Get to the race course or the fast club ride on an Amira Pro that you spec'd yourself.
  • FACT full carbon monocoque fork with a tapered 1-1/8" to 1-3/8" headset for strength and precision steering
  • FACT carbon Pave seatpost uses a Zertz insert to minimize road vibrations for greater comfort but remains stiff and efficient
  • Amira FACT IS 9r carbon frame uses women's race-inspired geometry and carbon lay-up, with integrated, tapered head tube, to create a light, stiff and fast ride

Technical Specifications

COCKPIT
SEATPOST Specialized Pro, FACT carbon w/ Zertz insert
FRAMESET
HEADSET 1-1/8"" upper and 1-3/8"" lower Cr-Mo cartridge bearings w/ 20mm carbon cone spacer and 20mm of carbon spacers
SEAT BINDER Forged alloy, 32.6mm
FORK S-Works FACT carbon full monocoque, 1-1/8"" to 1-3/8"" tapered steerer
FRAME S-Works FACT 9r carbon, FACT IS construction, 1-1/8"" to 1-3/8"" HT, women's race geometry, threaded BB

Geometry

Geometry Chart

- Geometry

  44 48 51 54 56
Crank Length 167.5mm 167.5mm 170mm 170mm 172.5mm
Stem Length 75mm 75mm 90mm 100mm 100mm
Handle-Bar Width 360mm 380mm 400mm 400mm 420mm
Wheelbase 969mm 973mm 976mm 982mm 993mm
Seat-Tube Length, B-B Center to Top 390mm 420mm 450mm 480mm 495mm
Head-Tube Length 105mm 115mm 125mm 145mm 165mm
Top-Tube Length, Horizontal 498mm 506mm 518mm 537mm 548mm
Front-Center 576mm 579mm 582mm 588mm 595mm
Head-Tube Angle 70.5° 71.25° 72° 72° 72°
Stand-Over Height 692mm 718mm 735mm 758mm 777mm
Fork Rake 51mm 51mm 49mm 49mm 49mm
Trail 66mm 62mm 59mm 59mm 59mm
Chain-Stay Length 405mm 405mm 405mm 405mm 408mm
Seat-Tube Angle 76° 75.75° 75.5° 74° 73.5°
B-B Drop 73mm 73mm 73mm 73mm 71.5mm
Seat-Post Length 300mm 300mm 350mm 350mm 350mm
