5-degree upsweep, 15mm rise, 750mm / 780mm width, 31.8mm
Tape
Specialized Trail Grips
Saddle
Bridge Comp, Hollow Cr-mo rails, 155/143mm
SeatPost
TranzX Dropper, 34.9mm, XS-S: 100mm, M: 125mm, L-XL: 150mm
Brakes
Front Brake
SRAM Level TRL, hydraulic disc, 4-piston, 200/180mm
Rear Brake
SRAM Level TRL, hydraulic disc, 2-piston, 180/160mm
Drivetrain
Rear Derailleur
SRAM NX Eagle, 12-speed
Shift Levers
SRAM NX Eagle, trigger, 12-speed
Cassette
SRAM NX Eagle, 12-speed, 11-50t
Chain
SRAM, SX Eagle, 12-speed
Crankset
SRAM, X1 Alloy Eagle, 12-speed
Chainrings
32T
Bottom Bracket
SRAM DUB, BSA 73mm, Threaded
Wheels & Tires
Rims
Specialized Alloy, Tubeless Ready, 29mm internal width, 28h
Front Hub
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
Rear Hub
Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h
Spokes
Stainless, 14g
Front Tire
Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 29x2.6"
Rear Tire
Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 29x2.6"
Inner Tubes
TUBES,STANDARD 48MM PV LOW LEAD 29x1.75/2.4, MAXXIS BRAND
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice. // eslint-disable-line react/no-danger
Geometry
| XS | S | M | L | XL | |
|---|---|---|---|---|---|
| Crank Length | 170mm | 170mm | 170mm | 170mm | 175mm |
| Handlebar Width | 750mm | 750mm | 780mm | 780mm | 780mm |
| Stem Length | 45mm | 45mm | 45mm | 45mm | 45mm |
| Saddle Width | 155mm | 143mm | 143mm | 143mm | 143mm |
| Seatpost Length | 356mm | 356mm | 406mm | 456mm | 456mm |
| Stack | 625mm | 625mm | 625mm | 639mm | 652mm |
| Reach | 400mm | 420mm | 440mm | 460mm | 480mm |
| Head-Tube Length | 95mm | 95mm | 95mm | 110mm | 125mm |
| Head-Tube Angle | 66.5° | 66.5° | 66.5° | 66.5° | 66.5° |
| B-B Height | 315mm | 315mm | 315mm | 315mm | 315mm |
| B-B Drop | 60mm | 60mm | 60mm | 60mm | 60mm |
| Trail | 113mm | 113mm | 113mm | 113mm | 113mm |
| Fork Length (full) | 540mm | 540mm | 540mm | 540mm | 540mm |
| Fork Rake/Offset | 46mm | 46mm | 46mm | 46mm | 46mm |
| Front-Center | 698mm | 718mm | 738mm | 764mm | 790mm |
| Chain-Stay Length - Short | 420mm | 420mm | 420mm | 420mm | 420mm |
| Chain-Stay Length - Long | 435mm | 435mm | 435mm | 435mm | 435mm |
| Wheelbase | 1122mm | 1142mm | 1162mm | 1188mm | 1214mm |
| Top-Tube Length (horizontal) | 579mm | 599mm | 619mm | 643mm | 667mm |
| Bike Stand-Over Height | 727mm | 747mm | 750mm | 754mm | 793mm |
| Seat-Tube Length | 340mm | 375mm | 410mm | 455mm | 505mm |
| Seat-Tube Angle | 74° | 74° | 74° | 74° | 74° |
