Improved front suspension, lighter weight, and wider gearing take the Ariel Sport a step (and a few miles) farther.
  • Specialized Borough XC Sport 700c tires roll fast, yet have enough bite for the trail
  • Triple crankset has all the gears you need for varied terrain, with Octalink-splined BB for added stiffness
  • Women's-specific BG Contour MTB grips are anatomically designed to keep hands pain-free and loose on long rides
  • Body Geometry Women's Riva MTB saddle combines generous padding and durable scuff guards for all-day performance and comfort
  • A1 Premium Aluminum frame with women's recreational geometry with lower standover for lightweight confidence and fender/rack braze-ons for versatility

Technical Specifications

DRIVETRAIN
CHAIN KMC Z8 w/ reusable Missing Link
BOTTOM BRACKET Octalink spline 68mm
CRANKSET SR SunTour Octalink spline, replaceable rings, w/composite anti-jump disc
FRONT DERAILLEUR Shimano FD-M191, 31.8mm clamp, top swing, dual pull
SHIFT LEVERS Shimano, SL-M310, 8-speed rapid fire
CASSETTE SRAM 8-speed, 11-32t
CHAINRINGS 48 x 38 x 28T w/ chainguard
REAR DERAILLEUR Shimano Acera, 8-speed
SUSPENSION
FORK SR SunTour SF11-NVX-MLO, alloy lower, 75mm travel, 28mm stanchion, coil spring, mech. LO
REAR SHOCK ---
WHEELS
FRONT HUB Double sealed, ground race, dual lock nuts w/ 17mm contact side, 5mm QR
REAR HUB Double sealed, ground race, dual lock nuts w/ 19mm contact side, 5mm QR
INNER TUBES Schraeder valve
SPOKES 2mm (14g) stainless
FRONT TIRE Specialized Borough XC Sport, 700x45c, 60TPI, wire bead
RIMS Alloy double wall, machined sidewalls, pinned, 32h
REAR TIRE Specialized Borough XC Sport, 700x45c, 60TPI, wire bead
COCKPIT
SADDLE Body Geometry Women's Riva MTB, 155mm width
SEATPOST Alloy, 2-bolt head, 12.5mm offset, 27.2mm
STEM Melt-forged alloy, 20 degree rise, 25.4mm clamp
HANDLEBARS Alloy riser bar, 25.4mm, 25mm rise, 8 degree back sweep, 6 degree up
GRIPS BG Contour, women's grip
BRAKES
FRONT BRAKE Die cast, alloy ""V"" brake, 60mm 1pc. pad
BRAKE LEVERS ""V""-brake, Linear pull
REAR BRAKE Die cast, alloy ""V"" brake, 60mm 1pc. pad
ACCESSORIES
PEDALS Composite plastic body, loose ball w/ reflectors
FRAMESET
HEADSET Ahead, loose ball, Cr-Mo cups, 25.5mm stack
SEAT BINDER Forged alloy
FRAME Specialized A1 Premium Aluminium w/ smooth welding, fender and rack braze-ons, forged drop outs and kickstand mount

Geometry

Geometry Chart

Ariel - Geometry

XS S M L
  XS S M L
Reach 363mm 383mm 400mm 418mm
Stack 618mm 618mm 627mm 637mm
Chainstay Length 459mm 459mm 459mm 459mm
Top Tube Length (Actual) 551mm 560mm 568mm 581mm
Ground-Top 910mm 910mm 920mm 929mm
Top Tube Length (Horizontal) 540mm 560mm 580mm 600mm
Head Tube Angle - Low Setting 70° 70° 70° 70°
Standover Height 662mm 682mm 720mm 754mm
Wheel Base 1068mm 1088mm 1109mm 1129mm
Head Tube Height 100mm 100mm 110mm 120mm
Seat Tube Angle (Actual) - Low Setting 74° 74° 74° 74°
Seat Tube Length - Center to Top 330mm 381mm 432mm 482mm
Bottom Bracket Height - Low Setting 292mm 292mm 292mm 292mm
