The Camber Expert hits a sweet spot with its outstanding suspension components, drivetrain, and sticky rubber.
  • Shimano hollow-forged 10-speed triple crankset with Octalink-splined BB interface makes for a lightweight and stiff power transfer
  • Shimano Deore XT Shadow rear derailleur delivers top-of-the-line shifting performance in a low-profile design for maximum clearance
  • 120mm-travel M4 alloy FSR frame with new suspension design and sealed cartridge bearing pivots for confident handling and smooth trail performance
  • Trusted RockShox Reba TK 120mm-travel fork with alloy steerer, Turn Key damper, adjustable rebound and lockout for consistent, lightweight performance
  • Custom Avid Elixir 5 SL hydraulic disc brakes/levers with G3 Clean Sweep rotors and alloy-backed organic pads for maximum stopping power and tool-free reach adjust
  • Custom Fox Triad II rear shock tackles all trail conditions with its 3-position, on-the-fly adjuster that includes lockout, fully open, and efficient ProPedal settings

Technical Specifications

FRAMESET
SEAT BINDER 34.9mm clamp ID, alloy collar w/ QR, black
HEADSET 1 1/8"" upper and lower campy style cartridge bearings for integrated alloy HT
FRAME M4 hydroformed tubing, sealed cartridge bearing pivots, disc only, Command Post routing, replaceable deraileur hanger, bolt on cable guides, 120mm travel
WHEELS
FRONT HUB Specialized Hi Lo disc, laser-etched logo, OS 28 end caps, sealed cartridge bearing, RWS, 28h
REAR HUB Specialized Hi Lo disc, lasere-etched logo, double sealed cartridge bearing, QR, 32h
INNER TUBES Ultralight presta valve
SPOKES 1.8mm (15g) stainless
RIMS Custom DT Swiss 445D, alloy disc, double wall, pin joint, eyelets, 24mm, 28/32h
FRONT TIRE S-Works ""The Captain"", 120 TPI, 2Bliss ready aramid bead, dual compound, 26x2.0""
REAR TIRE Specialized ""The Captain"" Control, 60 TPI, 2Bliss ready aramid bead, dual compound, 26x2.0""
DRIVETRAIN
BOTTOM BRACKET Shimano BB-ES25, Octalink spline, cartridge bearing
CHAIN KMC X10, 10-speed, w/ reuseable Missing Link, nickel plates
CRANKSET Shimano FC-M552, Hollowtech, 10-speed triple, replaceable rings, S: 170mm, others: 175mm
CASSETTE Shimano HG81, 10-speed, 11-36t
SHIFT LEVERS Shimano SL-M660-10R SLX, 10-speed, trigger
FRONT DERAILLEUR Shimano FD-M660-10E SLX, 10-speed, E-type for DMD, top swing, bottom pull
CHAINRINGS 42A x 32A x 24S
REAR DERAILLEUR Shimano RD-M772 Deore XT Shadow, 10-speed, long cage
COCKPIT
SADDLE Specialized BG Henge Comp, hollow Cr-Mo rails, 143mm width
SEATPOST 6061 alloy, 2-bolt micro adjust, setback head, 30.9mm, S/M:350mm, others:400mm
GRIPS Specialized lock-on, S/M: Grappler, Other: Rocca
HANDLEBARS Specialized XC low-rise bar, 2014 butted alloy, 680mm wide, 8 degree back sweep, 6 degree up, 31.8mm
STEM Specialized XC, 3D forged alloy, 4-bolt, 31.8mm clamp, adjustable rise
BRAKES
BRAKE LEVERS Avid Elixir 5 hydraulic
FRONT BRAKE Custom Avid Elixir 5 SL, hydraulic disc, alloy backed organic pads, G3 Clean Sweep rotor, S/M: 185mm, L/XL: 203mm
REAR BRAKE Custom Avid Elixir 5 SL, hydraulic disc, alloy backed organic pads, G3 Clean Sweep rotor, S/M: 160mm, L/XL: 185mm
ACCESSORIES
PEDALS Resin Test Ride Pedals with toe clips, CEN std.
SUSPENSION
FORK Custom RockShox Reba TK, Turn Key damper, Solo Air, alloy steerer, rebound adj. w/ LO, disc only, 120mm travel
REAR SHOCK Custom Fox Triad II for Specialized, custom on-the-fly 3-position switch 1) lock out 2) Open 3) ProPedal, rebound adj., 7.875x2.0""

Geometry

Geometry Chart

Camber - Geometry

S M L XL
  S M L XL
Stem Length 75mm 90mm 105mm 105mm
Crank Length 170mm 175mm 175mm 175mm
Seatpost Length 350mm 350mm 400mm 400mm
Handlebar Width 680mm 680mm 680mm 680mm
Reach 401mm 429mm 462mm 479mm
Stack 561mm 579mm 589mm 598mm
Chainstay Length 420mm 420mm 420mm 420mm
Top Tube Length (Actual) 531mm 561mm 590mm 608mm
Ground-Top 896mm 914mm 924mm 933mm
Top Tube Length (Horizontal) 556mm 590mm 625mm 645mm
Head Tube Angle - Low Setting 68.5° 68.5° 68.5° 68.5°
Standover Height 744mm 750mm 764mm 769mm
Wheel Base 1082mm 1118mm 1154mm 1175mm
Head Tube Height 120mm 140mm 150mm 160mm
Seat Tube Angle (Actual) - Low Setting 71° 71° 71° 71°
Seat Tube Length - Center to Top 394mm 445mm 483mm 534mm
Seat Tube Angle (Effective) - Low Setting 74.5° 74.5° 74.5° 74.5°
Bottom Bracket Height - Low Setting 335mm 335mm 335mm 335mm
