Camber Grom
$2,300.00
Part No.

Camber Grom

$2,300.00
Part No.  106249
load-spinner
Camber Grom
Overview
Technical Specifications
Geometry
Reviews
When it's time for Junior to start getting rad, get the little guy on the Camber Grom. It's designed to blend all of the trail bike characteristics that you want with the XC climbing ability that you need. This way, there's nothing that your little rider won't be able to cover on the trail. And to make sure of it, this Camber comes equipped with 24-inch wheels, while the frame has clearance to easily upgrade to 26-inch wheels when they start growing. Along these lines, the frame is built with a focus on ultra-low standovers, short tube lengths, and playful handling. And with plenty of suspension travel, a durable build kit, and a tough as nails M5 alloy frame, your dream family trail day is on its way to becoming a reality.
  • Tektro Gemini Comp hydraulic disc brakes put out plenty of stopping power and intuitive modulation, all while retaining a comfortable, ergonomic lever design.
  • M5 alloy frame is built for confident handling, control, and efficiency. We also included 135mm rear spacing for easy wheel compatibility, a SRAM front derailleur adapter for wider gearing options, and a threaded bottom bracket that's a breeze to maintain and a blast to ride. And while this bike comes with 24-inch wheels, there's plenty of room for 26-inch wheels once the little ones get growing.
  • Connected with our FSR Concentric Linkage, a FOX FLOAT Performance DPS rear shock provides 110mm of active and independent travel over any type of terrain.
  • A RockShox Recon Gold fork delivers 110 of plush, air-sprung travel, plus stiff stanchions and a TurnKey lockout for the climbs.
  • 24x2.0" Maxxis Snyper tires are supple, durable, and loaded with dependable traction over any kind of terrain.

Technical Specifications

FRAMESET
SEAT BINDER Alloy, 34.9mm
HEADSET 1-1/8"" upper, 1-1/2"" lower, threadless, Campy style, cartridge bearings
FRAME M5 alloy, 26 geometry, threaded BB, tapered head tube, 135mm rear spacing, DMD mount, SRAM FD adaptor, disc mount, 110mm travel
WHEELS
FRONT HUB Specialized, Hi Lo disc, OS28 end caps, sealed cartridge bearings, QR, 32H
REAR HUB QR 135mm
INNER TUBES Standard, Presta valve
SPOKES Stainless, 14g
RIMS Alex, 24"", 32h
FRONT TIRE Maxxis Snyper, 24x2.0"", 60TPI, wire bead
REAR TIRE Maxxis Snyper, 24x2.0"", 60TPI, wire bead
DRIVETRAIN
BOTTOM BRACKET SRAM GXP XR, 73mm
CHAIN SRAM PC-1031, 10-speed, w/ PowerLink, nickel finish
CRANKSET SRAM GX-1000, GXP spindle, 155mm arms, 32T X-Sync ring, 104mm BCD spider,
CASSETTE SRAM PG-1020, 10-speed, 11-36t
SHIFT LEVERS SRAM X5, 10-speed, aluminum trigger, w/ Matchmaker clamp
REAR DERAILLEUR SRAM X7 Type 2, 10-speed, mid cage
COCKPIT
SADDLE Specialized Youth, steel rails
SEATPOST Specialized, alloy, single bolt, 30.9mm
GRIPS Specialized Sip Grip, lock-on, half-waffle, regular thickness
HANDLEBARS Specialized, 7050 alloy, 8-backsweep, 6-upsweep, 10mm rise, 750mm width, 31.8mm clamp
STEM Specialized Trail, forged alloy, 4-bolt, 8-degree rise
BRAKES
BRAKE LEVERS Tektro Gemini Comp, hydraulic, reach adjust
FRONT BRAKE Tektro Gemini Comp, hydraulic disc, resin pad, 180/200mm rotor
REAR BRAKE Tektro Gemini Comp, hydraulic disc, resin pad, 180mm rotor
ACCESSORIES
PEDALS Nylon platform w/reflectors
SUSPENSION
FORK RockShox Recon Gold, Solo Air spring, 110mm travel, rebound adjust, TurnKey lockout, tapered alloy steerer, 42mm offset, 9mm QR dropout
REAR SHOCK FOX FLOAT Performance DPS, 3-position compression adjust, rebound adjust, 6.5x1.358""

Geometry

Geometry Chart

Camber - Geometry

  Grom
Stem Length 60mm
Crank Length 155mm
Seatpost Length 350mm
Handlebar Width 700mm
Reach 388mm
Stack 547mm
Wheelbase 1066mm
Bike Stand-Over Height 621mm
Head-Tube Length 110mm
Front-Center 643mm
Fork Rake/Offset 40mm
Head-Tube Angle 68.5°
Trail 83mm
B-B Height 291mm
Chain-Stay Length 420mm
Fork Length (full) 480mm
Seat-Tube Angle 74.5°
B-B Drop 30mm
Seat-Tube Length 394mm
Top-Tube Length (horizontal) 540mm
