Diverge Expert X1
$3,300.00
Part No.

Diverge Expert X1

$3,300.00
Part No.  107072
load-spinner
Diverge Expert X1
Overview
Technical Specifications
Geometry
Reviews
The Diverge Expert X1 excels where the road ends. With its unique bottom bracket height and front rake angle, the Diverge performs confidently and smoothly across any terrain. Meanwhile, the high-end FACT 10r carbon frame and fork provide both efficiency and comfort for long adventures in the saddle. Unique to the X1 is the simplicity and efficiency of the SRAM Force 1 drivetrain, which provides ample gearing options without the headache of front derailleur adjustments. The only limit to your exploration is how good your map is.
  • The SRAM Force 1 single-ring crankset is the ultimate in one-by simplicity, providing seamless, efficient power transfer without the worry of a front derailleur.
  • AXIS 4.0 Disc wheels provide plenty of control and performance in a bulletproof package, while the Roubaix Pro tires with Blackbelt protection keep flats at bay over rough terrain.
  • The Specialized FACT 10r carbon frame and fork combine the lightweight performance and compliance of our top-end carbon production methods with the vibration damping of Zertz inserts to smooth out even the harshest roads and provide confident and predictable handling.
  • The SRAM Force 1 11-speed rear derailleur is designed to work in perfect harmony with a one-by drivetrain, providing ample gearing options for varying terrain.

Technical Specifications

DRIVETRAIN
CHAIN SRAM PC-1170, 11-speed
BOTTOM BRACKET SRAM BB30
CRANKSET SRAM Force 1, 46T
SHIFT LEVERS SRAM Force, 11-speed, disc
CASSETTE SRAM XG-1150, 11-speed, 10-42t
REAR DERAILLEUR SRAM Force 1, 11-speed
COCKPIT
SADDLE Body Geometry Phenom Comp, hollow Cr-Mo rails, 143mm
TAPE Specialized Roubaix, w/ 2.5mm gel pads
SEATPOST Specialized CG-R, FACT carbon, single bolt, 27.2mm
STEM Specialized Comp Multi, 3D forged alloy, 4-bolt, 12-degree rise
HANDLEBARS Specialized Expert, shallow drop, alloy, 123mm drop, 75mm reach
WHEELS
REAR WHEEL AXIS 4.0 Disc SCS X1
INNER TUBES Standard, Presta valve
FRONT TIRE Specialized Roubaix Pro, 120TPI, folding bead, BlackBelt protection, Endurant casing, 700x30/32mm
REAR TIRE Specialized Roubaix Pro, 120TPI, folding bead, BlackBelt protection, Endurant casing, 700x30/32mm
FRONT WHEEL AXIS 4.0 Disc SCS X1
ACCESSORIES
PEDALS Nylon, loose ball bearings, w/ reflectors
FRAMESET
HEADSET 1-1/8 upper, 1-1/4"" lower, Campy style, crown race, 8mm carbon cone spacer, w/ 20mm of carbon spacers
SEAT BINDER Alloy, 31.6mm
FORK Specialized FACT carbon w/ Zertz, tapered
FRAME Specialized FACT 10r carbon, tapered head tube, OSBB

Geometry

Geometry Chart

Diverge - Geometry

  49 52 54 56 58 61 64
Stem Length 75mm 90mm 100mm 100mm 110mm 110mm 120mm
Crank Length 170mm 170mm 172.5mm 172.5mm 175mm 175mm 177.5mm
Seatpost Length 300mm 300mm 350mm 350mm 350mm 350mm 350mm
Handlebar Width 400mm 420mm 420mm 420mm 440mm 440mm 440mm
Reach 378mm 378mm 380mm 387mm 391mm 398mm 409mm
Stack 526mm 544mm 565mm 590mm 622mm 643mm 658mm
Wheelbase 989mm 995mm 1001mm 1011mm 1029mm 1039mm 1054mm
Bike Stand-Over Height 714mm 740mm 764mm 785mm 829mm 851mm 873.5mm
Head-Tube Length 100mm 120mm 140mm 165mm 200mm 220mm 235mm
Front-Center 589mm 596mm 597mm 608mm 622mm 630mm 645mm
Fork Rake/Offset 51mm 51mm 51mm 51mm 51mm 51mm 51mm
Head-Tube Angle 71.25° 71.25° 72° 72.5° 72.5° 73° 73°
Trail 64mm 64mm 59mm 56mm 56mm 53mm 53mm
B-B Height 270mm 270mm 271.5mm 271.5mm 273mm 273mm 273mm
Chain-Stay Length 412mm 412mm 415mm 415mm 418mm 420mm 420mm
Fork Length (full) 390mm 390mm 390mm 390mm 390mm 390mm 390mm
Seat-Tube Angle 75.5° 74° 73.5° 73.25° 73° 72.5° 72.5°
B-B Drop 77mm 77mm 76mm 76mm 74mm 74mm 74mm
Seat-Tube Length 418mm 447mm 466mm 485mm 530mm 555mm 590mm
Top-Tube Length (horizontal) 514mm 534mm 547mm 565mm 581mm 601mm 616mm
