COMPETITIVE XC Let's be honest here: The endless pursuit of speed is the reason you ride. That might mean beating up on the regulars at your Saturday morning ride or leading the pack through a tough section of trail at a NORBA National. Proven at every level of competition-our 2007 S-Works edition has already won a UCI World Cup. The Epic, with its incredibly efficient Flow Control Brain suspension technology, is the fastest suspension bike in the world.

Read all about Total Suspension Integration. (Adobe PDF, 3MB)

  • Body Geometry women's Jett saddle for lightweight comfort and race-ready control
  • S-Works The Captain front tire and Fast Trak LK rear tire is the ideal combination for speed and aggressive cornering
  • M5 alloy FSR frame with women’s-specific geometry and tubing creates a lightweight chassis with superior ride quality
  • Custom DT Swiss wheelset uses sealed cartridge bearings, a DT Swiss rear hub and stainless spokes for quality without the weight penalty
  • 100mm-travel RockShox SID Race fork uses motion control damper and external rebound/compression adjust to match performance with rear shock
  • Custom Avid Elixir R hydraulic brakes—160mm rotor in front and 140mm in back (L: 160mm rear)—for balanced and powerful stopping control
  • Specialized and Fox blend their brains to develop the new FlowControl Mini Brain shock with Brain Fade adjust inertia valve, air spring and adjustable rebound, tuned for women's XC performance

Technical Specifications

Technical Specifications

DRIVETRAIN
CHAIN SRAM PC-971, 9-speed w/Power Link
BOTTOM BRACKET Custom Shimano, integrated outboard bearing
CRANKSET Custom Shimano FC-M762, 2pc., S/M: 170mm, L: 175mm
FRONT DERAILLEUR Shimano M660 SLX, DMD, top swing, dual pull
SHIFT LEVERS SRAM X-9 aluminum trigger
CASSETTE Shimano HG61, 9-speed, 11-34t
CHAINRINGS 44A x 32A x 22S
REAR DERAILLEUR SRAM X-0, 9-speed mid cage
SUSPENSION
FORK RockShox SID Race for Specialized, 100mm travel, air spring, rebound and floodgate compression adj.w/ LO, alloy steerer
REAR SHOCK Fox/SBC remote mini-brain, inertia valve, w/ Brain fade adjust
WHEELS
FRONT HUB Specialized Hi Lo disc, CNC flange, sealed cartridge bearing, oversized end caps, 9mm DT RWS, alloy QR, 28h
REAR HUB Custom DT Swiss 330SL w/ alloy freehub, QR, 32h
INNER TUBES Ultralight presta valve
SPOKES DT Swiss Competition 1.8/1.6mm stainless
FRONT TIRE S-Works The Captain, 26x2.0"", 120 TPI, tubeless ready aramid bead, dual compound
RIMS Custom DT Swiss X420SL, 24mm w/ eyelets, 28/32h
REAR TIRE S-Works Fast Trak LK, 26x2.0"", 120 TPI, tubeless ready aramid bead, dual compound
COCKPIT
SADDLE Specialized Body Geometry women's Jett, hollow Cr-Mo rails, 143mm
SEATPOST 2014 butted alloy, single bolt setback, 30.9mm
STEM 3D forged alloy, adjustable rise, 31.8mm clamp
HANDLEBARS Specialized XC low rise bar, 7050 butted alloy, 31.8mm, 640mm wide, 8 degree back sweep, 6 degree up
GRIPS Specialized waffle lock on grip
BRAKES
FRONT BRAKE Custom Avid Elixir CR SL, allloy backed semi-met pads, alloy Elixir CR lever w/ pad contact and reach adj. 160mm rotors
BRAKE LEVERS Custom Avid Elixir CR SL Hydraulic, carbon lever blade, tool-less adj. reach and pad contact
REAR BRAKE Custom Avid Elixir CR SL, allloy backed semi-met pads, alloy Elixir CR lever w/ pad contact and reach adj. S/M: 140mm rotors, L: 160mm
ACCESSORIES
PEDALS None
FRAMESET
HEADSET 1-1/8"" Threadless, 10mm insertion alloy cups, sealed cartridge bearing
SEAT BINDER 7050 hard annodized alloy collar w/ QR, 34.9mm clamp ID, black
FRAME Era FSR M5 alloy, women's geometry, fully manipulated frame w/ women's specific ORE DT/TT, sealed cartridge bearings, 100mm travel, replaceable derailleur hanger
* Specifications are subject to change without notice

Geometry

Geometry Chart

- Geometry

S M L
  S M L
Crank Length 170mm 170mm 175mm
Stem Length 75mm 75mm 90mm
Seatpost Length 350mm 350mm 350mm
Handlebar Width 640mm 640mm 640mm
Reach 386mm 405mm 433mm
Stack 548mm 566mm 575mm
Chainstay Length 425mm 425mm 425mm
Top Tube Length (Actual) 523mm 546mm 576mm
Ground-Top 879mm 897mm 906mm
Top Tube Length (Horizontal) 540mm 565mm 595mm
Head Tube Angle - Low Setting 70° 70° 70°
Standover Height 719mm 722mm 727mm
Head Tube Height 100mm 120mm 130mm
Wheel Base 1048mm 1074mm 1104mm
Seat Tube Angle (Actual) - Low Setting 74.2° 74.2° 74.2°
Seat Tube Length - Center to Top 406mm 432mm 470mm
Bottom Bracket Height - Low Setting 331mm 331mm 331mm
