Crosstrail Comp Disc
$990.00
Part No.

Crosstrail Comp Disc

$990.00
Part No.  23575
load-spinner
Crosstrail Comp Disc
Overview
Technical Specifications
Geometry
Reviews
Shimano disc brakes and 9-speed drivetrain make an already versatile bike even more capable and fun to ride.
  • Double-walled, eyeletted 700c rims are durable and low maintenance
  • BG Contour MTB grips are anatomically designed to keep hands pain-free and loose on long rides
  • Shimano hydraulic disc brakes/levers assure solid, worry-free braking performance under any conditions
  • BG Crosstrail saddle has front/rear bumpers for on and off-road durability and ample padding for comfort
  • 75mm-travel coil-sprung fork with hydraulic lockout and magnesium lowers for greater adjustability and lighter weight
  • Smooth-welded A1 Premium Aluminum frame for lightweight confidence on any surface, with fender/rack braze-ons for versatility
  • Shimano Alivio 9-speed rear derailleur and Rapidfire trigger shifters have a reputation for high quality and reliable performance

Technical Specifications

FRAMESET
SEAT BINDER Forged alloy
HEADSET Ahead, loose ball, Cr-Mo cups, 25.5mm stack
FRAME Specialized A1 Premium Aluminium w/ smooth welding, w/ fender and rack braze-ons, forged drop outs w/ kickstand mount
WHEELS
FRONT HUB Machined disc side flange and mount, sealed bearings, dual lock nuts w/ 19mm contact side
REAR HUB Machined disc mount & flanges, doubel sealed, ground race, dual lock nuts w/ 19mm contact side
INNER TUBES Schraeder valve
SPOKES 2mm (14g) stainless
RIMS Alloy double wall, pinned, disc mount w/ eyelets, 32h
FRONT TIRE Specialized Borough XC Sport, 700x45c, 60TPI, wire bead
REAR TIRE Specialized Borough XC Sport, 700x45c, 60TPI, wire bead
DRIVETRAIN
BOTTOM BRACKET Octalink spline 68mm
CHAIN KMC X9 w/ reusable Missing Link
CRANKSET SR SunTour Octalink spline, replaceable rings, w/composite anti-jump disc
CASSETTE Shimano 9-speed
SHIFT LEVERS Shimano Alivio, 9-speed rapid-fire
FRONT DERAILLEUR Shimano Alivio, 31.8mm clamp, top swing, dual pull
CHAINRINGS 48A x 36S x 26T w/ chainguard
REAR DERAILLEUR Shimano Alivio, 9-speed
COCKPIT
SADDLE Specialized XC, Body Geometry, 143mm width, front and rear bumpers
SEATPOST Alloy, 2-bolt head, 12.5mm offset, 27.2mm
GRIPS BG Contour, closed end, 132mm
HANDLEBARS Butted alloy riser bar, 31.8mm, 25mm rise, 8 degree back sweep, 6 degree up
STEM 3D forged alloy, 6 degree rise, 31.8mm clamp
BRAKES
BRAKE LEVERS Hydraulic lever, included w/brake
FRONT BRAKE Shimano BRM-445 hydraulic disc brake w/ 160mm rotors
REAR BRAKE Shimano BRM-445 hydraulic disc brake w/ 160mm rotors
ACCESSORIES
PEDALS Super light alloy, loose ball, w/ reflectors
SUSPENSION
FORK SR SunTour SF11-NRX-D-LO, mag. lower, Cr-Mo stanchions, hydraulic LO
REAR SHOCK ---

Geometry

Geometry Chart

CrossTrail - Geometry

S M L XL XXL
  S M L XL XXL
Reach 405mm 417mm 425mm 431mm 429mm
Stack 606mm 618mm 627mm 639mm 653mm
Chainstay Length 459mm 459mm 459mm 459mm 459mm
Top Tube Length (Actual) 569mm 578mm 585mm 597mm 612mm
Ground-Top 898mm 910mm 919mm 931mm 945mm
Top Tube Length (Horizontal) 579mm 594mm 605mm 620mm 635mm
Head Tube Angle - Low Setting 69.5° 70° 70° 70.5° 70.5°
Standover Height 744mm 779mm 804mm 838mm 869mm
Wheel Base 1111mm 1121mm 1133mm 1138mm 1141mm
Head Tube Height 90mm 100mm 110mm 120mm 135mm
Seat Tube Angle (Actual) - Low Setting 74° 74° 74° 73.5° 72.5°
Seat Tube Length - Center to Top 394mm 445mm 483mm 533mm 584mm
Bottom Bracket Height - Low Setting 292mm 292mm 292mm 292mm 292mm
