Whether you're just getting into cyclocross or exploring the road less traveled, the CruX E5 is the perfect bike to help you get out there and get after it. With its premium alloy frame and mechanical disc brakes, you'll get pro-level performance at an even better value.
  • With a semi-compact race design and an E5 Premium Aluminum construction, the frame provides plenty of stiffness and agility for the tight turns and accelerations of cyclocross.
  • The Specialized FACT carbon fork increases steering response and rider input—no matter the terrain.
  • The FSA Gossamer Pro crankset is renowned for its bulletproof construction and reliable performance.

Technical Specifications

FRAMESET
SEAT BINDER Alloy, 31.8mm
HEADSET 1-1/8"" upper, 1-3/8” lower, steel bearings, 20mm alloy cone spacer, w/ 20mm spacers
FORK Specialized FACT carbon
FRAME Specialized E5 Premium Aluminum, fully-manipulated tubing, semi-compact race design, shaped top tube, 1-3/8"" lower bearing, internal cable routing, integrated headset, OSBB
DRIVETRAIN
CHAIN KMC X9, 9-speed, w/ reusable MissingLink
CRANKSET FSA Gossamer Pro, BB30, compact, 46/36T
CASSETTE Sunrace, 9-speed
SHIFT LEVERS Shimano Sora STI
FRONT DERAILLEUR Shimano Sora, braze-on
REAR DERAILLEUR Shimano Sora
COCKPIT
SADDLE Body Geometry Toupé Sport, steel rails, 143mm
TAPE Specialized CX Pro Gel
SEATPOST Specialized Sport, alloy, 2-bolt, 27.2mm
HANDLEBARS Specialized Comp, shallow drop, alloy, 125mm drop, 70mm reach
STEM Specialized Comp Multi, 3D forged alloy, 4-bolt, 12-degree rise
BRAKES
FRONT BRAKE Tektro Spyre, mechanical disc, dual pivot, 160mm rotor
REAR BRAKE Tektro Spyre, mechanical disc, dual pivot, 140mm rotor
ACCESSORIES
PEDALS Nylon, loose ball bearings, w/ reflectors
WHEELS
REAR WHEEL AXIS Classic Disc, wide
INNER TUBES Standard, Presta valve
FRONT TIRE Specialized Tracer Sport, 60TPI, wire bead, 700x33mm
REAR TIRE Specialized Tracer Sport, 60TPI, wire bead, 700x33mm
FRONT WHEEL AXIS Classic Disc, wide

Geometry

Geometry Chart

CruX - Geometry

  46 49 52 54 56 58 61
Stem Length 75mm 75mm 90mm 100mm 100mm 110mm 110mm
Crank Length 170mm 170mm 170mm 172.5mm 172.5mm 175mm 175mm
Seatpost Length 300mm 300mm 300mm 350mm 350mm 350mm 350mm
Handlebar Width 400mm 400mm 420mm 420mm 420mm 440mm 440mm
Reach 366mm 370mm 375mm 379mm 384mm 387mm 392mm
Stack 522mm 540mm 554mm 566mm 583mm 597mm 618mm
Wheelbase 1008mm 1009mm 1009mm 1016mm 1022mm 1025mm 1031mm
Bike Stand-Over Height 725mm 761mm 773mm 790mm 807mm 825mm 849mm
Head-Tube Length 100mm 115mm 125mm 140mm 155mm 170mm 190mm
Front-Center 593mm 595mm 595mm 601mm 606mm 609mm 615mm
Fork Rake/Offset 51mm 51mm 51mm 49mm 49mm 49mm 49mm
Head-Tube Angle 69.5° 70.5° 71.5° 71.5° 72° 72.5° 73°
Trail 76mm 70mm 63mm 65mm 62mm 59mm 56mm
B-B Height 279mm 279mm 279mm 281mm 281mm 283mm 283mm
Chain-Stay Length 425mm 425mm 425mm 425mm 425mm 425mm 425mm
Fork Length (full) 400mm 400mm 400mm 400mm 400mm 400mm 400mm
Seat-Tube Angle 75.5° 75.5° 74° 73.5° 73.25° 73° 72.5°
B-B Drop 71mm 71mm 71mm 69mm 69mm 67mm 67mm
Seat-Tube Length 460mm 490mm 520mm 540mm 560mm 580mm 610mm
Top-Tube Length (horizontal) 501mm 510mm 534mm 547mm 559mm 569mm 587mm
