Epic Marathon Carbon
$5,500.00
Part No.

Epic Marathon Carbon

$5,500.00
Part No.  22806
load-spinner
Epic Marathon Carbon
Overview
Technical Specifications
Geometry
Reviews
With a XC World Championship to its name and complete bike weights as low as 21.5 pounds, the Epic® is the lightest, most efficient and fastest performance cross-country bike available. An integrated approach to the design of all its critical components, along with an enhanced AFR inertia rear shock and Specialized/FOX Shox Mini Brain® damper, will no doubt make a full suspension convert out of any competition- hungry rider.
  • Race-ready Roval Control AL XC wheelset with oversized 28mm end caps is insanely durable, yet lightweight and prime for putting the hurt on every rider behind you
  • Avid Elixir R CR magnesium body brakes with tool-free reach adjust, alloy backed semi-metallic pads and carbon blades offer power-packed performance for speedy runs
  • S-Works The Captain 26 x 2.0" 2Bliss front tire works in concert with the S-Works Fast Trak LK rear tire to deliver exceptional traction, while minimizing rotating weight
  • Specialized and Fox blend their brains to develop the new FlowControl Mini Brain shock with Brain Fade adjust inertia valve, air spring and adjustable rebound for trophy-stockpiling performance
  • FACT IS-constructed 9m carbon frame with M5 alloy rear triangle and sealed cartridge bearing pivots delivers strength, rigidity and suppleness to create an uncompromising 100mm-travel Competitive XC bike
  • Specialized E100 FutureShock fork with 100mm of Brain-regulated travel and rebound adjust are supported by a carbon 1-1/8-1.5" crown-steerer assembly that balances smoothly with its Mini FlowControl rear

Technical Specifications

FRAMESET
SEAT BINDER 36.9mm clamp, one bolt for carbon frame/post
HEADSET 1 1/8"" - 1 1/2"" Threadless, Campy style upper and lower cartridge bearing.
FRAME FACT 9m carbon front triangle, IS construction, M5 aluminum rear triangle. sealed cartridge bearing pivots, 100mm travel, replaceable derailleur hanger
WHEELS
FRONT HUB Roval Control AL, alloy, oversize 28mm end caps
REAR HUB Roval Control AL with alloy freehub
INNER TUBES Ultralight presta valve
RIMS Roval Control AL, disc, 24mm
FRONT TIRE S-Works The Captain, 26x2.0"", 120 TPI, tubeless ready aramid bead, dual compound
REAR TIRE S-Works Fast Trak LK, 26x2.0"", 120 TPI, tubeless ready aramid bead, dual compound
DRIVETRAIN
BOTTOM BRACKET Custom Shimano BB-91, OS, press-in bearing
CHAIN SRAM PC-971, 9-speed w/Power Link
CRANKSET Shimano FC-M770 XT, 2pc., S: 170mm, others: 175mm
CASSETTE Shimano M770 XT, 9-speed, 11-34t
SHIFT LEVERS SRAM X-0, carbon/aluminum trigger
FRONT DERAILLEUR Shimano M770 XT, DMD, top swing, dual pull
CHAINRINGS 44A x 32A x 22S, 4-bolt, 104/64mm
REAR DERAILLEUR SRAM X-0, 9-speed, mid cage
COCKPIT
SADDLE Specialized Phenom SL, Ti rails, thin foam, S/M: 130mm, L/XL: 143mm
SEATPOST Thomson Elite Setback w/ 12 degree clamp, S/M: 367mm L/XL:410mm
GRIPS Specialized waffle lock on grip (S/M) Specialized Thick lock on grip (L/XL)
HANDLEBARS S-Works XC Carbon low-rise bar, uni-directional carbon, 31.8mm, 660mm wide, 8 degree back sweep, 6 degree up
STEM 3D forged alloy, adjustable rise, 31.8mm clamp
BRAKES
BRAKE LEVERS Custom Avid Elixir R CR MAG, magnesium body, carbon lever, tool-less reach adjust
FRONT BRAKE Custom Avid Elixir R CR MAG, alloy caliper, alloy backed semi-metallic pads, SS harware package,S/M: 160mm, L/XL: 185mm rotor
REAR BRAKE Custom Avid Elixir R CR MAG, alloy caliper, alloy backed semi-metallic pads, SS harware package, S/M: 140mm, L/XL: 160mm rotor
ACCESSORIES
PEDALS None
SUSPENSION
FORK Specialized Future Shock e100, inertia valve, 100mm travel, Brain Fade, external rebound adj., single sided air spring and damper, carbon 1-1/8"" to 1.5"" steerer
REAR SHOCK Fox/SBC remote Mini-Brain, inertia valve, w/ Brain fade adjust

Geometry

Geometry Chart

Epic - Geometry

S M L XL
  S M L XL
Stem Length 75mm 90mm 105mm 105mm
Crank Length 170mm 175mm 175mm 175mm
Seatpost Length 300mm 350mm 400mm 400mm
Handlebar Width 660mm 660mm 660mm 660mm
Reach 400mm 429mm 450mm 470mm
Stack 547mm 567mm 585mm 604mm
Chainstay Length 425mm 425mm 425mm 425mm
Top Tube Length (Actual) 547mm 580mm 603mm 633mm
Ground-Top 878mm 898mm 916mm 935mm
Top Tube Length (Horizontal) 554mm 589mm 615mm 641mm
Head Tube Angle - Low Setting 70° 70° 70° 70°
Standover Height 726mm 747mm 757mm 775mm
Wheel Base 1061mm 1098mm 1126mm 1153mm
Head Tube Height 126mm 144mm 154mm 184mm
Seat Tube Angle (Actual) - Low Setting 74° 74° 74° 74°
Seat Tube Length - Center to Top 394mm 444mm 483mm 533mm
Bottom Bracket Height - Low Setting 331mm 331mm 331mm 331mm
