Enduro SX Frame
Overview
Technical Specifications
Geometry
Reviews
The Enduro FSR SX Frameset is purpose-built for dual slalom and slopestyle, meaning that it's made for catching air. And to make sure that you're going to carry blistering speed out the gate and throughout the entire course, we built the frame from M5 aluminum on our Slalom/4X racing, 26-inch geometry. Compared to an Enduro FSR 29, you can expect an even shorter chainstay length, top tube, and seat tube, as well as a much lower bottom bracket height. Combined, this creates a confident, snappy geo that's purpose-built to rail through corners at speed. And when paired with 135mm of travel at the rear end, we guarantee that you'll be sending it with confidence in no time.
  • Thomson alloy seatpost features one of the most durable constructions out there, without coming at the expense of a high overall weight.
  • M5 alloy has been paired with our Slalom/4X Racing Geometry to form a frame that's quite literally capable of everything. The material featured here is light, stiff, and durable, while the geometry, 142mm rear spacing, and 26-inch wheel size lend themselves perfectly to gate-style racing. You'll also find sealed cartridge bearing pivots to reduce maintenance over time.
  • Custom FOX FLOAT Factory CTD rear shock features AUTOSAG for easy set up, climb, trail, and descend settings for on-the-fly adjustment, and 135mm of travel for plush performance over any type of terrain.

Technical Specifications

FRAMESET
SEAT BINDER Specialized, 7050 alloy, single bolt, 34.9mm
HEADSET 1-1/8"" upper, 1-1/2"" lower, threadless, Campy style, cartridge bearings
FRAME M5 alloy, Trail 29 Geometry, internal cable routing, 142mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, front derailleur compatible w/ Taco Blade, 135mm travel
SUSPENSION
REAR SHOCK Custom FOX FLOAT Factory CTD, custom tune, Boost Valve, Kashima coating, 203x44.5mm
COCKPIT
SEATPOST Thomson, alloy, straight, 12-degree clamp

Geometry

Geometry Chart

Enduro - Geometry

  Short Long
Reach 424mm 446mm
Stack 559mm 559mm
Wheelbase 1102mm 1124mm
Bike Stand-Over Height 691mm 691mm
Head-Tube Length 120mm 120mm
Front-Center 684mm 706mm
Fork Rake/Offset 39mm 39mm
Head-Tube Angle 68° 68°
Trail 92mm 92mm
B-B Height 311mm 311mm
Chain-Stay Length 419mm 419mm
Fork Length (full) 475mm 475mm
Seat-Tube Angle 76° 76°
B-B Drop 21mm 21mm
Seat-Tube Length 345mm 356mm
Top-Tube Length (horizontal) 563mm 585mm
