Allez Sport Triple

Borrowing technology from the World Championship winning Tarmac, the Allez® utilizes a bowed top tube, oversized alloy construction and performance components to deliver a fast and efficient ride that looks and feels like a top-end racing bike, without the hefty pricetag.

Technical Specifications

FRAMESET

FRAME

Specialized Allez A1 Premium aluminum, fully manipulated tubing, smooth weld compact race design, integrated headset

FORK

Allez carbon, carbon fiber legs, aluminum crown and steerer

HEADSET

Cage bearings integrated w/ headset, 20mm of spacers w/ top cap

SEAT BINDER

Alloy, 31.8mm

WHEELS

RIMS

Alex S500, aluminum, sleeve joint, CNC machined sidewalls

FRONT HUB

Forged aluminum, 32h, sealed ball bearings, QR

REAR HUB

Forged aluminum, 32h, double sealed ball bearings, cassette, QR

SPOKES

Stainless 14g

FRONT TIRE

Specialized Mondo Sport, 700x23c, wire bead, 60TPI, w/ Flak Jacket protection

REAR TIRE

Specialized Mondo Sport, 700x23c, wire bead, 60TPI, w/ Flak Jacket protection

INNER TUBES

Standard presta valve

DRIVETRAIN

FRONT DERAILLEUR

Shimano Sora

REAR DERAILLEUR

Shimano Tiagra

SHIFT LEVERS

Shimano Sora STI, flight deck compatible

CASSETTE

Shimano HG-50, 9-speed, 12-25t

CHAIN

KMC X9 w/ reuseable Missing Link

CRANKSET

Shimano FC-R453

CHAINRINGS

50 x 39 x 30T

BOTTOM BRACKET

Shimano BB-ES25, Octalink spline, cartridge bearing, 68mm x 118mm

COCKPIT

STEM

Specialized Elite-Set, 3D forged alloy, 4-position adjustable, 4-bolt 31.8mm clamp

HANDLEBARS

Specialized Comp Ergo, 6061 alloy

TAPE

Specialized S-Wrap, cork ribbon w/ gel

SADDLE

Body Geometry Rival road, w/ steel rails

SEATPOST

Alloy, two-bolt clamp, 27.2mm

BRAKES

FRONT BRAKE

Light dual pivot brake, Teflon pivots, forged alloy, w/ standard pads

REAR BRAKE

Light dual pivot brake, Teflon pivots, forged alloy, w/ standard pads

BRAKE LEVERS

Shimano Sora STI, flight deck compatible

ACCESSORIES

PEDALS

Silver cage/black body, w/ black toe clips and strap

* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.

Geometry

	49	52	54	56	58	61
Seat-Tube Angle	75.5°	74°	73.5°	73.25°	73°	72.5°
Head-Tube Length	110mm	130mm	155mm	180mm	205mm	230mm
Seat-Post Length	300mm	350mm	350mm	350mm	350mm	350mm
Head-Tube Angle	71.75°	72.5°	72.5°	73°	73°	73.5°
Chain-Stay Length	405mm	405mm	405mm	405mm	407mm	410mm
Top-Tube Length, Horizontal	518mm	537mm	548mm	565mm	582mm	600mm
Front-Center	580mm	580mm	587mm	595mm	610mm	617mm
Handle-Bar Width	400mm	420mm	420mm	420mm	440mm	440mm
Stand-Over Height	722mm	755mm	777mm	800mm	822mm	853mm
Seat-Tube Length, B-B Center to Top	430mm	480mm	500mm	520mm	540mm	580mm
Fork Rake	45mm	45mm	45mm	43mm	43mm	43mm
B-B Drop	71.5mm	71.5mm	69mm	69mm	67.5mm	67.5mm
Trail	65mm	60mm	60mm	59mm	59mm	56mm
Wheelbase	974mm	975mm	982mm	991mm	1008mm	1018mm
Crank Length	170mm	170mm	170mm	175mm	175mm	175mm
Stem Length	75mm	90mm	100mm	100mm	110mm	120mm
