Thinking hard about a hardtail race whip that’ll put others to shame? Not to worry,…
Frame
Specialized FACT 11m, Progressive XC Geometry, Rider-First Engineered™, threaded BB, 12x148mm rear spacing, internal cable routing
SWAT
SWAT EMT Cage-Mount Tool
Seat Binder
Specialized Alloy, 34.9mm, Titanium bolt
Saddle
Body Geometry Power Expert
SeatPost
S-Works FACT carbon, 10mm offset, 30.9mm
Tape
Specialized Trail Grips
Stem
Specialized XC, 3D-forged alloy, 4-bolt, 6-degree rise
Handlebars
S-Works Carbon XC Mini Rise, 6-degree upsweep, 8-degree backsweep, 10mm rise, 760mm, 31.8mm
Rims
Roval Control Carbon, 25mm internal width, Zero bead hook, Tubeless ready, 28h
Front Hub
DT Swiss 350, 15x110mm spacing, Torque caps, 6-bolt, 28h
Rear Hub
DT Swiss 350, Star Ratchet, SRAM XD driver body, 12mm thru-axle, 148mm spacing, 28h
Spokes
DT Swiss Competition Race
Front Tire
Fast Trak, Control casing, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.3"
Rear Tire
Fast Trak, Control casing, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.3"
Inner Tubes
Presta, 60mm valve
Fork
RockShox SID SL BRAIN, Top-Adjust Brain damper, Debon Air, 15x110mm, 44mm offset, 100mm Travel
Shift Levers
SRAM AXS Eagle Controller
Rear Derailleur
SRAM X01 Eagle AXS
Cassette
SRAM XG-1295 Eagle, 12-speed, 10-50t
Chain
SRAX X01 Eagle, 12-speed
Crankset
SRAM X1 carbon Eagle, Boost™ 148, DUB, 32T, SM: 170mm, M-XL 175mm
Bottom Bracket
SRAM DUB, BSA 73mm, Threaded
Front Brake
SRAM Level TLM, 2-piston caliper, hydraulic disc
Rear Brake
SRAM Level TLM, 2-piston caliper, hydraulic disc
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
S | M | L | XL | |
---|---|---|---|---|
Crank Length | 170mm | 175mm | 175mm | 175mm |
Handlebar Width | 760mm | 760mm | 760mm | 760mm |
Stem Length | 60mm | 70mm | 70mm | 70mm |
Saddle Width | 155mm | 143mm | 143mm | 143mm |
Seatpost Length | 350mm | 400mm | 400mm | 400mm |
Stack | 608mm | 608mm | 622mm | 636mm |
Reach | 405mm | 430mm | 455mm | 480mm |
Head Tube Length | 95mm | 95mm | 110mm | 125mm |
Head Tube Angle | 68.5° | 68.5° | 68.5° | 68.5° |
BB Height | 309mm | 309mm | 309mm | 309mm |
BB Drop | 63mm | 63mm | 63mm | 63mm |
Trail | 101mm | 101mm | 101mm | 101mm |
Fork Length, Full | 506mm | 506mm | 506mm | 506mm |
Fork Rake/Offset | 44mm | 44mm | 44mm | 44mm |
Front Center | 670mm | 695mm | 725mm | 755mm |
Chainstay Length | 430mm | 430mm | 430mm | 430mm |
Wheelbase | 1092mm | 1117mm | 1148mm | 1178mm |
Top Tube Length, Horizontal | 579mm | 604mm | 633mm | 662mm |
Bike Standover Height | 762mm | 792mm | 816mm | 847mm |
Seat Tube Length | 400mm | 430mm | 470mm | 520mm |
Seat Tube Angle | 74° | 74° | 74° | 74° |
