Fun and fast, plush and stable, the Crossroads Sport is a great way to navigate the neighborhood and blaze the bike path, 21 speeds and 700c wheels will keep the pedaling efficient on any terrain.
  • A1 Premium Aluminum 700c frame with hybrid geometry for an upright, stable riding position and low standover for bike path bliss, includes integrated kickstand mount
  • 63mm-travel suspension fork with preload adjustment offers a smoother, more comfortable ride
  • Durable, double-walled 700c alloy rims roll fast and can handle varied terrain
  • Smooth-rolling Hemisphere 700x38c tires with puncture protection to eliminate flats and a semi-connected tread pattern for traction and control on pavement or gravel
  • Shimano triple crankset with chainguard gives you precise, hassle-free shifting and efficient gearing for varied terrain
  • Riser bar creates a stable and comfortable position
  • BG Comfort grips alleviate hand pain and tingling fingers
  • Comfort Plus saddle uses springs, dual-density foam, and a wide platform for over-the-top comfort, while a suspension seatpost takes the edge of bumpy roads

Technical Specifications

DRIVETRAIN
BOTTOM BRACKET Cartridge bearing, square spindle w/ crank stop right side, capless bolts
CHAIN KMC Z7
CRANKSET Shimano FC-M131, w/ chainguard
SHIFT LEVERS Shimano Revo twist, 7-speed
FRONT DERAILLEUR Shimano FD-TX51, 31.8mm clamp, top swing, dual pull
CASSETTE Shimano Mega Range, 7-speed, 14-34t
CHAINRINGS 48/38/28, w/ chainguard
REAR DERAILLEUR Shimano Altus, 7-speed
SUSPENSION
REAR SHOCK ---
WHEELS
FRONT HUB Double sealed, ground race, dual lock nuts w/ 17mm contact side, 5mm QR
REAR WHEEL ---
REAR HUB Double-sealed, ground race, freewheel type, QR
INNER TUBES Schrader valve
SPOKES 2mm (14g) stainless
RIMS Alloy double-wall
FRONT TIRE Specialized Hemisphere w/ Flak Jacket, 26 TPI, 700x38c
REAR TIRE Specialized Hemisphere w/ Flak Jacket, 26 TPI, 700x38c
FRONT WHEEL ---
COCKPIT
SADDLE Comfort Plus, dual-density foam, springs
TAPE Body Geometry Comfort, closed end, 92mm
SEATPOST A-1 Suspension Seatpost, alloy, 27.2mm w/ 3.8mm spring
HANDLEBARS Comfort riser bar, 60mm rise, 15-degree back sweep. 25.4
STEM Ground Control adjustable rise, alloy head/quill, 2-bolt, 25.4mm clamp
BRAKES
FRONT BRAKE Alloy linear pull, 1pc. pad
BRAKE LEVERS Alloy 4-finger, Kraton lever for twist shifter
REAR BRAKE Alloy linear pull, 1pc. pad
ACCESSORIES
PEDALS Comfort Pedal, composite body w/rubber top, sealed loose ball
FRAMESET
HEADSET 1-1/8"" threaded, sealed loose ball bearings
SEAT BINDER Forged alloy w/ QR
FORK SR Suntour NEX-4110V2, alloy lower, Hi-Ten stanchions and steerer, coil/Mcu spring, preload adjust, 63mm travel
FRAME Specialized A1 Premium Aluminum, 700c Hybrid geometry, formed tubes, integrated kickstand mount, replaceable hanger

Geometry

Geometry Chart

- Geometry

  SM MD LG XL
Wheelbase 1102mm 1118mm 1140mm 1156mm
Seat-Tube Length, B-B Center to Top 370mm 425mm 480mm 535mm
Head-Tube Length 130mm 150mm 170mm 190mm
Top-Tube Length, Horizontal 590mm 605mm 620mm 635mm
Front-Center 641mm 657mm 679mm 695mm
Head-Tube Angle 69.5° 69.5° 69° 69°
Stand-Over Height 724mm 759mm 801mm 842mm
Fork Rake 40mm 40mm 40mm 40mm
Trail 89mm 89mm 93mm 93mm
Chain-Stay Length 470mm 470mm 470mm 470mm
Seat-Tube Angle 72° 72° 72° 72°
B-B Drop 70mm 70mm 70mm 70mm
Seat-Post Length 0mm 0mm 0mm 0mm
