Allez Sprint Frameset

2021 Allez Sprint Frameset

We created the all-new Allez Sprint by cannibalizing the Tarmac SL7. We tore the Tarmac apart, and rebuilt it from alloy with our Smartweld technology. We leveraged every innovation and insight learned during its development to create the all-new Allez Sprint. Whether chasing a National title or attacking your buddies 15 minutes into an “easy” Sunday spin, we won’t be offended if you mistake the Allez for a Tarmac SL7. Some may call it a carbon copy, we call it the World’s First Alloy Super Bike

Technical Specifications

FORK

Fork

FACT Carbon, 12x100mm thru-axle, flat-mount disc

COCKPIT

SeatPost

2021 S-Works Tarmac Carbon seat post, FACT Carbon, Di2 Compatible, 20mm offset

FRAMESET

Frame

Specialized E5 Premium Aluminum Disc frame with D'Aluisio Smartweld Sprint Technology, hydroformed aluminum tubing, tapered head tube, fully internally routed cables, threaded BB

* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.

Geometry

495254565861
Seatpost Length300mm300mm300mm300mm380mm380mm
Stack508mm520mm537mm558mm584mm605mm
Reach378mm383mm387mm398mm405mm411mm
Head Tube Length105mm115mm133mm153mm180mm200mm
Head Tube Angle71.75°72.5°73°73.5°73.5°74°
BB Height266mm266mm268mm268mm268mm268mm
BB Drop74mm74mm72mm72mm72mm72mm
Trail63mm58mm58mm55mm55mm52mm
Fork Length, Full366mm366mm366mm366mm366mm366mm
Fork Rake/Offset47mm47mm44mm44mm44mm44mm
Front Center575mm578mm580mm592mm607mm614mm
Chainstay Length410mm410mm410mm410mm410mm410mm
Wheelbase974mm976mm979mm992mm1006mm1013mm
Top Tube Length, Horizontal509mm532mm541mm563mm578mm596mm
Bike Standover Height735mm755mm765mm795mm815mm835mm
Seat Tube Length470mm495mm510mm530mm550mm570mm
Seat Tube Angle75.5°74°74°73.5°73.5°73°
Geometry
VOTED “BEST BRAND”—AGAIN

2022 Gran Fondo Awards

The riders have spoken. We are proud to announce that Specialized was crowned #1 again for best drop bar bike brand in the prestigious Gran Fondo Best Brand Awards for 2022. When we focus on what our riders want the most, it makes sense that our bikes are loved year after year.

Aero is Everything

We leveraged every innovation and insight learned during the Tarmac SL7’s time in the Win Tunnel to make the new Allez Sprint 41 seconds faster over 40km than the previous Allez Sprint.

Smartweld

Smartweld helps us deliver the new Allez Sprint’s aerodynamics, power transfer, and handling—it’s our unique process for stronger, more integrated welds in the best possible position to create performance and durability.

Allez, LA!

A two-decade-long collaboration with the best riders in the world has pushed our engineering team farther than we ever thought possible, so far in fact that the new Tarmac SL7 redefines the modern race bike.

The New Allez Sprint
The New Allez Sprint
